Comparative Accuracy of Circadian Phase Markers: A Critical Analysis for Biomedical Research and Chronotherapy

Abstract

Accurate assessment of circadian phase is critical for advancing chronobiology research and developing chronotherapeutic drugs. This article provides a comprehensive analysis of the comparative accuracy, methodological nuances, and practical applications of key circadian phase markers. We evaluate gold-standard biomarkers like Dim Light Melatonin Onset (DLMO) and core body temperature against emerging digital proxies derived from wearable data. Tailored for researchers and drug development professionals, this review synthesizes evidence on analytical precision, operational challenges, and validation protocols. It aims to guide the selection of optimal markers for specific research contexts, from controlled laboratory studies to large-scale real-world trials, thereby supporting the translation of circadian medicine into clinical practice.

The Circadian Clockwork: Foundational Concepts and Gold-Standard Phase Markers

The Suprachiasmatic Nucleus (SCN) of the hypothalamus functions as the master circadian pacemaker in mammals, coordinating near-24-hour rhythms in physiology and behavior to align with environmental cycles [1]. This small region of approximately 10,000 neurons sits directly above the optic chiasm and orchestrates a hierarchical network of peripheral clocks found in virtually all tissues [2] [3]. The SCN achieves this coordination through a complex system of neuronal, hormonal, and metabolic signals that synchronize subordinate oscillators, ensuring temporal harmony across organ systems [4] [3].

Understanding the SCN's function is critical in circadian research, particularly for evaluating comparative accuracy of circadian phase markers. The precision of the central pacemaker, coupled with its ability to integrate external cues (primarily light) and coordinate peripheral rhythms, establishes the foundation for assessing various molecular, physiological, and behavioral circadian biomarkers used in both basic research and drug development.

Core Timekeeping Mechanisms: From Molecular Loops to Network Coordination

The Transcriptional-Translational Feedback Loop (TTFL)

The fundamental cellular clock mechanism consists of interlocked transcriptional-translational feedback loops (TTFL) [3].

• Core Negative Feedback Loop: The CLOCK and BMAL1 proteins form a heterodimer that activates transcription of Period (Per1, Per2, Per3) and Cryptochrome (Cry1, Cry2) genes. PER and CRY proteins then multimerize, translocate to the nucleus, and inhibit CLOCK:BMAL1 activity, repressing their own transcription [2] [5].
• Stabilizing Loop: CLOCK:BMAL1 also activates transcription of Rev-erbα and Rora. REV-ERB proteins repress, while ROR proteins activate, Bmal1 transcription, creating an additional stabilizing loop [5].

This molecular oscillator operates in a precisely timed sequence across approximately 24 hours. Around circadian time (CT) 0, CRY1 blocks CLOCK:BMAL1 activity. As CRY1 degrades, CLOCK:BMAL1-driven transcription peaks (around CT8), producing REV-ERB, which subsequently represses Bmal1 (peak around CT10). PER:CRY complexes then translocate to the nucleus (around CT12), directly repressing CLOCK:BMAL1 during the subjective night [5].

Diagram 1: The Core Transcriptional-Translational Feedback Loop (TTFL) and its key inputs. The 24-hour cycle progresses through specific stages at defined Circadian Times (CT), driven by interacting feedback loops. Light entrains the loop via the Retinohypothalamic Tract (RHT), while VIP signaling helps synchronize individual SCN neuron clocks.

Beyond the TTFL: Emerging Mechanisms and Network Properties

While the TTFL remains a foundational model, recent research reveals additional layers of regulation necessary to explain the SCN's robustness:

• Non-TTFL Oscillators: Evidence points to the existence of post-translational oscillators, potentially based on ATPase activity (e.g., involving RUVBL2), that may represent an evolutionarily conserved timekeeping mechanism [3].
• Novel Synchronization Perspectives: Some models suggest that classical biochemical signaling alone may be insufficient to explain the SCN's precision. Emerging hypotheses explore potential roles for quantum biological phenomena, such as biophoton-mediated coherence or radical pair mechanisms in cryptochromes, in enhancing long-range temporal coordination [4].
• SCN Network Organization: The SCN is anatomically and functionally divided into a ventrolateral core (receiving direct retinal input via the retinohypothalamic tract and rich in Vasoactive Intestinal Peptide (VIP) neurons) and a dorsomedial shell (characterized by arginine-vasopressin (AVP) neurons) [1]. The coupling between these approximately 10,000 neurons, facilitated by neurotransmitters like GABA and peptides like VIP, transforms noisy cellular oscillations into a robust, coordinated population-level signal [3] [6]. Mathematical modeling suggests this network may exhibit small-world or scale-free properties, optimizing its ability to synchronize and resist perturbation [6].

Experimental Toolkit: Methods for SCN and Circadian Rhythm Analysis

Key Research Reagent Solutions

Table 1: Essential Research Reagents for SCN and Circadian Rhythm Investigation

Reagent Category	Specific Examples	Primary Function in Circadian Research
Primary Antibodies	Anti-AVP, Anti-VIP, Anti-GRP [7]	Immunohistochemical identification of specific SCN neuronal subpopulations (e.g., shell vs. core).
Clock Protein Antibodies	Anti-PER1/2, Anti-BMAL1, Anti-CRY1, Anti-CLOCK [7]	Visualization of core clock protein expression, localization, and rhythmicity in tissues.
Neuronal Activity Markers	Anti-c-FOS, Anti-pERK [7]	Assessment of immediate-early gene expression to map neuronal activation, e.g., in response to light.
Luciferase Reporters	Bmal1-luc, Per2-luc [8] [9]	Real-time monitoring of clock gene promoter activity in live cells or tissues, enabling period determination.
Genetic Tools	PER3 VNTR genotyping; Mutant models (e.g., Cry2 knockdown) [8] [9]	Investigation of genetic polymorphisms and gene function on circadian period, phase, and entrainment.

Core Assessment Methodologies and Protocols

Robust assessment of SCN function and circadian rhythms requires specialized protocols that control for confounding environmental variables.

Diagram 2: Key Methodological Approaches in Circadian Research. Methods span human in vivo studies, ex vivo and in vitro models, and anatomical/molecular analyses, often used in combination to validate findings and connect mechanisms to physiology.

Forced Desynchrony Protocol [9]: This gold-standard human protocol dissociates sleep-wake cycles from the endogenous circadian pacemaker. Participants live on non-24-hour (e.g., 28-hour) sleep-wake cycles in dim light, distributing behavior evenly across all circadian phases. This allows for clean measurement of the intrinsic period of the central circadian pacemaker by frequently sampling a marker like plasma melatonin or core body temperature.

Ex Vivo SCN Electrophysiology and Imaging [7] [9]: The SCN can be maintained in a brain slice preparation, allowing direct measurement of its electrical and metabolic rhythms. Neuronal firing rates show a robust circadian rhythm. Combining this with real-time imaging of gene expression (e.g., using Bmal1-luc or Per2-luc reporters) provides a high-resolution view of pacemaker function and cellular coupling.

Anatomical and Molecular Analysis [7]: Techniques like in situ hybridization and immunohistochemistry are applied to SCN tissue collected at different time points. These methods reveal the spatial and temporal patterns of clock gene expression and neuropeptide (AVP, VIP) distribution. Critical considerations include sampling at sufficient frequency across the cycle and, for free-running studies, accounting for individual period differences to avoid the appearance of dampened rhythms in group data.

Quantitative Comparison of Circadian Phase Markers

The accuracy of a circadian phase marker is evaluated based on its robustness, stability, and correlation with the master pacemaker. Different markers reflect outputs at various levels of the circadian hierarchy.

Table 2: Quantitative Comparison of Key Circadian Phase Markers

Circadian Marker	Typical Measurement Method	Relationship to SCN Pacemaker	Key Strengths	Key Limitations / Variability
Plasma Melatonin	Dim Light Melatonin Onset (DLMO) in forced desynchrony [9]	Direct, humoral output of the central pacemaker.	Gold standard for central rhythm in humans; Clear, predictable rhythm.	Invasive, requires controlled conditions; Robustness can decline in patients (e.g., -10% in MJD) [8].
Core Body Temperature (CBT)	Telemetric sensors (animal) or rectal probe (human) [8]	Tightly regulated by SCN; rhythm is a complex output.	Continuous measurement possible; strong circadian component.	Masked by activity, sleep, and food intake; Phase advance in disease (e.g., +1°C at active onset in MJD mice) [8].
Peripheral Clock Gene Expression	qPCR or luciferase reporting in fibroblasts [9]	Slaved oscillator, synchronized by SCN.	Accessible (e.g., skin biopsies); usable for high-throughput screening.	Period differs from central pacemaker (e.g., 24.61±0.33h in vitro vs. 24.16±0.17h in vivo) [9].
Rest-Activity Rhythm	Actigraphy (human) or wheel-running (animals) [2] [8]	Behavioral output driven by SCN.	Non-invasive, long-term monitoring in naturalistic settings.	Highly susceptible to environmental and social constraints; Fragmentation increases in pathology (MJD patients & mice) [8].
SCN Neuropeptide Expression	Immunohistochemistry (AVP, VIP) [7] [8]	Direct measure of SCN core timekeeping and output.	Anatomically precise; reveals SCN subpopulation function.	Invasive, terminal procedure; requires careful time-series design. Levels reduced in disease (e.g., MJD mice) [8].
Digital Circadian Biomarkers	Wearable-derived heart rate & sleep data [10]	Statistical estimate of central (CRCO) & peripheral (CRPO) phases.	Passive, real-world assessment; large-scale feasibility.	Indirect measure; CRCO-sleep misalignment increases with shift work (1.67h to 2.19h) [10].

Implications for Research and Drug Development

The choice of circadian phase marker significantly impacts research outcomes and therapeutic development. Key considerations include:

• Central vs. Peripheral Phase: Markers like melatonin rhythm reflect the central SCN pacemaker, while fibroblast rhythms or some digital biomarkers reflect peripheral oscillators, which can have different periods and responses to perturbations [9]. This is critical for drugs targeting specific tissues.
• Marker Sensitivity to Disruption: Neurodegenerative diseases like Machado-Joseph Disease (MJD) demonstrate that circadian disruption is an early pathological feature. Studies show progressive decline in rest-activity robustness, altered core body temperature rhythms, and reduced VIP/AVP in the SCN, offering potential circadian biomarkers for disease progression [8].
• Real-World Monitoring: The emergence of digital biomarkers from wearables allows for the quantification of circadian disruption—such as misalignment between the central clock and sleep—on a large scale. These markers show bidirectional links with mood and depressive symptoms, validating their use in mental health and pharmacological studies [10].

The SCN's role as the master pacemaker hinges on its multi-scale organization—from robust intracellular TTFLs to a coordinated network of coupled neurons that generates a precise temporal signal for the entire organism. A comprehensive understanding of its core principles is fundamental for selecting and interpreting circadian phase markers. The comparative data shows that while gold-standard methods like melatonin rhythm in forced desynchrony provide the most direct window into the central pacemaker, emerging methods like digital biomarkers offer scalable alternatives for real-world contexts. For researchers and drug development professionals, the strategic selection of these markers, with a clear understanding of their relationship to the SCN, is essential for accurately diagnosing circadian disorders, timing drug administrations (chronotherapeutics), and developing treatments that target the core clock mechanism itself.

Circadian rhythms, the endogenous biological oscillations with a period of approximately 24 hours, govern critical physiological processes from gene expression to behavior. Accurately defining circadian phase is paramount for researchers and clinicians, particularly in developing chronotherapies where drug administration is timed to an individual's internal clock [11]. The core parameters defining these rhythms are the period (cycle length), amplitude (oscillation strength), and phase (timing of rhythmic events). The Phase-Response Curve (PRC) quantitatively describes how external stimuli, like light or drugs, shift the phase of these rhythms. This guide compares the experimental methodologies and accuracy of contemporary tools for measuring circadian phase, providing a framework for selecting optimal approaches in research and drug development.

Comparative Analysis of Circadian Phase Measurement Techniques

The quantification of circadian phase has evolved from invasive laboratory assays to non-invasive computational estimates leveraging wearable technology. The table below compares the performance characteristics of key methodologies.

Table 1: Performance Comparison of Circadian Phase Measurement Techniques

Method / Tool	Measured Input	Ground Truth Comparison	Reported Accuracy (vs. DLMO)	Key Advantages	Key Limitations
Consumer Wearables (Activity) [12]	Wrist-based activity	Dim Light Melatonin Onset (DLMO)	~1 hour (mean absolute error)	Highly scalable, uses existing devices, performs well in shift workers	Less accurate in highly irregular schedules
Research Actigraphy (Light) [12]	Wrist-based light exposure	Dim Light Melatonin Onset (DLMO)	Performance inferior to activity in shift workers	Direct measurement of primary zeitgeber	Poor performance on disrupted schedules, requires specialized device
Singularity Response (SR) [13] [14]	Various stimuli (e.g., Dexamethasone, Forskolin)	Traditional Phase Response Curve (PRC)	Reduces experiment time from days to a single measurement [14]	High-throughput, reveals tissue-specific responses [14]	Primarily in vitro application, requires desynchronized cell populations
Wearable Heart Rate (HR) Monitoring [10] [15]	Heart Rate & Heart Rate Variability	Chronotype Questionnaires & Actigraphy	Correlates with chronotype (r = -0.73) [15]	Provides internal rhythm estimate (peripheral clock)	Indirect measure, requires robust statistical inference
Core Body Temperature (CBT) [15]	Core Body Temperature	Chronotype Questionnaires & Actigraphy	Correlates with chronotype (r = -0.61) [15]	Classic, validated circadian biomarker	Inconvenient for continuous monitoring, sensor adhesion issues

Experimental Protocols for Key Circadian Phase Studies

Understanding the experimental design behind the data is crucial for evaluating these technologies.

Protocol: Predicting Circadian Phase from Consumer Wearables

This protocol validates the use of activity data from commercial devices for phase estimation [12].

• Objective: To evaluate the accuracy of predicting circadian phase (DLMO) using activity data from consumer wearables compared to research-grade actigraphy light data.
• Subjects & Devices: Three cohorts were used: day workers (n=10) and night shift workers (n=27) wearing an Actiwatch Spectrum, and non-shift workers (n=20) wearing an Apple Watch.
• Data Collection: Participants wore devices for 7-14 days, recording activity (all devices) and light (Actiwatch) in 30-second epochs.
• Ground Truth Assessment: Following ambulatory monitoring, participants underwent in-lab assessment of DLMO via salivary melatonin every 30 minutes.
• Modeling & Analysis: Four different mathematical models of the human circadian clock were used to process the activity and light data from the wearables to generate phase predictions, which were then compared against the measured DLMO.

Protocol: Singularity Response (SR) for Phase Response Curves (PRCs)

This protocol describes a high-throughput method for quantifying entrainment properties [13] [14].

• Objective: To rapidly characterize the PRC for a given stimulus using a single experiment on a desynchronized cell population, rather than multiple stimuli at different phases.
• Cell/Model System: In vitro studies using cell lines (e.g., NIH3T3) or tissue slice cultures expressing circadian reporter genes.
• Desynchronization: A population of cellular clocks is brought to a low-amplitude "singularity state" through prolonged constant conditions or using phase-scattering agents.
• Stimulus Application: A single, defined stimulus (e.g., drug, temperature change) is applied to the desynchronized population.
• Measurement & Analysis: The subsequent re-synchronization of the population is tracked. The phase and amplitude of the resulting collective rhythm constitute the Singularity Response (SR), from which the full PRC can be mathematically reconstructed.

Protocol: Digital Markers of Circadian Disruption from Multi-Sensor Wearables

This protocol links real-world circadian disruption to mental health risks [10].

• Objective: To derive digital markers of circadian disruption from wearable data and explore their association with mood and depressive symptoms.
• Cohort: Over 800 first-year medical interns provided over 50,000 days of data.
• Data Collection: Participants wore a Fitbit Charge 2 to collect continuous heart rate (HR), activity, and sleep data.
• Circadian Inference: A nonlinear Kalman filtering framework was applied to the HR and activity data to estimate the phase of the central circadian oscillator (CRCO) and a peripheral oscillator (CRPO). Sleep midpoint was used as the behavioral rhythm.
• Disruption Metrics: Three digital markers were calculated: 1) CRCO-sleep misalignment, 2) CRPO-sleep misalignment, and 3) Internal misalignment (CRCO vs. CRPO). These were correlated with daily self-reported mood scores and PHQ-9 depression questionnaires.

Signaling Pathways and Molecular Targets of the Circadian Clock

The mammalian circadian clock is driven by a transcription-translation feedback loop (TTFL). Targeting this core mechanism is a primary goal of chronobiotic drug discovery [16].

Diagram 1: Core circadian clock transcriptional feedback loop.

This table details key tools and reagents for investigating circadian rhythms and their pharmacological modulation.

Table 2: Key Research Reagent Solutions for Circadian Biology

Reagent / Resource	Function / Description	Example Application
ChronobioticsDB [17]	A curated database of drugs and compounds known to modulate circadian rhythm parameters.	Identifying known chronobiotics for drug repurposing or understanding mechanisms.
Mathematical Models [12]	Algorithms that process light and activity data to predict circadian phase (e.g., Forger, Hannay models).	Non-invasive phase prediction from wearable device data in human subjects.
Singularity Response (SR) Method [13] [14]	A high-throughput experimental protocol that uses desynchronized cells to estimate a full Phase Response Curve (PRC) from a single measurement.	Rapidly screening the resetting potential of pharmaceutical compounds on cellular clocks.
Reporter Cell Lines [11]	Cells engineered with luciferase or fluorescent proteins under control of circadian gene promoters (e.g., PER2::LUC).	Real-time, longitudinal monitoring of circadian rhythms in living cells or tissues.
Core Clock-Targeting Compounds [16]	Small molecules targeting specific clock components (e.g., CRY ligands, REV-ERB agonists/antagonists, CK1 inhibitors).	Pharmacologically probing clock function and developing chronotherapeutics.

The accurate definition of circadian phase is a multi-faceted challenge addressed by a suite of evolving technologies. While gold-standard assays like DLMO remain essential for validation, the field is rapidly advancing towards scalable, non-invasive methods based on wearable data and sophisticated mathematical models [12] [10]. For in vitro drug discovery, the Singularity Response method offers a powerful high-throughput alternative to traditional PRC measurement [13] [14]. The choice of tool depends critically on the research context: population-level studies in real-world settings benefit from consumer wearables, whereas mechanistic drug discovery relies on molecular tools and high-throughput cellular assays. A unified understanding of these approaches—from their experimental protocols to their comparative performance—enables researchers and drug developers to precisely target the circadian clock for therapeutic benefit.

Dim Light Melatonin Onset (DLMO) is universally recognized as the most reliable marker of the central circadian phase in humans. This assessment provides a comparative analysis of DLMO against other circadian phase markers, detailing its experimental protocols, accuracy, and applications in clinical and research settings. We synthesize current evidence to affirm its gold-standard status and explore emerging methodologies that seek to complement or potentially supplement this measure in the future.

The suprachiasmatic nucleus (SCN) in the hypothalamus acts as the master pacemaker of the circadian system, orchestrating 24-hour rhythms in physiology, metabolism, and behavior. Accurate assessment of its phase is crucial for diagnosing circadian rhythm sleep-wake disorders, optimizing chronotherapeutics, and understanding the impact of circadian disruption on health. While numerous physiological rhythms reflect circadian influence, the gold standard for assessing central clock timing remains the dim-light melatonin onset (DLMO).

DLMO represents the time in the evening when endogenous melatonin secretion from the pineal gland begins to rise, marking the transition to the biological night. Its preeminence stems from its direct regulation by the SCN, its relatively stable phase relationship with the sleep-wake cycle, and its measurability in accessible biofluids like saliva and blood. This review systematically evaluates DLMO's validation, performance, and practicality against emerging alternatives, providing researchers with the methodological foundation necessary for its implementation in circadian medicine.

The Scientific Basis of DLMO

Physiological Pathway of Melatonin Secretion

Melatonin synthesis is a direct output of the central circadian clock. The SCN transmits signals through a multi-synaptic pathway to the pineal gland, which is suppressed by light during the day via GABA-ergic input. As darkness falls, this suppression is removed, leading to the disinhibition of the pineal gland and the release of melatonin into the circulation. This sharp increase in melatonin concentration at the beginning of the biological night is the physiological event captured by the DLMO measurement [18] [19].

Diagram: The physiological pathway from light input to melatonin secretion.

DLMO as the Gold Standard

DLMO is considered the best-established marker of central circadian phase for several key reasons [20] [19]. It provides a direct functional readout of the SCN's rhythmic control over the pineal gland, unlike other rhythms that may be more susceptible to masking by non-circadian factors. Methodologically, it allows for precise phase determination with a standard deviation of approximately 14 to 21 minutes, a level of precision unmatched by other endocrine markers like cortisol, which has a standard deviation of about 40 minutes [19].

The reliability of DLMO is reflected in its inclusion in the latest catalog of diagnostic criteria for circadian rhythm sleep disorders [21]. Its accuracy in defining internal circadian time has made it the indispensable reference against which all novel circadian biomarkers must be validated.

Comparative Analysis of Circadian Phase Markers

While DLMO is the gold standard, other rhythms are sometimes used to assess circadian phase. The table below provides a quantitative comparison of DLMO with other common markers.

Table 1: Quantitative Comparison of Key Circadian Phase Markers

Marker	Biological Source	Approx. Phase Precision (SD)	Key Advantage	Primary Limitation
DLMO [19]	Pineal Gland (Saliva/Blood)	14-21 minutes	Direct SCN output; High precision	Logistically burdensome; Requires dim light
Core Body Temperature (CBT) Minimum [20]	Systemic Physiology	~1 hour	Can be continuously monitored	Strongly masked by sleep/wake cycles and posture
Cortisol Awakening Response (CAR) [19]	Adrenal Cortex (Saliva/Blood)	~40 minutes	Easy morning sampling	Highly sensitive to stress and awakening artifacts
Peripheral Blood Monocyte Transcriptome (BodyTime) [21]	Blood Monocytes	Comparable to DLMO*	Requires only a single blood sample	Reflects peripheral oscillator phase in addition to central drive

Performance Data from Validation Studies

The superiority of DLMO is demonstrated in head-to-head comparisons. In the development of the "BodyTime" assay, a blood transcriptome-based test was shown to be "as accurate as the current gold standard method, dim light melatonin onset" for estimating internal circadian time [21]. This external validation underscores DLMO's role as the benchmark.

Emerging digital markers derived from wearable devices, such as circadian rhythms in heart rate, show promise for real-world, longitudinal assessment. However, their validation still relies on correlation with gold-standard measures like DLMO to confirm their accuracy in reflecting the central circadian phase [20] [10].

Standard and Emerging DLMO Measurement Protocols

The Gold-Standard Laboratory Protocol

The traditional method for assessing DLMO involves a controlled laboratory or clinical setting to minimize confounding variables [21] [19].

Detailed Methodology:

• Pre-Sampling Conditions: Participants must avoid substances that affect melatonin levels (e.g., beta-blockers, NSAIDs, antidepressants, melatonin supplements) for a suitable washout period. They should maintain a regular sleep-wake schedule for several days prior.
• Dim-Light Environment: Sampling must occur in dim light (<10-30 lux) to prevent light-induced melatonin suppression. This typically requires a dedicated, light-controlled room or chamber.
• Sample Collection: Saliva or blood plasma samples are collected at regular intervals (e.g., every 30-60 minutes) over a 4- to 8-hour window in the evening and early night (e.g., from 5 hours before to 1 hour after habitual bedtime).
• Sample Handling: Saliva samples are typically centrifuged and frozen at -20°C or -80°C until analysis.
• Melatonin Assay: Hormone concentration is determined using sensitive techniques like radioimmunoassay (RIA), enzyme-linked immunosorbent assay (ELISA), or the more specific liquid chromatography-tandem mass spectrometry (LC-MS/MS) [19].
• DLMO Calculation: The time of DLMO is determined by interpolating between sample times. Common methods include:
  • Fixed Threshold: Time when concentration crosses an absolute threshold (e.g., 3 pg/mL or 4 pg/mL for saliva).
  • Variable Threshold: Time when concentration rises 2 standard deviations above the mean of baseline (pre-rise) samples.
  • "Hockey-Stick" Algorithm: An objective, automated method that identifies the point of change from baseline to a sustained rise [18] [19].

Diagram: Standard workflow for laboratory-based DLMO assessment.

Remote and Home-Based DLMO Protocols

To overcome the logistical and cost barriers of in-lab testing, validated home-based DLMO protocols have been developed [18] [22].

Key Modifications for Remote Collection:

• At-Home Kits: Participants are provided with a kit containing salivettes, a dim red light headlamp, a light meter to verify ambient dim light, blue light-blocking glasses, and pre-labeled tubes and cool packs for sample storage [22].
• Objective Compliance Monitoring: Studies use tools like medication event monitoring system (MEMS) bottle caps that record the exact time of sample collection and temperature sensors to ensure sample integrity during storage and shipping [22].
• Feasibility: Recent studies have shown high rates of detectable DLMO (>98%) using home-based methods, even in specific populations like individuals with obesity, demonstrating robust feasibility and acceptability [18] [22].

The Scientist's Toolkit: Essential Reagents and Materials

Table 2: Key Research Reagent Solutions for DLMO Measurement

Item	Function/Description	Application Note
Salivette (Sarstedt) [22]	Untreated cotton or synthetic swab in a plastic centrifuge tube for sterile saliva collection.	Standardized for hormone collection; compatible with various assays.
Melatonin ELISA/RIA Kits [19]	Immunoassay kits for quantifying melatonin concentration in saliva or plasma.	Cost-effective; potential for cross-reactivity. Requires validation.
LC-MS/MS Platform [19]	Liquid chromatography with tandem mass spectrometry for hormone quantification.	Higher specificity and sensitivity; considered the analytical gold standard.
Actigraphy Watch (e.g., ActTrust) [22]	Wearable device to monitor rest-activity cycles and sleep timing for days/weeks before DLMO.	Provides objective data on sleep-wake patterns and calculates phase angle.
Digital Lux Meter (e.g., VWR LXM001) [22]	Precisely measures ambient light intensity to verify dim-light conditions during sampling.	Critical for protocol adherence and data validity.
Blue Light-Blocking Glasses [22]	Prevents melatonin suppression from screens or ambient light during evening sampling.	Essential for participant compliance in home settings.

DLMO remains the undisputed gold-standard biomarker for assessing the phase of the central circadian clock. Its direct physiological link to the SCN, high precision, and robust validation across countless studies solidify this status. While traditional laboratory assessment is cumbersome, the successful development of remote, home-based protocols is enhancing its accessibility for large-scale studies and clinical application.

The future of circadian phase assessment lies not in replacing DLMO, but in leveraging its precision to validate novel, scalable tools. Transcriptomic assays like BodyTime and digital biomarkers from wearables show significant promise for specific use cases, but they are validated against and ultimately complementary to the reliable benchmark that DLMO provides. For any research or clinical application requiring an accurate measure of the central circadian phase, DLMO is the definitive tool.

The accurate assessment of an individual's internal circadian phase is a cornerstone of chronobiology and precision medicine. While multiple biomarkers exist, the core body temperature (CBT) minimum remains a foundational physiological marker. The advent of validated, non-invasive wearable sensors has significantly enhanced the feasibility of continuous CBT monitoring in real-world settings, positioning it for direct comparison with other established and emerging circadian phase markers. The following table summarizes the key characteristics of these markers based on current research.

Table 1: Comparative Analysis of Primary Circadian Phase Markers

Marker	Underlying Physiology	Typical Measurement	Key Performance Data	Key Advantages	Key Limitations
Core Body Temperature (CBT) Minimum	Rhythms in heat production and loss driven by the suprachiasmatic nucleus (SCN); minimum typically occurs in the second half of the night [23].	Continuous measurement via ingestible pills or validated non-invasive wearables (e.g., Calera sensor) [24].	Correlates with Actigraph-derived acrophase (r=0.79, p<0.001) [25]. High agreement with rectal temperature for phase timing (ICC=0.96) [24].	Robust, continuous physiological signal; validated for home use with minimal invasiveness [25] [24].	Requires specialized equipment; waveform can be masked by activity, postural changes, and sleep [23].
Dim Light Melatonin Onset (DLMO)	Evening rise in melatonin secretion from the pineal gland, directly controlled by the SCN [19].	Serial saliva or blood samples (e.g., 4-6 hour window before habitual bedtime) analyzed with LC-MS/MS or immunoassay [19].	Considered the "gold standard" peripheral marker; allows SCN phase determination with high precision (SD: 14-21 minutes) [19].	High temporal precision; direct output of the central pacemaker [19].	Logistically demanding; requires controlled dim light; expensive; sampling frequency limits temporal resolution [19].
Cortisol Awakening Response (CAR)	Sharp rise in cortisol levels 30-45 minutes after waking, reflecting HPA axis activity influenced by circadian timing [19].	Serial saliva or blood samples collected immediately upon waking and at intervals thereafter [19].	Less precise phase marker than DLMO (SD: ~40 minutes) [19].	Non-invasive sampling; integrates circadian phase with stress system activity [19].	Highly sensitive to stress and anticipation of waking; lower precision for circadian phase assessment [19].
Activity-Rhythm Acrophase	Behavioral manifestation of the sleep-wake cycle, influenced by both circadian and homeostatic processes [23].	Wrist-worn actigraphy over multiple days [25] [10].	Correlates strongly with CBT-derived acrophase (r=0.96, p<0.001) [25].	Low-cost and common hardware; ideal for long-term, ecologically valid studies [25] [10].	An indirect proxy; can be confounded by environmental constraints and non-circadian motivated behaviors [23].

Detailed Experimental Protocols for Marker Assessment

Protocol for CBT Minimum Assessment via Non-Invasive Wearable Sensor

This protocol is adapted from validation studies involving the Calera wearable sensor, which provides a practical method for obtaining circadian CBT data outside the laboratory [25] [24].

• Objective: To determine the timing of the CBT minimum over multiple 24-hour cycles in a participant's natural environment.
• Equipment: Calera research-grade wearable core body temperature sensor (or equivalent validated device) [24].
• Duration: A minimum of 3-5 days of continuous monitoring is recommended for reliable phase assessment, though longer periods (e.g., 14 days) improve robustness [25] [24].
• Procedure:
  • Sensor Calibration & Placement: Ensure the sensor is individually calibrated. Adhere to manufacturer instructions for placement on the skin (typically on the chest or upper arm) to ensure optimal skin contact and data quality [24].
  • Data Collection: Participants wear the sensor continuously throughout the study period, including during sleep and bathing (if the device is waterproof). They are instructed to maintain a normal daily routine.
  • Data Processing:
    • Raw heat flux and skin temperature data are processed by the device's algorithm to estimate CBT [24].
    • Data is visually inspected for artifacts (e.g., periods of poor contact or device removal).
    • A cosinor analysis or similar non-linear filtering technique (e.g., Kalman filter) is applied to the clean, time-stamped CBT data to model the circadian waveform [10].
  • Phase Determination: The CBT minimum is identified as the time of the lowest point in the fitted circadian CBT curve for each 24-hour period [10].

Protocol for DLMO Assessment (Salivary)

This protocol outlines the standard method for assessing the circadian phase using melatonin, widely regarded as a gold standard against which other markers are compared [19].

• Objective: To determine the Dim Light Melatonin Onset (DLMO) time in a controlled, dim-light environment.
• Equipment: Salivette collection tubes; freezer for sample storage at ≤ -20°C; access to a dim-light environment (< 10 lux); LC-MS/MS system for hormone analysis [19].
• Duration: A single evening session of 4-6 hours.
• Procedure:
  • Participant Preparation: For 2 hours prior to and throughout sampling, participants remain in dim light (< 10 lux). They should refrain from eating, drinking caffeinated beverages, brushing teeth, or engaging in vigorous activity.
  • Sample Collection: Starting 5 hours before and continuing until 1 hour after habitual bedtime, participants provide saliva samples every 30 minutes [19]. Exact sampling times are rigorously recorded.
  • Sample Analysis: Saliva samples are centrifuged and analyzed using LC-MS/MS, which offers superior specificity and sensitivity compared to immunoassays [19].
  • Phase Determination (DLMO Calculation): The most common method is the fixed threshold approach, where DLMO is defined as the time when the interpolated melatonin concentration crosses a predefined threshold (e.g., 3-4 pg/mL in saliva) [19]. Alternative methods include the variable threshold (2 standard deviations above the mean of baseline samples) or the "hockey-stick" algorithm [19].

Visualizing Circadian Phase Assessment Workflows

The following diagrams illustrate the logical and methodological pathways for determining circadian phase using CBT and DLMO.

Circadian Phase Marker Decision Pathway

Core Body Temperature Measurement Workflow

The Scientist's Toolkit: Essential Research Reagent Solutions

For researchers designing studies involving circadian phase assessment, the following tools and reagents are critical for generating high-quality data.

Table 2: Essential Research Tools for Circadian Phase Assessment

Tool/Reagent	Function in Circadian Research	Key Considerations
Non-Invasive CBT Sensor (e.g., Calera)	Enables continuous, ambulatory monitoring of core body temperature rhythm for determining CBT minimum [24].	Validated against gold-standard methods (e.g., ingestible pills, rectal probes); check for individual unit calibration and battery life for longitudinal studies [24].
Portable Actigraph	Records movement data to calculate activity-based rest-activity cycles and acrophase as a behavioral circadian proxy [25] [10].	Select devices with validated algorithms for sleep-wake detection; consider compatibility with analysis software.
Salivette Collection Kits	Facilitates the standardized, non-invasive collection of saliva samples for DLMO and CAR assessment [19].	Use kits that do not interfere with assay analysis (e.g., LC-MS/MS); ensure a cold chain for sample storage.
LC-MS/MS Instrumentation	Provides high-specificity, high-sensitivity quantification of low-abundance hormones like melatonin and cortisol in saliva and blood [19].	Superior to immunoassays by avoiding cross-reactivity; requires significant capital investment and technical expertise [19].
Dim Light Chamber	Provides a controlled environment (< 10 lux) necessary for unbiased assessment of DLMO, preventing light-induced melatonin suppression [19].	Critical for protocol fidelity; light levels must be verified with a lux meter.

The cortisol awakening response (CAR) is defined as a profound increase in cortisol secretion from the adrenal glands that occurs during the first 30-60 minutes after awakening. This phenomenon is considered a distinct feature of the hypothalamus-pituitary-adrenal (HPA) axis, superimposing the fundamental circadian rhythmicity of cortisol secretion [26]. In circadian medicine, accurate assessment of HPA axis rhythmicity provides critical insights into an individual's stress physiology and overall health status. The CAR has attracted significant research interest as a potential biomarker for stress reactivity in various pathological conditions, including depression, post-traumatic stress disorder, and other stress-related disorders [27]. Within the context of comparative circadian phase marker research, the CAR represents one of several measurable outputs that can reveal the functional status of the body's central circadian timing system and its alignment with peripheral oscillators.

The accurate assessment of circadian parameters is fundamental to understanding their role in physical and mental health. Traditional circadian research has focused on quantifying phase, amplitude, period, and disruption of circadian oscillators, which is essential for investigating sleep-wake disorders, social jet lag, interindividual differences in entrainment, and developing chronotherapeutics [20]. The CAR occupies a unique position within this landscape as it represents a dynamic response that may reflect the complex interaction between the central circadian pacemaker in the suprachiasmatic nucleus (SCN), HPA axis activity, and behavioral transitions such as sleep-wake cycles.

Methodological Approaches for Assessing HPA Axis Rhythmicity

Traditional CAR Measurement Protocols

Conventional assessment of the CAR typically involves the collection of saliva samples at multiple time points upon awakening and during the subsequent hour. This approach requires strict participant adherence to sampling protocols, including precise recording of awakening time and minimal delay in obtaining the first sample. The diurnal cycle of cortisol secretion follows a characteristic pattern, with the CAR representing a distinct surge superimposed upon the gradual circadian decline throughout the day [26]. Methodological guidelines emphasize the importance of controlled conditions for obtaining reliable CAR data, as factors such as sampling delay, light exposure, and stress can significantly influence measurements [27].

The traditional view posits that the CAR is a distinct phenomenon separate from the underlying circadian rhythm of cortisol secretion, potentially serving as a marker of anticipation for the upcoming day [26]. Research has indicated that the CAR is influenced by a variety of factors including gender, health status, health behaviors, and stress perception [26]. Furthermore, associations have been observed between the CAR and patterns of cortical activation, with one study finding that individuals with greater right-sided centroparietal cortical activation showed an increased CAR in anticipation of exams [28].

Novel Methodological Advances

Recent technological innovations have enabled more sophisticated approaches to assessing HPA axis rhythmicity. In vivo microdialysis represents a significant advancement, allowing continuous measurement of tissue-free cortisol levels in interstitial fluid in naturalistic home settings [27]. This method involves the insertion of a linear microdialysis probe subcutaneously in abdominal tissue, with samples collected automatically over a 24-hour period using a portable device. This approach minimizes the intrusiveness of measurement and allows for assessment of cortisol dynamics before and after awakening without disrupting normal daily activities or sleep quality.

Another innovative approach involves using wearable devices to derive digital markers of circadian disruption. These methods employ computational algorithms, including nonlinear Kalman filtering frameworks, to analyze physiological time-series data such as heart rate and activity patterns collected from wearables [10]. This enables simultaneous statistical inference of multiple circadian biomarkers, including the central circadian oscillator and peripheral oscillators, under real-world conditions. These digital approaches facilitate large-scale data collection over extended periods, providing insights into circadian disruption patterns not feasible with laboratory-based methods alone.

Table 1: Comparison of Methodological Approaches for Assessing HPA Axis Rhythmicity

Method	Key Features	Advantages	Limitations
Salivary CAR Assessment	Multiple samples after awakening; Cortisol immunoassays	Non-invasive; Suitable for home collection; Established protocols	No pre-awakening measurements; Subject to compliance issues; Single day assessment typically
Plasma Cortisol Measurement	Repeated blood sampling in controlled settings	High accuracy; Direct measurement; Precise awakening time assessment	Invasive; Laboratory setting affects sleep; Not suitable for long-term monitoring
In Vivo Microdialysis	Continuous interstitial fluid collection; Portable device	Continuous measurement; Naturalistic setting; Pre- and post-awakening data	Potential time lag vs plasma; 20-min averaging; Semi-invasive procedure
Wearable-Derived Digital Markers	Heart rate, activity, sleep data; Computational algorithms	Passive continuous monitoring; Large-scale deployment; Real-world data	Indirect measure; Validation against gold standards ongoing

Comparative Analysis of Circadian Phase Markers

The CAR in the Context of Other Circadian Biomarkers

The cortisol awakening response must be understood within the broader landscape of circadian biomarkers, which include melatonin rhythms, core body temperature, peripheral clock gene expression, and behavioral rhythms. The suprachiasmatic nucleus (SCN) serves as the master circadian pacemaker, regulating multiple output rhythms through complex neuroendocrine pathways [29]. The SCN regulates the pineal gland's production of melatonin through a multi-step pathway, with melatonin secretion occurring during the dark phase and effectively signaling the body to prepare for sleep [30]. This rhythm is frequently used as a gold standard marker for assessing the phase of the central circadian clock.

Circadian rhythms are generated at the molecular level by a transcriptional-translational feedback loop involving core clock genes. The CLOCK protein forms a heterodimer with BMAL1, binding to E-box enhancer elements upstream of Period (Per) and Cryptochrome (Cry) genes, thereby activating their transcription [30]. These molecular rhythms can be measured in various tissues and represent another class of circadian phase markers. The relationship between these different circadian biomarkers is complex, with the CAR representing an integrated neuroendocrine output that may reflect both central and peripheral circadian processes.

Emerging Challenges to the CAR as a Distinct Circadian Marker

Recent research has raised fundamental questions about the nature of the CAR as a distinct circadian marker. A groundbreaking study using in vivo microdialysis to measure tissue-free cortisol levels in 201 healthy volunteers before and after awakening in a home setting found that the rate of increase in cortisol secretion did not change when participants awoke compared with the preceding hour when they were asleep [27]. This finding challenges the long-standing assertion that CAR is a distinctive post-awakening response superimposed on an endogenous cortisol rhythm.

Instead, this research suggests that the best predictor of cortisol increase after awakening was the level of cortisol reached in the hour preceding awakening, indicating that cortisol secretion during initial waking appears to be more tightly regulated by intrinsic circadian rhythmicity than by the transition from sleep to wakefulness itself [27]. The study revealed considerable between-subject variability in cortisol dynamics, which was partly explained by sleep duration and timing of waking relative to the previous morning. For individuals with long sleep duration (mean 548 minutes), the maximal rate of cortisol release occurred 97 minutes before waking, whereas short sleepers (mean 369 minutes) showed a maximum increase in cortisol release 12 minutes after waking [27].

Table 2: Comparative Accuracy of Circadian Phase Markers in Human Research

Circadian Marker	Biological Source	Assessment Method	Phase Accuracy	Practical Utility
CAR	HPA Axis	Salivary cortisol, plasma, microdialysis	Disputed; may reflect circadian zenith rather than distinct response [27]	Moderate; subject to multiple confounding factors
Dim Light Melatonin Onset (DLMO)	Pineal Gland	Salivary/plasma melatonin	High; reliable marker of central circadian phase [20]	Low; requires controlled dim light conditions
Core Body Temperature	SCN via autonomic nervous system	Rectal/ingestible sensors	Moderate; masked by activity and sleep [20]	Low; impractical for long-term monitoring
Peripheral Clock Gene Expression	Various tissues	Transcriptomic analysis	Variable; tissue-specific phases [20]	Low; invasive sampling required
Wearable-Derived Digital Markers	Multiple systems	Heart rate, activity, skin temperature	Moderate; correlates with central phase under entrained conditions [10]	High; suitable for long-term real-world assessment

Signaling Pathways and Regulatory Mechanisms

The regulation of cortisol secretion involves a complex hierarchical system with multiple levels of control. The following diagram illustrates the key components and their interactions:

HPA Axis Regulatory Pathways

The hypothalamic-pituitary-adrenal axis is regulated by a complex network of neural and endocrine signals. The suprachiasmatic nucleus (SCN) serves as the master circadian pacemaker, sending neural projections to the paraventricular nucleus (PVN) of the hypothalamus [31]. The PVN releases corticotropin-releasing hormone (CRH), which stimulates the pituitary gland to secrete adrenocorticotropic hormone (ACTH). ACTH then acts on the adrenal cortex to stimulate cortisol synthesis and release. Cortisol exerts negative feedback on both the PVN and pituitary to regulate its own production. This system is influenced by both circadian inputs from the SCN and stress-related inputs from various brain regions [31].

The molecular machinery of circadian timing involves a core feedback loop of clock genes. The CLOCK-BMAL1 heterodimer activates transcription of Per and Cry genes, whose protein products eventually suppress their own transcription, creating approximately 24-hour oscillations [30]. These molecular rhythms regulate the timing of the HPA axis and are themselves influenced by hormonal signals, including cortisol. This creates a bidirectional relationship between the circadian system and HPA axis function, with disruptions in one system potentially affecting the other.

Experimental Evidence and Current Controversies

Key Experimental Findings

The fundamental nature of the CAR has been questioned by a recent study that adopted an innovative microdialysis approach to measure tissue-free cortisol levels in 201 healthy volunteers before and after awakening in a home setting [27]. This research found that at a population level, the rate of change of cortisol increase was no different between the first hour of awakening and the preceding hour, demonstrating that waking per se is not accompanied by a distinct acceleration in cortisol release [27]. Instead, the best predictor of increased release was the level of cortisol reached in the hour preceding awakening.

The same study revealed remarkable individual differences in cortisol dynamics based on sleep patterns. For individuals with long sleep durations (~9 hours), maximal cortisol secretion occurred well before awakening (97 minutes prior), whereas for short sleepers (~6 hours), the maxima occurred after waking (12 minutes post-awakening) [27]. Similar patterns emerged for individuals with aligned versus misaligned sleep schedules relative to their previous wake time, highlighting the importance of sleep regularity in circadian cortisol rhythms.

Research using wearable devices to assess circadian disruption in large populations has revealed significant associations between circadian misalignment and mental health risks. One study analyzing over 50,000 days of data from more than 800 first-year physicians found that circadian disruption markers were bidirectionally linked to mood both before and after participants began shift work [10]. Specifically, misalignment between the central circadian oscillator and the sleep-wake cycle had the most significant negative impact on next-day mood.

Implications for Chronotherapy and Drug Development

The growing understanding of circadian rhythms in hormone regulation and drug metabolism has significant implications for chronotherapy—the practice of timing medication administration to optimize efficacy and minimize side effects. Research has shown that the timing of drug administration can affect a medication's effectiveness and side effects by as much as ten times based on circadian rhythms [30]. This is particularly relevant for psychiatric medications, as disorders such as major depression, bipolar disorder, and schizophrenia are associated with disruptions in circadian rhythms [30].

Mathematical modeling approaches have been developed to optimize dosing regimens based on circadian physiology. One such model focusing on dopamine reuptake inhibitors found that taking these medications a few hours before the body's natural rise in dopamine can help prolong the treatment's effects [32]. The model also revealed that taking medications at the wrong circadian time can trigger sharp spikes and crashes in neurotransmitter levels, while properly timed dosing sustains levels much longer [32].

Table 3: Chronotherapy Applications Based on Circadian Principles

Therapeutic Area	Circadian Consideration	Chronotherapy Approach	Evidence Level
Psychiatric Disorders	HPA axis dysregulation; CAR alterations	Timing of antidepressants to align with cortisol rhythms [30]	Preclinical and limited clinical studies
Neurodegenerative Diseases	Dopamine and other neurotransmitter rhythms	Dosing of Parkinson's medications before natural dopamine rise [32]	Mathematical modeling and some clinical validation
Metabolic Disorders	Circadian rhythms in glucose metabolism	Timing of food intake and medications to align with metabolic rhythms [29]	Animal studies and emerging human trials
Cancer Therapy	Cell cycle rhythms and drug metabolism cycles	Timing chemotherapy to minimize toxicity and maximize efficacy [29]	Some clinical implementation with ongoing research

The Scientist's Toolkit: Essential Research Reagents and Methodologies

Table 4: Essential Research Materials for HPA Axis and Circadian Rhythm Research

Research Tool	Application	Key Features	Representative Use
Salivary Cortisol Kits	CAR assessment in naturalistic settings	Non-invasive; home collection; immunoassay-based	Traditional CAR measurement with multiple post-awakening samples [26]
In Vivo Microdialysis System	Continuous cortisol monitoring	Portable; continuous ISF sampling; 20-min intervals	Assessment of pre- and post-awakening cortisol dynamics [27]
Wearable Activity Monitors	Digital circadian rhythm assessment	Long-term monitoring; heart rate, activity, sleep data	Derivation of central and peripheral circadian phase markers [10]
Transcriptomic Analysis Kits	Peripheral clock gene expression	RNA sequencing; microarray; qPCR	Molecular rhythm assessment in tissues or blood [20]
Melatonin Assays	DLMO assessment for central circadian phase	Salivary or plasma measurement; dim light conditions	Gold standard phase marker comparison [20]
Mathematical Modeling Platforms	Chronotherapy optimization	Computational simulation of circadian drug effects	Dosing time optimization for dopamine medications [32]

The assessment of HPA axis rhythmicity through cortisol measurements, particularly the cortisol awakening response, remains an active and evolving area of research. While traditional views conceptualize the CAR as a distinct response to awakening, emerging evidence suggests it may be more tightly coupled to underlying circadian processes than previously thought [27]. This has significant implications for its utility as a circadian phase marker in both research and clinical applications.

Future research directions should focus on reconciling disparate findings from different measurement methodologies, understanding the substantial interindividual variability in CAR patterns, and developing integrated models that account for the complex interactions between central and peripheral circadian oscillators, the HPA axis, and behavioral cycles. The development of novel digital approaches for circadian assessment [10] holds particular promise for large-scale, real-world monitoring of circadian health and its relationship to disease states. As these methodologies continue to evolve, so too will our understanding of the fundamental nature of the cortisol awakening response and its place in the pantheon of circadian phase markers.

In the field of chronobiology, accurately assessing the phase and amplitude of the body's internal clock is paramount for both research and clinical applications. The endogenous circadian pacemaker, located in the suprachiasmatic nucleus (SCN) of the hypothalamus, regulates near-24-hour oscillations in numerous physiological processes, from sleep-wake cycles to hormone secretion [33] [20]. However, since the SCN cannot be measured directly in humans, researchers rely on peripheral markers to infer its status. Among the most established of these markers are the rhythms of melatonin, cortisol, and core body temperature (CBT). This guide provides a comparative analysis of these three key circadian rhythms, evaluating their interrelationships, accuracy, and methodological considerations to inform researchers and drug development professionals in the selection of appropriate biomarkers for circadian phase assessment.

Physiological Interrelationships of Circadian Markers

The rhythms of melatonin, cortisol, and CBT are intrinsically linked yet represent distinct aspects of the circadian system's output. Their precise temporal relationships create a predictable pattern over the 24-hour day.

Phase and Temporal Relationships

Under normal entrained conditions, these three markers exhibit a specific phase sequence:

• Melatonin (DLMO): Levels begin to rise in the evening under dim light, typically peak around 2-4 AM, and decrease to low levels by morning [34] [35]. This hormone is a direct marker of the circadian night.
• Core Body Temperature: The CBT rhythm reaches its minimum during the late night/early morning, approximately 1-2 hours before habitual wake time [36] [10].
• Cortisol: This hormone shows a sharp rise in the early morning, peaking around 8-9 AM shortly after awakening (Cortisol Awakening Response) [34] [35].

A study by Rivest et al. (1989) revealed that these rhythms have different underlying ultradian frequencies—approximately 5.5 hours for melatonin and 8 hours for cortisol—suggesting different control mechanisms for their pulsatile secretion [37]. Furthermore, the temporal relationship is such that plasma melatonin begins to rise when cortisol is at its lowest, peaks as cortisol begins its ascent, and declines as cortisol reaches its peak [37].

Underlying Circadian Pacemaker vs. Peripheral Oscillators

A critical distinction must be made between markers that reflect the central SCN pacemaker and those influenced by peripheral oscillators or masking effects.

• Melatonin: Widely considered the gold-standard proxy for the central pacemaker due to its strong control by the SCN and relative resistance to non-photic masking effects, though light exposure must be controlled [20] [34].
• Core Body Temperature: The endogenous component of the CBT rhythm is a marker of the central pacemaker, but it is highly susceptible to masking from activity, posture, and the sleep-wake cycle, necessitating specialized protocols like the Constant Routine for accurate measurement [36] [20].
• Cortisol: While its circadian pattern is under SCN control via the hypothalamic-pituitary-adrenal (HPA) axis, cortisol is highly susceptible to masking from stress, posture, and light [37] [34].

Table 1: Characteristic Phase Timing of Primary Circadian Markers under Entrained Conditions

Circadian Marker	Evening/Late Night Phase	Early Morning Phase	Daytime Phase
Melatonin	Rise begins in evening (DLMO), peaks at 2-4 AM [34] [35]	Levels decline rapidly after wake time	Low baseline levels
Core Body Temperature (CBT)	Gradual decline through evening	Minimum ~1-2 hrs before wake time [36] [10]	Rises through day, peak in afternoon/evening
Cortisol	Lowest trough during early night	Sharp rise (CAR) around wake time, peak at 8-9 AM [34] [35]	Gradual decline through day, low evening

Comparative Accuracy and Variability as Phase Markers

The utility of a circadian marker depends heavily on its precision and low variability when measured under controlled conditions.

Direct Comparison of Phase Estimation Variability

A landmark study by Klerman et al. (2002) directly compared the mathematical variability of phase estimates for melatonin, cortisol, and CBT under controlled conditions where pacemaker variability was minimized. The results demonstrated clear hierarchical performance among the markers [38].

Table 2: Comparative Variability of Circadian Phase Estimates from Key Markers [38]

Circadian Marker	Approximate Standard Deviation of Phase Estimates (Hours)	Relative Ranking for Precision
Plasma Melatonin	0.23 - 0.35 hours	Highest Precision
Plasma Cortisol	~0.65 hours	Intermediate Precision
Core Body Temperature (CBT)	~0.78 hours	Lowest Precision

This study concluded that all methods of calculating circadian phase from plasma melatonin data were less variable than those using CBT or cortisol data [38]. This superior precision makes melatonin the marker of choice for studies requiring high accuracy, such as quantifying phase shifts in response to light or determining circadian phase in clinical populations.

Relationship to Chronotype and Age

The phase of these markers varies systematically with an individual's chronotype (morningness-eveningness) and age.

• Chronotype: In young adults, the phases of melatonin and CBT rhythms occur significantly earlier in morning-types than in evening-types [36]. This relationship underscores that self-reported preference is reflected in physiological markers.
• Aging: Older adults, who tend to be more morning-type, exhibit an earlier circadian phase. However, the phase angle between circadian phase and waketime is shorter in older morning-types compared to young morning-types, indicating age-related changes in the fundamental relationship between the pacemaker and the sleep-wake cycle that are not fully explained by a shift toward morningness [36].

Methodological Protocols and Emerging Technologies

Accurate assessment requires strict control over confounding factors. The following experimental protocols and technologies are central to the field.

Gold-Standard Measurement Protocols

• Dim Light Melatonin Onset (DLMO): The gold standard for phase assessment. It requires sampling melatonin in dim light (<10-15 lux) in the evening, typically via saliva or plasma every 30-60 minutes to determine the time when levels rise above a predetermined threshold [34] [39].
• Constant Routine (CR) Protocol: A rigorous procedure designed to unmask the endogenous circadian component by eliminating or distributing confounding factors evenly across the cycle. Participants remain awake for at least 24 hours in a semi-recumbent posture under constant dim light, with nutritional intake distributed evenly in small snacks [36] [20]. This protocol is essential for obtaining clean CBT and cortisol rhythms.
• Forced Desynchrony Protocol: Participants are scheduled to live on a day length (e.g., 28 hours) far from 24 hours, allowing the separation of endogenous circadian rhythms from the effects of sleep and behavior [20].

Novel and Emerging Assessment Methods

Recent innovations aim to make circadian phase assessment more accessible for real-world and clinical settings.

• Wearable Digital Sensors: A 2024 study used wearable data (heart rate, activity, sleep) to estimate digital analogs of central and peripheral circadian rhythms. The study found that misalignment between the central oscillator and sleep midpoint was significantly associated with worse next-day mood in a large cohort of medical interns [10].
• Non-Invasive Biosensors: A 2025 study demonstrated a wearable sensor that continuously measures cortisol and melatonin from passive perspiration, showing strong agreement with salivary levels. This technology enables dynamic monitoring of circadian health outside the lab [40].
• Saliva Transcriptomics: Methods like TimeTeller use RNA levels of core clock genes (e.g., ARNTL1, PER2) in saliva to assess the peripheral clock phase. This approach has shown significant correlation between the acrophase of ARNTL1 gene expression and the acrophase of cortisol [39].

Diagram 1: Experimental Workflow for Circadian Phase Assessment. This chart outlines the primary methodologies, from sample collection to key output metrics, used to determine the phase of circadian rhythms.

The Scientist's Toolkit: Essential Research Reagents and Materials

Table 3: Key Research Reagent Solutions for Circadian Rhythm Analysis

Item/Category	Specific Examples & Functions	Application Context
Immunoassays	ELISA, RIA Kits: For quantifying hormone (melatonin, cortisol) concentrations in plasma, saliva, or urine [34] [35].	Standard hormone level determination; RIA used in polar research [35].
LC-MS/MS	Liquid Chromatography-Tandem Mass Spectrometry: High-sensitivity and specificity detection of melatonin and cortisol, considered superior to immunoassays [34].	Gold-standard analytical confirmation; preferred for high-precision requirements.
Saliva Collection Kits	Salivettes, RNAprotect: Non-invasive collection of saliva for hormone assays (DLMO) or RNA preservation for transcriptomics [34] [39].	Ambulatory and at-home data collection; gene expression rhythm studies.
Portable Biosensors	Wearable sweat sensors with electrochemical detection: Enable continuous, dynamic monitoring of cortisol and melatonin [40].	Real-world, longitudinal circadian health monitoring.
Activity/Rhythm Monitors	Wrist Actigraphy (e.g., Fitbit, PMS-8 Recorder): Objective tracking of sleep-wake cycles and activity rhythms for phase angle calculation [36] [10].	Verifying subject compliance; estimating sleep midpoint.
Controlled Environment Supplies	Dim red light (<10-15 lux), constant routine equipment (e.g., specialized chairs, hourly snack provisions).	Essential for unmasking endogenous rhythms in lab studies (DLMO, CR) [36] [34].

Implications for Research and Chronotherapy

Understanding the interrelationships and relative accuracy of these markers is crucial for advancing circadian medicine.

• Chrono-Therapeutics: The timing of drug administration based on circadian rhythms can optimize efficacy and minimize side effects. Accurate phase assessment is the foundation of this approach [20] [39].
• Mental Health: Real-world digital studies have demonstrated a bidirectional link between circadian disruption (misalignment between estimated central pacemaker and sleep) and mood, highlighting the clinical relevance of these markers [10].
• Future Directions: The field is moving towards high-dimensional "omics" approaches and machine learning to extract circadian information from fewer samples, making personalized chronotherapy more feasible [20] [39].

Melatonin, core body temperature, and cortisol provide complementary yet distinct windows into the functioning of the human circadian system. Melatonin rhythm, particularly the DLMO, stands as the most precise and reliable marker of central circadian phase. Cortisol provides critical information about the HPA axis and the morning wake-up signal, while CBT remains a valuable, though more variable, marker when measured under controlled conditions. The choice of marker(s) depends on the specific research question, required precision, logistical constraints, and available resources. As technology advances, the integration of traditional biochemical markers with novel digital and molecular tools promises to deepen our understanding of circadian physiology and unlock the full potential of chronotherapy in clinical practice.

From Lab to Clinic: Methodological Protocols for Circadian Phase Assessment

In the field of chronobiology, accurately assessing an individual's endogenous circadian phase is fundamental to both research and clinical applications. The central circadian pacemaker in the suprachiasmatic nucleus (SCN) governs daily rhythms in physiology and behavior, but its output is often masked by external influences such as light exposure, sleep-wake cycles, and feeding patterns [41]. To address this challenge, researchers have developed specialized laboratory protocols that control for these confounding factors, allowing for the precise measurement of the underlying circadian rhythm. The Constant Routine (CR) and Forced Desynchrony (FD) protocols represent the gold standard methodologies in human circadian research, providing the benchmark against which all other circadian assessment tools are validated [41] [42]. These protocols enable the measurement of key circadian phase markers such as dim light melatonin onset (DLMO) and the core body temperature minimum, which are considered the most reliable indicators of central circadian timing [12] [42] [43]. Understanding the comparative strengths, applications, and methodological details of these approaches is essential for researchers, scientists, and drug development professionals working in circadian biology.

The Constant Routine and Forced Desynchrony protocols share the common goal of unmasking endogenous circadian rhythms, but they employ fundamentally different strategies to achieve this objective.

The Constant Routine protocol is designed to distribute potential masking factors evenly across the circadian cycle by maintaining participants in a state of prolonged wakefulness under constant environmental conditions [41]. During a CR protocol, subjects are kept in constant conditions for at least 24 hours, including constant dim light, constant temperature, and constant semi-recumbent posture. Food intake is evenly distributed throughout the protocol, and subjects are typically not allowed to sleep for the duration [41]. This method "unmasks" the endogenous rhythm by removing the influence of behavioral and environmental cycles.

In contrast, the Forced Desynchrony protocol separates the endogenous circadian rhythm from the imposed rest-activity cycle by scheduling sleep-wake cycles to a period significantly different from 24 hours (typically 20 or 28 hours) [44]. In an FD study on rats, researchers subjected 8 animals to a 20-hour forced activity cycle consisting of 10 hours of forced wakefulness and 10 hours for rest and sleep, which differed from their endogenous circadian rhythm (about 24 hours) [44]. This approach allows researchers to examine the endogenous circadian component independent of the masking effects of the sleep-wake cycle.

Table: Core Characteristics of Gold Standard Circadian Protocols

Feature	Constant Routine	Forced Desynchrony
Primary Objective	Remove masking effects by distributing them evenly	Separate circadian and homeostatic processes
Duration	Typically 24-50 hours	Extends over multiple days (often 1-3 weeks)
Environmental Controls	Constant dim light, temperature, posture	Controlled light-dark cycles matching imposed schedule
Sleep-Wake Schedule	Total sleep deprivation	Imposed non-24-hour sleep-wake cycle
Key Measured Outputs	DLMO, core body temperature rhythm	Phase relationship between circadian rhythms and imposed cycle
Primary Applications	Characterizing endogenous circadian phase	Studying interaction between circadian and homeostatic systems

Detailed Methodological Breakdown

Constant Routine Protocol Implementation

The Constant Routine protocol requires rigorous environmental control and careful participant management. The protocol is conducted in specially designed laboratory environments where light levels are maintained at constant dim light (typically <10-15 lux) to avoid resetting the circadian pacemaker, and temperature is held constant to prevent thermoregulatory effects on circadian outputs [41]. Participants maintain a semi-recumbent posture throughout the protocol to minimize activity-induced masking, and are kept awake by laboratory staff who continuously monitor their alertness [41].

Nutritional intake is carefully controlled through equicaloric snacks or small meals provided at regular intervals (e.g., hourly), ensuring that metabolic variations do not confound circadian measurements [41]. The protocol typically extends for at least 24 hours, though longer durations (up to 50 hours) are sometimes employed to better characterize the full circadian cycle. Throughout the protocol, physiological variables are sampled frequently – core body temperature via rectal probe or ingestible telemetry pill, salivary melatonin collected every 30-60 minutes for DLMO determination, and other parameters such as cognitive performance, hormone levels (e.g., cortisol), and subjective sleepiness assessed at regular intervals [42].

The CR protocol has been instrumental in characterizing the endogenous components of diurnal rhythms of melatonin, core body temperature, thyroid stimulating hormone (TSH), glucose tolerance, heart rate, and cognitive performance [41]. For core body temperature specifically, the curve recorded under constant conditions serves as one of the gold standard methods to quantify circadian phase, with the rhythm typically showing an amplitude of 0.8°C to 1.0°C between maximum during the active period and minimum during the inactive period [42].

Forced Desynchrony Protocol Implementation

The Forced Desynchrony protocol imposes a sleep-wake cycle that differs substantially from 24 hours (usually 20 or 28 hours), effectively "desynchronizing" the endogenous circadian pacemaker from the behavioral cycle [44]. This approach relies on the fact that the human circadian system cannot entrain to such extreme cycles, allowing researchers to assess circadian parameters across all phases of the circadian cycle. The protocol is conducted in carefully controlled environments where light-dark cycles are matched to the imposed schedule, with light levels during wake periods typically maintained at low intensity (∼10-20 lux) to minimize masking effects on the circadian pacemaker.

During an FD protocol, participants live on the non-24-hour schedule for multiple cycles (often 1-3 weeks), with sleep episodes scheduled according to the imposed rhythm [44]. The forced desynchrony approach allows researchers to separate the contribution of the endogenous circadian pacemaker from the direct effects of the sleep-wake cycle and behavioral influences. In the rat FD study, researchers found that 68-77% of the variation in raw body temperature data could be explained by a summation of estimated endogenous circadian cycle and forced activity cycle components [44].

Measurements collected throughout the protocol include core body temperature, melatonin levels, hormonal profiles, cognitive performance metrics, and other physiological parameters. The extended duration allows for comprehensive assessment of circadian phase and amplitude, as well as the interaction between circadian and homeostatic processes regulating sleep, alertness, and performance.

Diagram: Forced Desynchrony separates endogenous circadian rhythms from imposed behavioral cycles.

Quantitative Comparison of Protocol Outputs

The comparative performance of Constant Routine and Forced Desynchrony protocols can be evaluated through their accuracy in measuring key circadian parameters, their reliability across different populations, and their methodological constraints.

Table: Performance Metrics of Gold Standard Circadian Protocols

Performance Metric	Constant Routine	Forced Desynchrony
Phase Estimation Accuracy	High (DLMO ± 30 min)	High (Comprehensive phase-response)
Amplitude Assessment	Direct measurement under constant conditions	Separated from masking effects
Protocol Duration	Shorter (24-50 hours)	Longer (1-3 weeks)
Participant Burden	High (sleep deprivation)	Very high (extended confinement)
Resource Intensity	High (staffing, lab resources)	Very high (extended staffing, resources)
Sample Throughput	Moderate	Low
Masking Control	Excellent for most outputs	Comprehensive for circadian & homeostatic

Research comparing these methodologies demonstrates that each approach offers distinct advantages depending on the research question. The Constant Routine protocol provides exceptional accuracy for determining circadian phase markers such as DLMO, which remains the gold standard phase marker in human circadian research [43]. Studies have shown that the core body temperature rhythm measured under constant routine conditions serves as a validated output of the central clock, with the time of temperature minimum providing a reliable phase marker [42].

The Forced Desynchrony protocol offers unique insights into the interaction between circadian and homeostatic processes. In the rat FD study, researchers were able to demonstrate that free-running circadian periods of body temperature during FD were similar to free-running periods measured in constant conditions, suggesting that the applied forced activity cycle did not substantially alter the intrinsic period of the circadian pacemaker [44]. This protocol is particularly valuable for constructing phase-response curves to light and other stimuli, and for understanding how circadian rhythms interact with sleep homeostasis to regulate cognitive performance and alertness.

Experimental Applications and Validation Data

Protocol Validation and Cross-Comparison

The validity of both Constant Routine and Forced Desynchrony protocols is well-established in circadian literature, with each method providing critical validation for the other. The Constant Routine protocol has been extensively validated through its ability to consistently characterize endogenous circadian rhythms across multiple physiological systems. Research has confirmed that the core body temperature curve recorded under constant conditions serves as one of the gold standard methods to quantify or demonstrate circadian phase, correlating closely with other established markers such as DLMO [42].

The Forced Desynchrony protocol has been validated through its consistent findings across species and laboratories. In the rat FD study, researchers demonstrated that the protocol successfully introduced a 10-hour sleep/10-hour wake cycle that differed from the endogenous circadian rhythm, with the forced activity cycle reducing clock-related circadian modulation of activity [44]. Importantly, this reduction of circadian modulation did not significantly affect body temperature rhythms, suggesting that the core circadian pacemaker remained relatively unaffected by the imposed behavioral cycle.

Applications in Circadian Research and Drug Development

Both protocols have proven invaluable in advancing our understanding of human circadian biology and have direct applications in drug development and precision medicine:

• Phase-Response Curve Development: FD protocols have been essential in establishing phase-response curves for light, melatonin, and other chronobiotics, informing timing strategies for light therapy and drug administration [12].

• Chronotherapy Optimization: CR protocols provide precise individual phase assessment critical for timing drug administration to align with optimal circadian windows of drug metabolism and efficacy [12].

• Shift Work Research: Both protocols have revealed the profound circadian disruption experienced by shift workers, with studies showing significant internal desynchrony between central and peripheral rhythms [12] [10].

• Mental Health Applications: Recent research utilizing digital analogs of these protocols has demonstrated bidirectional links between circadian disruption and mood, with circadian markers showing predictive value for depression risk assessment [10].

The translation of these laboratory gold standards to real-world applications is advancing rapidly with the development of wearable technology and mathematical modeling. Recent studies have shown that activity data from consumer wearables can predict DLMO with accuracy approaching laboratory methods (within ~1 hour in normal conditions) [12] [43]. However, these digital approaches continue to use CR and FD protocols as their validation benchmark, emphasizing the enduring importance of these laboratory gold standards.

Essential Research Reagents and Materials

Implementing gold standard circadian protocols requires specialized materials and equipment to ensure proper environmental control and physiological monitoring.

Table: Essential Research Reagents for Gold Standard Circadian Protocols

Item	Function	Protocol Application
Dim Light Setup	Maintains constant illumination <10-15 lux to avoid circadian phase shifts	Critical for both CR and FD
Temperature Probes	Measures core body temperature continuously via rectal or ingestible sensors	Essential for both protocols
Salivary Melatonin Collection	Determines DLMO through regular sampling and immunoassay	Primary outcome for both protocols
Controlled Climate Chamber	Maintains constant ambient temperature and humidity	Required for laboratory implementation
Activity Monitoring	Records motor activity via actigraphy or wearable devices	Used in FD for schedule compliance
Standardized Nutritional Supplements	Provides equicaloric nutrition at scheduled intervals	Critical for CR protocol
Cognitive Test Batteries	Assesses circadian variation in performance	Applied in both protocols
Hormonal Assay Kits	Measures cortisol, TSH, and other hormone rhythms	Secondary outcomes in both protocols

The selection and proper implementation of these research reagents is critical to protocol success. For example, the dim light conditions must be rigorously maintained throughout both protocols, as even brief exposure to brighter light can cause phase shifts that compromise data integrity [41]. Melatonin assessment requires careful timing and handling procedures, with samples typically collected every 30-60 minutes during critical phase-assessment periods [43]. The controlled environment of the laboratory is essential, with dedicated climate-controlled chambers necessary to maintain constant temperature and humidity throughout the protocol duration [41].

Diagram: Constant Routine protocol uses environmental constancy to unmask endogenous rhythms.

The Constant Routine and Forced Desynchrony protocols represent complementary gold standard approaches for assessing circadian phase in human research. While the Constant Routine excels at providing precise phase estimates of the central circadian pacemaker by distributing masking factors evenly across the cycle, the Forced Desynchrony protocol offers unique insights into the interaction between circadian and homeostatic processes by separating these systems through imposed non-24-hour cycles. Both methodologies have been rigorously validated and continue to serve as critical benchmarks against which emerging technologies such wearable-based circadian assessment are measured [12] [43].

The choice between these protocols depends heavily on the specific research question, with CR protocols offering greater efficiency for phase assessment and FD protocols providing more comprehensive characterization of circadian system dynamics. As circadian medicine advances toward real-world applications, including chronotherapy and mental health interventions, the fundamental insights gained from these laboratory gold standards continue to inform the development of scalable assessment tools and timing-based treatments [10]. Despite the emergence of sophisticated mathematical models and wearable technology, these rigorous laboratory protocols remain essential for validating new methods and advancing our understanding of human circadian biology.

Dim Light Melatonin Onset (DLMO) is the gold standard biomarker for assessing the phase of the human circadian clock [39] [19]. It represents the time in the evening when endogenous melatonin secretion begins to rise, signaling the onset of the biological night [45]. The accurate measurement of DLMO is crucial for both research and clinical practice, particularly in diagnosing circadian rhythm sleep-wake disorders, optimizing chronotherapy in drug development, and understanding the impact of circadian disruption on health outcomes [46] [19]. This guide provides a comparative analysis of the practical aspects of DLMO measurement, focusing on sampling protocols across different biological matrices and the methodological approaches for determining the onset time. The objective is to equip researchers and drug development professionals with the necessary information to select and implement the most appropriate DLMO assessment strategy for their specific applications.

Sampling Matrices and Protocol Design

The choice of biological matrix for melatonin collection is a critical decision that impacts participant burden, logistical complexity, and analytical performance. The three primary matrices used are saliva, blood, and urine, each with distinct advantages and limitations.

Table 1: Comparison of Biological Matrices for DLMO Assessment

Matrix	Sampling Protocol	Key Advantages	Key Limitations	Primary Use Context
Saliva	5-8 hours prior to & after habitual bedtime [45] [19]. Hourly or half-hourly sampling [45].	Non-invasive, suitable for home/remote collection [45] [22]. High participant compliance [45]. Salivary levels correlate well with plasma levels [45].	Lower hormone concentration, requiring highly sensitive assays [19]. Potential for contamination from food or drink.	Current Gold Standard for remote and clinic-based research; growing in clinical diagnostics.
Blood (Plasma/Serum)	Serial blood draws in a clinic/lab, similar timing window to saliva.	Higher analyte concentration, potentially better assay reliability [19]. Considered the historical reference standard.	Highly invasive, requires a clinical setting and cannulation [45]. Disrupts normal sleep and behavior.	Primarily in tightly controlled laboratory studies.
Urine	Less standardized; typically involves collecting total urine over intervals (e.g., every 3-4 hours) or first-morning urine.	Non-invasive. Can provide an integrated measure of melatonin metabolites (e.g., 6-sulfatoxymelatonin).	Lower temporal resolution, making precise DLMO determination difficult.	Epidemiological and large-scale population studies where precise phase is less critical.

Saliva has emerged as the dominant matrix in modern research due to its non-invasive nature, which allows for collections in ecologically valid, free-living environments [22]. A typical salivary DLMO protocol involves collecting samples under dim light conditions, usually starting 5 hours before and continuing until 1 hour after an individual's habitual bedtime [45] [19]. Samples can be collected hourly, though half-hourly sampling provides higher precision for calculating the onset time [45]. Crucially, this can be implemented remotely using at-home kits that include salivettes, a light meter to verify dim light conditions (<10–50 lux), blue light-blocking glasses, and temperature sensors for monitoring sample integrity during storage and transport [22].

Experimental Protocols for Salivary DLMO

The following provides a detailed methodology for a self-directed, remote salivary DLMO collection protocol, as validated in recent studies.

Materials and Reagents

• Saliva Collection Device: Untreated Salivettes or similar passive drool kits [22].
• Light Meter: To ensure ambient light remains in dim conditions (e.g., <50 lux, ideally <10 lux) throughout the collection period [22].
• Blue Light-Blocking Glasses: To be worn if screen use is necessary during collection [22].
• Timer and MEMs Cap: A Medication Event Monitoring System (MEMs) cap or simple timer to record the exact timing of each sample [22].
• Cold Chain Supplies: Freezer bags, pre-frozen ice packs, and a -20°C freezer for sample storage immediately after collection and until shipment [22].
• Shipping Materials: Pre-paid shipping label and insulated container for return to the analytical laboratory.

Sample Collection Procedure

• Participant Preparation and Scheduling: Participants are instructed to avoid certain substances for 24 hours prior to collection, including alcohol, caffeine, and nicotine. They should also avoid non-steroidal anti-inflammatory drugs (NSAIDs) and beta-blockers, which can suppress melatonin, as well as melatonin supplements, which can artificially elevate levels [19]. The collection is scheduled on a typical night, avoiding the day after a night of shift work or significant sleep loss.
• Dim Light Conditions: Participants should enter dim light conditions at least one hour before the first sample is collected and maintain them until the protocol is complete. They should use the light meter to verify the light levels.
• Sample Collection Timeline: Collection begins 5-6 hours before habitual bedtime and continues until 1-2 hours after bedtime. For example, for a bedtime of 23:00, sampling would run from 18:00 to 01:00 [45] [22].
• Sampling Frequency: Samples are collected every 30-60 minutes. Half-hourly sampling provides higher precision for onset calculation but increases cost and participant burden [45].
• Sample Handling: Immediately after collection, samples are stored in the participant's home freezer (-20°C). All samples are shipped with ice packs to the analytical laboratory via overnight courier for analysis.

Analytical Methods

Two primary analytical platforms are used for quantifying salivary melatonin:

• Immunoassays (ELISA): These are widely used and do not require sample extraction. The Salimetrics Melatonin Assay is a common competitive ELISA with a reported sensitivity of 1.35 pg/mL and a run time of 3.5 hours [45].
• Liquid Chromatography-Tandem Mass Spectrometry (LC-MS/MS): This method is increasingly regarded as the superior technique due to its higher specificity, sensitivity, and reproducibility. It effectively avoids the cross-reactivity issues that can plague immunoassays, which is critical for accurately measuring low concentrations of salivary melatonin [34] [19].

Data Analysis: Fixed vs. Variable Threshold Methods

Once melatonin concentrations are obtained, DLMO is determined by identifying the time at which levels consistently rise above a baseline. The two most common methods for this are the fixed threshold and the variable threshold.

Table 2: Comparison of DLMO Analysis Methods

Method	Definition	Calculation	Pros	Cons
Fixed Threshold	Time when melatonin concentration crosses a pre-defined absolute value.	A common threshold is 3 pg/mL or 4 pg/mL for saliva [45] [19].	Simple, straightforward to implement and compare across studies.	Can miss DLMO in low melatonin producers (e.g., elderly) whose levels may never reach the threshold [45] [19].
Variable Threshold (3k Method)	Time when melatonin crosses a threshold based on an individual's own baseline.	Threshold = Mean of first 3 low daytime samples + 2 Standard Deviations [45].	Accounts for individual differences in baseline secretion and amplitude; suitable for low producers.	Requires stable baseline samples; can be unreliable if fewer than 3 baseline samples are available [19].
Hockey-Stick Algorithm	An objective, automated method that models the point of change from baseline to exponential rise.	Fits a two-segment regression model to identify the breakpoint in the data series [19].	Automated, reduces subjective bias; shows strong agreement with expert visual inspection.	Requires computational implementation; may be less intuitive than threshold methods.

The choice of analysis method can significantly impact the calculated DLMO time. A study comparing the variable threshold to a fixed 3 pg/mL threshold found that the variable method produced DLMO estimates that were 22–24 minutes earlier in 76% of cases, which was often closer to the physiological onset [19]. Salimetrics, a provider of assay kits, recommends the variable threshold method for its ability to handle low secretors [45]. Conversely, some researchers favor the fixed threshold, arguing that the variable method can produce inaccurate phase estimates if the baseline is unstable or the calculated threshold falls below the assay's limit of detection [19]. The "hockey-stick" algorithm offers a promising, more objective alternative that demonstrates strong agreement with visual assessments by experts [19].

Research Reagent Solutions

The following table details key materials and reagents essential for implementing a salivary DLMO study.

Table 3: Essential Research Reagents and Materials for Salivary DLMO

Item	Function/Description	Example Specifications/Notes
Salivette	Device for collecting passive drool saliva samples.	Untreated (cotton-free) is preferred for melatonin to avoid interference [22].
Melatonin Assay Kit	For quantifying melatonin concentration in saliva.	ELISA (e.g., Salimetrics): Sensitivity <1.5 pg/mL, no extraction needed [45]. LC-MS/MS: Higher specificity and sensitivity; gold-standard for accuracy [19].
Light Meter	To verify dim light conditions (<10-50 lux) are maintained.	Critical for protocol validity; light is the primary zeitgeber that suppresses melatonin [22].
MEMs Cap	Electronic bottle cap that records the date and time of each sample opening.	Provides objective compliance data in remote studies [22].
Cold Chain Kit	For stable storage and transport of samples.	Includes freezer bags, ice packs, and insulated shipping container to maintain -20°C.

Workflow and Pathway Diagrams

The following diagram illustrates the end-to-end workflow for a remote salivary DLMO study, from participant preparation to data analysis.

Remote DLMO Assessment Workflow

The molecular pathway of melatonin production and its relationship to the core circadian clock is fundamental to interpreting DLMO. The following diagram outlines this regulation.

Melatonin Regulation by Circadian Clock

The practical measurement of DLMO has evolved significantly, with salivary sampling coupled with sensitive analytical techniques like LC-MS/MS establishing itself as the most feasible and robust method for both research and emerging clinical applications. The choice between sampling matrices involves a trade-off between precision and practicality, while the selection of an analysis method (fixed vs. variable threshold) requires consideration of the study population's melatonin profile and the need for standardization versus individualization. Remote, self-directed protocols are demonstrating strong feasibility, even in specialized populations, increasing the accessibility of this gold-standard circadian phase marker. For researchers and drug development professionals, this comparative guide provides a foundation for designing rigorous, reproducible DLMO studies that can accurately capture the timing of the internal circadian clock, thereby enhancing the validity of findings in circadian biology and chronotherapy.

Core body temperature (CBT) serves as a critical physiological parameter in clinical medicine and research, particularly as a primary marker for circadian phase assessment. The accurate measurement of CBT is essential for diagnosing circadian rhythm sleep disorders, evaluating the physiological impact of shift work, and investigating the relationship between circadian disruption and metabolic health [47] [48] [49]. Monitoring techniques can be broadly categorized into invasive methods, which measure temperature directly at core body sites, and non-invasive methods, which estimate CBT from peripheral measurements. The choice between these approaches involves important trade-offs between accuracy, patient comfort, and practicality, especially in ambulatory settings where continuous monitoring is required over extended periods. This guide provides a comprehensive comparison of these techniques, focusing on their performance characteristics and applications in circadian rhythm research.

Core Body Temperature as a Circadian Phase Marker

The human circadian system generates near-24-hour rhythms in physiology and behavior, governed primarily by the suprachiasmatic nucleus (SCN) in the hypothalamus. CBT exhibits a robust circadian rhythm, typically reaching its minimum (CBTtrough) during the late night or early morning and peaking in the late afternoon or evening [47] [49]. This rhythm is considered a reliable output of the central circadian pacemaker, making the precise assessment of CBTtrough a valuable marker for determining internal circadian timing [47] [48].

The relationship between central circadian regulation and peripheral rhythms is a subject of intensive research. Evidence indicates that individuals with higher CBT amplitude exhibit greater rhythmicity in blood plasma metabolites, suggesting that robust central circadian timing promotes synchronization throughout the body's systems [49]. This interconnection underscores the importance of accurate CBT measurement not only for assessing central circadian phase but also for understanding its downstream effects on peripheral physiology.

Invasive CBT Monitoring Techniques

Methodologies and Technical Specifications

Invasive CBT monitoring techniques involve placing sensors directly in body sites that closely reflect the temperature of core organs and blood.

Rectal Temperature Measurement: Considered a gold standard in research settings, rectal probes are typically inserted 10-15 cm beyond the anal sphincter to ensure reliable measurement [47]. This method provides continuous data collection with minimal lag in detecting core temperature changes. In circadian rhythm studies, measurements are typically recorded at 1-minute intervals and averaged over 10-minute periods for analysis [47].

Ingestible Telemetric Pills: These capsule-shaped sensors are swallowed and transmit temperature data as they travel through the gastrointestinal tract. They are particularly valuable for field studies and situations where rectal probes are impractical. In constant routine protocols—the gold standard for unmasking endogenous circadian rhythms—ingestible pills have been used to collect CBT data over 40-hour periods under controlled conditions [49].

Intravascular Temperature Sensing: This hospital-based approach involves temperature sensors integrated into vascular catheters, typically placed in the pulmonary artery (via pulmonary artery catheters) or peripheral arteries. It is considered the clinical gold standard for core temperature measurement in intensive care settings [50].

Accuracy and Performance Data

Systematic reviews and meta-analyses have quantified the accuracy of invasive methods relative to intravascular temperature measurement (the reference standard) in clinical populations:

Table 1: Accuracy of Invasive CBT Monitoring Methods Compared to Intravascular Measurement

Measurement Method	Number of Studies	Pooled Mean Bias (°C)	Pooled 95% Limits of Agreement (°C)
Oesophageal	3	0.06 (-0.07 to 0.18)	-0.39 to 0.51
Rectal	3	-0.05 (-0.21 to 0.10)	-0.51 to 0.41
Urinary Bladder	5	-0.06 (-0.16 to 0.05)	-0.80 to 0.68

Source: Systematic review and meta-analysis of 13 studies (632 patients, 105,375 measurements) [50]

Non-Invasive CBT Monitoring Techniques

Methodologies and Technical Specifications

Non-invasive techniques estimate CBT through sensors placed on external body surfaces, using various physiological parameters and algorithmic approaches.

Patch-Type Wearable Sensors: Devices such as the CALERA Research sensor incorporate heat flux and skin temperature measurements in a wearable format. These sensors typically attach to the torso approximately 20 cm below the armpit using medical-grade adhesive patches [47]. They employ machine learning algorithms to convert peripheral measurements into CBT estimates, transmitting data wirelessly to cloud platforms for analysis [47] [24].

Tympanic Infrared Thermometry: This approach uses infrared sensors to measure thermal radiation from the tympanic membrane, which shares blood supply with the hypothalamus. Measurements are rapid but provide only intermittent data points.

Zero Heat Flux Technology: This method uses specially designed probes that create a thermal insulator over the skin surface, effectively creating a closed environment where skin temperature equilibrates with core temperature.

Accuracy and Performance Data

Recent validation studies have quantified the performance of non-invasive methods against invasive reference standards:

Table 2: Accuracy of Non-Invasive CBT Monitoring Methods

Measurement Method	Reference Standard	Mean Bias	95% Limits of Agreement	Study Context
CALERA Sensor	Rectal Probe	0.16 hours (circadian phase)	-0.76 to 1.07 hours	Circadian phase assessment in real-world setting [47]
CALERA Sensor	Gastrointestinal Pill	-0.01°C	±0.36°C	Cycling exercise in heat [24]
CALERA Sensor	Tympanic Measurement	0.11°C	±0.34°C	Acute stroke patients [24]
Axillary	Intravascular	-0.25°C*	-1.03 to 0.53°C*	ICU patients [50]
Tympanic Infrared	Intravascular	-0.33°C*	-1.27 to 0.61°C*	ICU patients [50]
Zero Heat Flux	Intravascular	-0.02°C*	-0.54 to 0.50°C*	ICU patients [50]

Note: Values marked with * are derived from a systematic review and meta-analysis of ICU patients [50]

Comparative Analysis of Methodologies

Direct Comparison of Accuracy and Precision

When directly compared against intravascular temperature measurement (the clinical gold standard), systematic review evidence demonstrates that most non-invasive peripheral thermometers have poor accuracy and wide limits of agreement, making them unreliable for critical care applications where precise temperature measurement is essential [50]. Only oesophageal measurements showed clinically acceptable accuracy (mean bias 0.06°C) in this setting [50].

However, in ambulatory settings for circadian rhythm assessment, newer wearable technologies show more promising results. The CALERA sensor demonstrated excellent reliability (ICC = 0.96) and substantial agreement (CCC = 0.96) with rectal probes for determining the circadian phase of CBT (CBTtrough), with a mean bias of just 0.16 hours in determining the timing of the temperature minimum [47].

Experimental Protocols for Validation

Circadian Rhythm Validation Protocol: One recent validation study involved 16 participants (8 males, 8 females) aged 19-45 years who wore both the CALERA sensor on the chest and a rectal probe for 3-5 days in real-world settings [47]. Wrist actigraphy simultaneously recorded sleep-wake patterns. The CBTtrough was defined as the midpoint of the nocturnal decrease in CBT, identified using a geometric method where a line at the middle level between the temperature at the point more than 0.2°C higher from the minimum values crossed the descending and ascending parts of the temperature rhythm [47].

Sleep Research Protocol: Another comparative study involved 14 subjects undergoing simultaneous invasive (ingestible capsule) and non-invasive (GreenTeg patch) CBT measurements during sleep [51]. Measurements were compared based on correlation, consistency, difference, and stability. Results showed significant correlation between methods, which strengthened at lower ambient temperatures. However, the non-invasive instrument exhibited substantial error during unstable core temperature periods, though errors were smaller during stable temperature periods [51].

Method-Specific Advantages and Limitations

Table 3: Comparative Analysis of CBT Monitoring Techniques

Method	Advantages	Limitations	Optimal Use Cases
Rectal Probe	High accuracy; Continuous data; Gold standard for circadian research	Discomfort; Practical limitations; Sleep disruption	Laboratory-based circadian rhythm studies
Ingestible Pills	Good accuracy; Suitable for field studies; Minimal interference with sleep	Single-use cost; Gastrointestinal transit limitations	Constant routine protocols; Field studies with continuous monitoring
Intravascular	Highest clinical accuracy; Continuous measurement	Highly invasive; Infection risk; ICU setting only	Critical care medicine
Patch-Type Wearables	Good patient comfort; Continuous data; Suitable for long-term monitoring	Lower accuracy during unstable temperatures; Algorithm dependency	Ambulatory circadian monitoring; Sleep studies
Tympanic Infrared	Rapid measurement; Non-invasive	Intermittent data only; Technique sensitivity	Spot checks in clinical settings

Technical and Methodological Considerations

Impact of Measurement Site on Circadian Phase Assessment

Different measurement techniques exhibit varying relationships with the true core temperature due to physiological and technical factors. In circadian research, the timing of CBTtrough (rather than absolute temperature values) serves as the primary phase marker. While absolute temperature differences exist between measurement sites, the timing of the temperature minimum remains relatively consistent across methods that accurately track core temperature trends [47].

Signal Processing and Demasking Algorithms

Raw CBT data contains both endogenous circadian signals and non-circadian "masking" effects from sleep, activity, and environmental factors. Advanced analytical approaches are required to separate these influences. Recent research has developed physiology-grounded generalized additive models that outperform traditional cosine-model fits for estimating circadian timing from CBT data [48]. These improved methods better account for substantial masking of circadian effects, reducing sleep-related biases in circadian phase estimation [48].

Factors Influencing Measurement Accuracy

Several physiological and technical factors affect the reliability of both invasive and non-invasive CBT measurements:

• Body Composition: Body fat rate significantly affects the reliability of non-invasive CBT measurements due to the insulating properties of adipose tissue [51].
• Environmental Conditions: The correlation between invasive and non-invasive measurements improves in lower ambient temperatures [51].
• Device Calibration: Individual calibration of sensors for heat flux and skin temperature measurements is essential for optimal accuracy in non-invasive devices [24].
• Physiological State: Non-invasive instruments exhibit greater error during periods of unstable core temperature compared to stable conditions [51].

The Scientist's Toolkit: Essential Research Reagent Solutions

Table 4: Key Research Materials and Solutions for CBT Monitoring Studies

Item	Function/Application	Specification Notes
CALERA Research Sensor	Non-invasive CBT estimation via heat flux and skin temperature	Machine learning algorithm; Wireless data transmission; Medical-grade adhesive patches [47] [24]
Rectal Temperature Probe	Invasive CBT measurement reference standard	15cm insertion depth; 1-minute sampling capability; Flexible wired design [47]
Ingestible Telemetric Pills	Gastrointestinal CBT monitoring	Single-use; Wireless data transmission; 24-36 hour battery life [49]
Wrist Actigraph	Simultaneous sleep-wake cycle monitoring	Cole-Kripke algorithm for sleep scoring; 1-minute epoch data [47]
Data Analysis Software	Circadian phase analysis and demasking	Custom algorithms for CBTtrough identification; Generalized additive models for demasking [47] [48]

The selection between invasive and non-invasive CBT monitoring techniques involves careful consideration of research objectives, measurement context, and precision requirements. Invasive methods, particularly rectal probes and ingestible pills, remain the gold standard for laboratory-based circadian research where maximal accuracy is essential. However, recent advances in non-invasive wearable technologies show promising results for ambulatory monitoring, with performance characteristics that may be sufficient for many research applications, particularly those focused on circadian phase assessment rather than absolute temperature values.

The growing validation evidence for devices like the CALERA sensor suggests that non-invasive methods can provide reasonable estimates of circadian phase while offering substantial advantages in patient comfort, practicality, and applicability to real-world settings. Researchers should match method selection to their specific precision requirements, with invasive methods preferred for high-acuity applications and non-invasive methods offering a viable alternative for longitudinal ambulatory studies where traditional methods are impractical.

CBT Method Selection Workflow: This diagram illustrates the decision-making process for selecting appropriate core body temperature monitoring methods based on accuracy requirements, study context, and monitoring duration.

Accurately estimating an individual's circadian phase is fundamental to understanding health, disease, and therapeutic efficacy. The long-standing gold standard, Dim Light Melatonin Onset (DLMO), requires frequent biological sampling under controlled dim-light conditions, making it impractical for large-scale or real-world studies [52] [53]. The emergence of wearable technology provides a compelling alternative, enabling continuous, unobtrusive monitoring of physiological parameters like activity, heart rate, and skin temperature in naturalistic settings. This guide objectively compares the performance of these digital proxies, framing them within the critical research aim of identifying accurate, scalable circadian phase markers for scientific and clinical application.

Comparative Accuracy of Digital Circadian Phase Proxies

The following table summarizes the performance of different wearable-derived data modalities in estimating circadian phase, primarily against the gold standard of DLMO.

Table 1: Comparative Accuracy of Wearable Data Modalities for Circadian Phase Estimation

Data Modality	Study Population	Validation Method	Key Performance Metrics	Supporting Evidence
Activity + Light (Actigraphy)	45 fixed night shift workers [52]	In-lab DLMO	Lin's concordance: 0.70; Absolute mean error: 2.88 hours; 76% predictions within 2 hours, 91% within 4 hours of DLMO [52]	First validation in a shift-work population with extreme circadian disruption.
Heart Rate + Activity	>900 medical interns (shift workers) [54]	Constant routine protocol (historical comparison)	Circadian phase and amplitude closely matched constant routine studies [54].	Enables creation of personalized Phase Response Curves (PRCs) from ambulatory data [54].
Skin Temperature, Activity, Posture (TAP)	General population (home-based settings) [55]	DLMO (at-home collection)	Validated for DLMO estimation in self-directed, home-based settings [55].	Multi-sensor approach (Fibion Krono) specifically designed for circadian monitoring [55].
Activity-Derived Rest-Activity Rhythms	76,026 UK Biobank participants [56]	Mortality & Morbidity (Predictive Validity)	"CosinorAge" (from 7-day accelerometry) associated with 8-12% increased all-cause mortality risk per year of advanced biological aging [56].	A scalable digital biomarker of aging and healthspan, linking circadian rhythm strength to hard clinical endpoints [56].

Detailed Experimental Protocols and Methodologies

Actigraphy-Based DLMO Prediction in Shift Workers

Objective: To test the feasibility and accuracy of predicting DLMO using wrist actigraphy and photometry data in fixed night shift workers, a population with severe circadian disruption [52].

Protocol:

• Participants: 45 fixed night shift workers [52].
• Actigraphy Monitoring: Participants wore a wrist actigraph for an average of 17.0 (±10.3) days before DLMO assessment. The device collected continuous data on movement and ambient light exposure [52].
• Gold-Standard Phase Assessment: Participants subsequently underwent a 24-hour laboratory stay in dim light (<10 lux). Saliva samples were collected hourly for 24 hours to measure melatonin concentration and determine the precise clock time of DLMO [52].
• Modeling & Analysis: Actigraphy-recorded light and activity data served as input to a published mathematical model of the human circadian clock. The model-generated phase predictions were then compared to the measured in-lab DLMO to determine agreement [52].

Circadian Rhythm of Heart Rate (CRHR) Assessment

Objective: To investigate if circadian rhythms of heart rate can be accurately tracked using ambulatory wearable data in the demanding real-world environment of medical interns working rotating shifts [54].

Protocol:

• Data Collection: Researchers analyzed over 130,000 days of wearable heart rate and activity data from more than 900 medical interns [54].
• Statistical Modeling: A statistical method was developed to extract key parameters: basal heart rate, CRHR amplitude, and circadian phase. The model explicitly accounted for confounding effects on heart rate, such as acute physical activity, meals, posture, and stress [54].
• Validation: The derived phase and amplitude of the CRHR were compared to historical data from highly controlled constant routine laboratory protocols, where they showed close agreement [54].

Multi-Sensor TAP Methodology

Objective: To leverage a combination of Temperature, Activity, and Posture (TAP) data for ambulatory circadian monitoring and DLMO estimation [55].

Protocol:

• Device: Uses a multi-sensor wearable device (e.g., Fibion Krono) equipped with accelerometers, a skin temperature sensor, and a light sensor [55].
• Data Synthesis: The device continuously monitors distal skin temperature fluctuations (a known circadian marker), body movement, and body position. These data streams are integrated to model the underlying circadian phase [55].
• Validation: The TAP method has been validated against DLMO in peer-reviewed studies, including those facilitating home-based DLMO collection, demonstrating its utility for circadian phase estimation outside the laboratory [55].

Visualization of Workflows and Logical Relationships

From Multi-Sensor Data to Phase Estimation

Figure 1: A generalized workflow for deriving circadian phase estimates from multi-sensor wearable data.

Decision Logic for Modality Selection

Figure 2: A decision logic framework for selecting a circadian phase estimation modality based on research objectives and constraints.

The Scientist's Toolkit: Essential Research Reagents & Materials

Table 2: Key Reagents and Solutions for Wearable Circadian Phase Research

Item / Solution	Function / Application	Example Products / Models
Research-Grade Actigraph	Captures high-fidelity movement and light data; allows access to raw data and uses validated, open algorithms [53].	ActiGraph wGT3X-BT, Fibion Krono [55]
Consumer Wearables with PPG/ECG	Provides heart rate, heart rate variability, and derived sleep metrics; useful for large-scale studies but often involves proprietary algorithms [57] [53].	Apple Watch, Fitbit, Garmin [58]
Multi-Sensor Monitoring Device	Integrates sensors for skin temperature, posture, and light, specifically designed for holistic circadian rhythm assessment [55].	Fibion Krono [55]
Phase Estimation Software & Models	Open-source or commercial platforms that process wearable data streams to generate circadian phase and rhythm parameter estimates [52] [56].	www.predictDLMO.com [52], R packages (e.g., for cosinor analysis [59] [56])
Salivary Melatonin Kit	The gold-standard biomarker for validation studies; used for in-lab or at-home collection of samples to determine DLMO [52] [55].	Various commercial immunoassay kits

Discussion and Future Directions

The comparative data indicates a trade-off between ecological validity, precision, and scalability. Actigraphy-based models offer a strong balance, demonstrating good concordance with DLMO even in challenging shift-work populations [52]. Heart rate models provide a physiologically rich signal that accounts for internal and external stressors but require sophisticated modeling to remove non-circadian confounders [54]. Multi-sensor TAP approaches represent a dedicated effort to combine the most robust peripheral circadian signals into a single, validated system [55].

Future development must address critical limitations, including poor algorithm generalizability across diverse populations (e.g., different age groups, physiological conditions like pregnancy) and occupations [54]. Furthermore, the opacity of proprietary algorithms in consumer devices remains a significant barrier to scientific trust and clinical adoption [53]. Ongoing research is leveraging machine learning to fuse these multi-modal data streams, aiming to create more robust and personalized digital circadian biomarkers, not just for phase, but for overall healthspan and biological aging [56].

The ability to accurately estimate an individual's circadian phase is critical for a wide range of applications, from optimizing drug timing in chronotherapy to managing shift work schedules and treating circadian rhythm sleep disorders. Gold-standard measures of circadian phase, such as Dim Light Melatonin Onset (DLMO), are resource-intensive and impractical for continuous tracking. Computational and mathematical models that predict circadian phase using non-invasive, ambulatory data offer a promising alternative. This guide provides a comparative analysis of the current landscape of these models, focusing on their use of light and activity data as primary inputs, and examines their accuracy across different populations and conditions.

Performance Comparison of Circadian Phase Prediction Models

The performance of circadian phase prediction models varies based on their underlying methodology, input data types, and the population being studied. The following tables summarize the comparative accuracy of various models.

Table 1: Overall Model Performance Across Different Conditions

Model Type	Primary Input Data	Population Tested	Prediction Error (vs. DLMO)	Key Strengths
Dynamic Models (e.g., Jewett-Kronauer)	Light exposure [60] [61]	Healthy adults, DSWPD patients, Shift workers [62] [61]	~68 min RMSE in DSWPD; ±1 h in healthy adults [61]	Based on neurophysiology; generalizes across conditions [60]
Statistical/ML Models	Light, sleep timing, demographics [61]	Delayed Sleep-Wake Phase Disorder (DSWPD) patients [61]	~57 min RMSE; 75% within ±1 h [61]	High accuracy in specific clinical populations [61]
Actigraphy-Based Models	Physical activity (Actigraphy) [62] [12]	Healthy adults, Shift workers [62] [12]	Comparable to light-based models in healthy adults; superior in shift workers [62] [12]	Leverages widely available consumer wearables [62]
Consumer Wearable Models	Physical activity (Apple Watch) [62] [12]	Healthy non-shift workers [62] [12]	Within 1 h of DLMO [62] [12]	Scalable to large populations using existing devices [62]

Table 2: Detailed Performance Metrics from Key Studies

Study & Model	Population	Sample Size	Mean Absolute Error (MAE)	Root Mean Square Error (RMSE)	Accuracy within ±1 h
Huang et al. (2021) - Activity-Driven Models [62] [12]	Healthy Adults (Day Workers)	10	Not Reported	Not Reported	Achieved (Similar to light-based models)
Huang et al. (2021) - Activity-Driven Models [62] [12]	Shift Workers	27	Not Reported	Not Reported	Outperformed light-based models
Huang et al. (2021) - Activity-Driven Models [62] [12]	Healthy Adults (Apple Watch)	20	Not Reported	Not Reported	~1 hour
Stone et al. (2021) - Dynamic Model [61]	DSWPD Patients	77 (Test Set)	57 min	68 min	58%
Stone et al. (2021) - Statistical Model [61]	DSWPD Patients	77 (Test Set)	44 min	57 min	75%

Experimental Protocols and Methodologies

Data Collection and Ground Truth Validation

A critical aspect of developing and validating circadian phase prediction models is the rigorous collection of data and its comparison against a gold-standard phase marker.

• Ambulatory Data Recording: In typical study protocols, participants wear a data-logging device on the wrist for a period of 5 to 14 days before laboratory assessment. Research-grade actiwatches (e.g., Actiwatch Spectrum) record light (in lux) and activity counts (from a triaxial accelerometer) in short epochs (e.g., 30-60 seconds) [62] [12]. Studies using consumer devices, such as the Apple Watch, similarly collect activity data, though often with different units and potential data gaps due to battery charging [62] [12].
• Gold-Truth Phase Measurement: The ambulatory monitoring period is followed by an in-laboratory assessment of circadian phase. The most common marker is the Dim Light Melatonin Onset (DLMO). This involves collecting saliva or blood samples every 30-60 minutes under dim light conditions (<10-50 lux), typically starting several hours before habitual bedtime and continuing for a few hours after. DLMO is calculated as the time when melatonin concentration exceeds a predefined threshold, often two standard deviations above the mean of low daytime values [62] [60] [12]. For populations with highly variable sleep timing, like shift workers, a 24-hour urinary assessment of the melatonin metabolite 6-sulphatoxymelatonin (aMT6s) may be used to determine the rhythm's acrophase (peak time) [60].

Model Training and Prediction Workflow

The process of using the collected data for phase prediction involves several steps, which can be visualized in the following workflow.

Workflow Diagram Title: Circadian Phase Prediction Pipeline

The key steps are:

• Data Preprocessing: Raw light and activity data are cleaned to handle missing values (e.g., via interpolation or using the mean of preceding hours) [61]. Data may be aggregated (e.g., taking the maximum light level in 60-minute bins) to reduce noise and computational load [61]. Actigraphy data is often used to estimate sleep and wake times.
• Model Execution: The preprocessed data is fed into a mathematical model.
  • Dynamic Models: These are typically differential equation models (e.g., the Jewett-Kronauer model) that simulate the state of the circadian pacemaker (often represented as a limit-cycle oscillator) over time. Light data is processed through a phase response curve (PRC) that dictates how the clock advances or delays based on the timing and intensity of light exposure [60] [61]. Some models also incorporate a non-photic input driven by the sleep-wake or activity-rest cycle [62] [12].
  • Statistical/Machine Learning Models: These models, including multiple linear regression, establish a direct functional relationship between input features and DLMO. Features can include light exposure during specific phase delay and advance regions of the PRC, habitual sleep timing, and demographic variables [61].
• Validation: The model's predicted DLMO is compared against the measured gold-standard DLMO. Common error metrics include Mean Absolute Error (MAE), Root Mean Square Error (RMSE), and the proportion of predictions falling within ±1 hour of the actual DLMO [61].

Conceptual Framework of Light and Activity Inputs

Understanding how light and activity data serve as inputs to circadian models requires a brief overview of the underlying biological system and how models abstract its key components.

The Circadian Pacemaker and Its Inputs

The central circadian pacemaker, located in the suprachiasmatic nucleus (SCN), is entrained to the 24-hour day primarily by light perceived by the retina. This light information is processed through a well-defined phase response curve (PRC), which describes how light exposure in the early night causes phase delays, and light in the late night causes phase advances [60]. Mathematical models encode this PRC to dynamically adjust the phase and amplitude of the simulated oscillator.

While light is the primary zeitgeber, non-photic stimuli like activity and the sleep-wake cycle also influence circadian timing. The mechanisms are less well-defined than for light, but activity is often used as a proxy for these non-photic effects and for the sleep-wake schedule itself, which is closely related to circadian phase [62] [12]. The following diagram illustrates how these inputs are integrated within a comprehensive model framework.

Diagram Title: Conceptual Model of Circadian Phase Prediction

The Scientist's Toolkit: Essential Research Reagents and Materials

This section details key tools and methodologies employed in circadian phase prediction research.

Table 3: Key Reagents and Tools for Circadian Phase Prediction Research

Tool Category	Specific Examples	Function & Application in Research
Ambulatory Monitors	Actiwatch Spectrum, Actiwatch-L (Philips Respironics) [62] [12]	Research-grade devices for simultaneous, high-resolution recording of light exposure (lux) and physical activity (counts). The gold-standard for model input validation.
Consumer Wearables	Apple Watch, Fitbit [62] [12] [10]	Consumer devices that primarily record activity. Enable large-scale, real-world studies due to widespread use, though often with less control over data quality and availability (e.g., light data).
Biochemical Assay Kits	Salivary Melatonin RIA/ELISA Kits	Used to quantify melatonin concentrations from saliva samples collected in the lab or at home for the determination of DLMO, the gold-standard phase marker [60] [61].
Mathematical Models	Jewett-Kronauer model, Forger et al. model, Hannay et al. model [62] [60] [63]	Dynamical systems models of the human circadian pacemaker. Take light and/or activity data as input and generate a time series of the predicted circadian phase.
Data Processing Tools	Actiware (Philips), Custom scripts in MATLAB, R, or Python [62] [12]	Software for initial data processing, including scoring sleep/wake states from actigraphy, data cleaning, and aggregating raw sensor data into model-ready inputs.

The field of computational circadian phase prediction has matured significantly, offering researchers and clinicians multiple viable approaches. Dynamic models based on the neurophysiology of the circadian system provide a generalizable framework that performs well across healthy and clinical populations. Statistical models can achieve high precision, particularly in specific patient groups like DSWPD, when trained on relevant data. The emergence of activity-based models is particularly noteworthy, as they demonstrate comparable accuracy to light-based models in healthy individuals and even superior performance in shift workers, all while leveraging the vast and growing installed base of consumer wearables. The choice of model and input data should be guided by the target population, the required accuracy, and the practicality of data collection. Future work will likely focus on further personalizing model parameters, improving the quality of light sensing from consumer devices, and validating these tools in broader clinical and occupational settings.

In circadian rhythm research, the precise assessment of an individual's internal biological time is paramount. While gold-standard biomarkers like dim-light melatonin onset (DLMO) provide direct measures of circadian phase, their application in large-scale studies is often constrained by cost, invasiveness, and participant burden [2] [64]. Consequently, researchers frequently rely on indirect proxies, including self-reported chronotype questionnaires and prospectively completed sleep diaries, to estimate circadian timing and disruption. The Morningness-Eveningness Questionnaire (MEQ) and the Munich Chronotype Questionnaire (MCTQ) represent two foundational instruments in this domain, alongside the fundamental practice of maintaining sleep logs [65] [64]. This guide provides a comparative analysis of these tools, evaluating their methodologies, correlation with physiological markers, and respective suitability for different research contexts within circadian science and drug development.

The MEQ and MCTQ approach the concept of chronotype from distinct but complementary angles. The MEQ assesses an individual's inherent subjective preference for the timing of sleep and daily activities [66] [64]. In contrast, the MCTQ infers chronotype from reported behaviors, calculating the midpoint of sleep on free days (MSF) as a primary metric [2] [67]. Sleep diaries, while not a direct measure of chronotype, provide essential, high-resolution data on sleep-wake patterns across multiple days, which is critical for contextualizing questionnaire data and assessing stability or misalignment [2] [64].

The table below summarizes the core characteristics and performance metrics of these tools.

Table 1: Comparative Analysis of Circadian Phase Proxies

Feature	Morningness-Eveningness Questionnaire (MEQ)	Munich Chronotype Questionnaire (MCTQ)	Sleep Diary / Log
Primary Metric	Preference-based score (e.g., "Definitely Morning") [68]	Behavior-based Mid-Sleep on Free Days (MSF) [67]	Self-reported timings: Bed, Sleep Onset, Wake Up, Rise [64]
Domains Captured	Subjective preference for activity timing, alertness, and sleep [65] [64]	Sleep timing, duration, and light exposure on workdays vs. free days; enables Social Jetlag calculation [2] [68]	Sleep onset latency (SOL), wake after sleep onset (WASO), total sleep time (TST), sleep efficiency (SE) [2]
Correlation with Physiological Phase (DLMO)	Modest to strong correlation (r ~ -0.73 with MSF) [67]	Strong correlation with MEQ (r = -0.73 with MSF) [67]	Used to contextualize DLMO measurements; foundational for diagnosing Circadian Rhythm Sleep-Wake Disorders [64]
Key Strength	Measures internal preference, useful for predicting light/melatonin phase response [64]	Quantifies behavioral misalignment (Social Jetlag); highly ecological [68]	Prospective, detailed data on sleep patterns and influencing factors (caffeine, exercise) [2] [64]
Primary Limitation	Based on preference, not actual behavior; potential for recall bias [65]	Less accurate for individuals with irregular work schedules [2]	Does not directly measure circadian phase; requires participant compliance [64]

Experimental Protocols for Validation and Application

Protocol for Validating Questionnaires Against Physiological Markers

A standard protocol for establishing the convergent validity of chronotype questionnaires involves correlating their outputs with the phase of the circadian pacemaker, as measured by DLMO.

• Objective: To determine the strength of the relationship between MEQ/MCTQ scores and the timing of DLMO.
• Population: Typically involves healthy adults, though studies often also include patient populations like those with Delayed Sleep-Wake Phase Disorder (DSWPD) [64].
• Procedures:
  • Questionnaire Administration: Participants complete the MEQ and MCTQ.
  • DLMO Assessment: Participants collect saliva or blood samples in a controlled, dim-light environment (< 10-20 lux) on one or more evenings, typically every 30-60 minutes starting 4-6 hours before habitual sleep time and continuing until sleep time. Samples are assayed for melatonin concentration [64].
  • Data Analysis: The DLMO phase is calculated, often defined as the time when melatonin concentration crosses a fixed threshold (e.g., 3 or 4 pg/mL). Correlation analyses (e.g., Pearson's r) are performed between DLMO time and both the MEQ total score and the MCTQ-derived MSF. A strong negative correlation is expected between MEQ score and DLMO (higher morningness scores correlate with earlier DLMO), and a strong positive correlation is expected between MSF and DLMO (later sleep midpoints correlate with later DLMO) [67].

This protocol has demonstrated that while these tools are correlated with physiological phase, the relationships can be weaker and more variable in clinical populations, underscoring their role as proxies rather than replacements for biomarker assessment [64].

Protocol for Assessing Social and Behavioral Misalignment

The MCTQ is uniquely designed to quantify "social jetlag," the misalignment between biological and social clocks.

• Objective: To calculate the degree of social jetlag and its association with health outcomes such as depressive symptoms [66] [68].
• Population: Working populations or student cohorts with distinct work/school and free-day schedules.
• Procedures:
  • Questionnaire Administration: Participants complete the MCTQ, providing sleep onset and offset times separately for workdays and free days.
  • Calculation:
    • MSW: Midpoint between sleep onset and offset on workdays.
    • MSF: Midpoint between sleep onset and offset on free days.
    • Social Jetlag (SJL): Absolute difference between MSF and MSW (in hours) [68].
  • Statistical Analysis: Researchers can then use regression models to investigate whether SJL mediates the relationship between evening chronotype (from MEQ or MCTQ) and outcomes like depressive symptoms (measured by, e.g., PHQ-9) or insomnia severity [66] [68]. Studies have shown that while eveningness is strongly linked to depression, SJL itself may be a less consistent mediator [66].

Assessment Workflow and Research Reagents

The following diagram illustrates a standard research workflow for selecting and applying these tools in a study investigating circadian phase and its health impacts.

Figure 1: A workflow for utilizing chronotype questionnaires and sleep diaries in a research study, highlighting the points at which different tools are integrated and how they can be validated with physiological markers.

Research Reagent Solutions

The table below details key tools and materials required for implementing the described protocols.

Table 2: Essential Research Reagents and Tools for Circadian Assessment

Item Name	Function/Description	Example Application in Protocol
Morningness-Eveningness Questionnaire (MEQ)	19-item scale assessing subjective preference for sleep/wake timing and peak alertness [66] [64].	Categorizing participants as morning, intermediate, or evening types for group comparisons or correlation with outcome variables [69].
Munich Chronotype Questionnaire (MCTQ)	Questionnaire capturing sleep timing and duration separately for work and free days [2] [67].	Calculating Mid-Sleep on Free Days (MSF) as a chronotype metric and Social Jetlag (SJL) as a measure of misalignment [68].
Sleep Diary	Prospective daily log of sleep and related behaviors (e.g., caffeine, exercise) [2] [64].	Tracking sleep parameters like Sleep Onset Latency (SOL) and Wake After Sleep Onset (WASO) over 1-2 weeks to establish baseline patterns [2].
Salivary Melatonin Assay Kit	Laboratory kit for quantifying melatonin concentrations in saliva samples.	Determining the Dim Light Melatonin Onset (DLMO) in validation studies to establish a gold-standard circadian phase marker [64].

The MEQ, MCTQ, and sleep logs are indispensable, yet distinct, tools in the circadian researcher's toolkit. The choice between them should be driven by the specific research question. The MEQ is optimal for studies focused on internal preference and its relationship to cognitive function or treatment response. The MCTQ is superior for investigations into the real-world impact of behavioral misalignment, such as social jetlag, on mental and metabolic health [66] [68]. Sleep diaries provide the foundational, high-fidelity temporal data required to contextualize both. Ultimately, these proxies are most powerful when their individual strengths are recognized and leveraged appropriately, and when their limitations are acknowledged, particularly in clinical populations where direct biomarker validation remains the gold standard [65] [64].

Optimizing Accuracy: Tackling Methodological Challenges and Confounding Factors

In the field of chronobiology, accurately determining an individual's circadian phase is critical for both research and clinical applications, from optimizing drug timing to diagnosing sleep disorders. However, a significant challenge in this pursuit is the phenomenon of masking—where exogenous factors like environmental light, posture, and activity can acutely alter the expression of circadian biomarkers, thereby obscuring the true signal of the endogenous circadian pacemaker [70]. This guide provides a comparative analysis of common circadian phase markers, evaluating their susceptibility to masking effects and summarizing the experimental protocols necessary to control for these confounders. The ability to distinguish a true circadian signal from a masked response is fundamental to the accuracy and reliability of comparative circadian phase marker research.

Comparative Analysis of Circadian Biomarkers

The table below compares key circadian biomarkers, their susceptibility to various masking factors, and their respective methodological requirements.

Table 1: Comparison of Key Circadian Phase Markers and Masking Controls

Biomarker	Primary Masking Factors	Impact of Masking	Control Methodologies	Relative Invasiveness
Dim Light Melatonin Onset (DLMO)	Light, posture, sleep, certain medications (e.g., beta-blockers, NSAIDs) [19] [71]	Light exposure suppresses melatonin production, directly altering the biomarker [19]. Sleep and posture can influence secretion patterns.	Strict dim light conditions (<10 lux) before and during sampling; maintain semi-recumbent posture; avoid sleep during sampling window [71] [19].	Medium (frequent saliva or blood sampling)
Cortisol Awakening Response (CAR)	Light, stress, activity, sleep timing, posture [19]	Light can blunt the morning peak; stress and physical activity can acutely elevate cortisol levels [19].	Sample immediately upon waking while in bed; control light conditions; minimize stress; use standardized sampling protocols [19].	Medium (frequent saliva sampling)
Core Body Temperature (CBT)	Sleep-wake cycle, posture, activity, food intake [72]	The sleep-wake cycle is a potent masker of CBT, with sleep causing a sharp decline and activity causing a rise [72].	Use of constant routine or forced desynchrony protocols to distribute masking factors evenly across the circadian cycle [72].	High (invasive rectal or ingestible probe)
Activity-Based Phase Prediction	Light-dark cycle, scheduled activities, "social jet lag" [12] [10]	Activity is directly driven by scheduled behaviors (work, commuting) which can mask the endogenous rhythm [72] [12].	Mathematical modeling (e.g., two-process model) to separate circadian and homeostatic components from activity data [72] [12].	Low (wearable actigraphy)
Heart Rate (HR) Circadian Rhythm	Physical activity, stress, sleep-wake transitions, caffeine [43] [10]	Exercise is a powerful acute masker of heart rate. Sleep and wake transitions cause rapid shifts [43].	Use of Bayesian algorithms to model and subtract the acute effects of exercise from the underlying circadian component [43].	Low (wearable photoplethysmography)

Essential Experimental Protocols for Controlling Masking

To ensure the accurate measurement of circadian phase, specific experimental protocols are designed to minimize or account for masking effects.

The Constant Routine Protocol

This gold-standard protocol is designed to reveal the endogenous circadian rhythm by holding masking factors constant.

• Methodology: For 24-40 hours or longer, participants remain in a state of enforced wakefulness under dim light conditions. They are provided with identical small snacks and fluids at regular intervals (e.g., hourly). Posture is maintained semi-recumbent, and activity levels are kept minimal [72] [71].
• Purpose: By distributing the effects of sleep, activity, food intake, and posture evenly across all circadian phases, the resulting rhythms in melatonin, cortisol, and temperature are considered a pure reflection of the endogenous pacemaker.

Dim Light Melatonin Onset (DLMO) Assessment

This is the most common method for assessing circadian phase in a clinical or field setting, with specific controls for light masking.

• Methodology: Saliva or blood samples are collected in the 4-6 hours before an individual's habitual bedtime. The critical control is maintaining dim light conditions (<10-30 lux), often verified with a lux meter at eye level [71] [19]. Participants should remain in a semi-recumbent position and avoid exercise, caffeine, and heavy meals during the sampling period [71].
• Purpose: Removing the masking effect of light allows for the accurate detection of the endogenous onset of melatonin secretion.

Mathematical Modeling of Wearable Data

With the rise of consumer wearables, computational methods have been developed to estimate circadian phase from activity or heart rate while accounting for masking.

• Methodology: Activity or heart rate data is collected via a wrist-worn device. Mathematical models, such as the two-process model or newer formulations that include a sleep inertia component, are applied to this data [72] [12]. For heart rate, models explicitly include a term for the acute effect of activity (masking) to isolate the underlying circadian oscillation [43].
• Purpose: These models statistically separate the endogenous circadian signal from the acute, masking influences of behavior and exercise, allowing for non-invasive phase estimation in real-world conditions.

The following diagram illustrates the core decision-making workflow for selecting an appropriate biomarker based on research constraints and the primary masking factors of concern.

The Scientist's Toolkit: Key Reagents & Materials

Table 2: Essential Research Materials for Circadian Rhythm Studies

Item	Function & Application
Salivary Melatonin/Cortisol Collection Kit	Non-invasive collection of saliva for hormone analysis via immunoassay or LC-MS/MS to determine DLMO or CAR [19].
Actigraph Device	Wrist-worn device that measures gross motor activity and (in some models) light exposure for long-term, ambulatory monitoring of rest-activity cycles [2] [73].
Consumer Wearable (e.g., Apple Watch, Fitbit)	Provides data on heart rate and activity, which can be processed with mathematical models to predict circadian phase in real-world settings [12] [10] [43].
Lux Meter	Crucial for verifying and maintaining dim light conditions (<10 lux) during DLMO assessment to prevent light-induced melatonin suppression [71] [19].
Core Body Temperature Sensor	Ingestible telemetric pill or rectal probe for continuous, high-fidelity measurement of CBT, the classic circadian rhythm [72].
LC-MS/MS Instrumentation	Considered the gold-standard analytical method for quantifying low concentrations of hormones like melatonin in saliva due to its high specificity and sensitivity, reducing cross-reactivity issues common in immunoassays [19].

Signaling Pathways and Experimental Workflows

The relationship between the central circadian pacemaker, its outputs, and the points where masking factors interfere is fundamental to understanding circadian biology. The following diagram maps this complex interaction.

The selection of a circadian phase marker is a strategic decision that balances accuracy, practicality, and vulnerability to masking. DLMO remains the most reliable field-based marker, provided strict dim light protocols are followed. Core body temperature offers high fidelity in a laboratory setting using constant routines, while activity and heart rate from wearables provide scalable, real-world estimates at the cost of requiring sophisticated models to filter out behavioral noise. A critical understanding of masking—the external factors that can distort these biological signals—is not merely a methodological detail but the very foundation of obtaining valid and reproducible results in comparative circadian research. Future advancements will likely focus on refining computational models to better disentangle the endogenous circadian signal from the pervasive effects of masking in freely behaving individuals.

The accurate quantification of hormones such as melatonin and cortisol is fundamental to circadian rhythm research. This guide provides an objective comparison of immunoassay and Liquid Chromatography-Tandem Mass Spectrometry (LC-MS/MS) methodologies, detailing their performance characteristics, appropriate applications, and practical implementation to aid researchers in selecting the optimal analytical platform.

In the field of chronobiology, the precise measurement of circadian phase markers like melatonin and cortisol is paramount. These hormones serve as key proxies for the phase of the suprachiasmatic nucleus (SCN), the body's master clock [74]. The choice between immunoassay and LC-MS/MS is not merely a technical decision; it directly impacts the reliability of fundamental circadian metrics such as the Dim Light Melatonin Onset (DLMO) and the Cortisol Awakening Response (CAR) [74]. Misalignment of these rhythms is linked to a spectrum of disorders, from neurodegenerative diseases to metabolic syndrome, underscoring the need for accurate quantification [74]. This guide synthesizes current evidence to compare these two dominant analytical techniques.

Head-to-Head Comparison: Performance Metrics at a Glance

The following table summarizes the core analytical characteristics of immunoassays and LC-MS/MS for hormone quantification.

Table 1: Analytical Platform Comparison for Hormone Quantification

Feature	Immunoassay	LC-MS/MS
Principle of Detection	Antibody-Antigen Binding [75]	Mass-to-Charge Ratio of Ions [76]
Specificity	Moderate; susceptible to cross-reactivity with structurally similar molecules [74] [77]	High; physically separates and identifies analytes based on mass [74] [76]
Sensitivity	Good for most clinical applications (e.g., ng/mL) [77]	Excellent; capable of detecting low pg/mL levels, crucial for salivary melatonin [74] [78]
Multiplexing Capability	Limited; typically single analyte or a few via panel testing	High; can simultaneously quantify multiple hormones and their metabolites in a single run [78]
Throughput & Automation	High; well-suited for automated, high-volume clinical analyzers [79]	Moderate to High; modern systems can achieve high throughput but often require more expert operation [80]
Sample Volume	Typically moderate	Can be very low (e.g., 20-50 μL) [80] [81]
Cost & Accessibility	Widely available; lower instrument cost; simpler operation [76]	Higher capital and maintenance cost; requires specialized expertise [76]

Experimental Data and Protocol Deep Dive

Comparative Performance in Real-World Applications

Recent studies directly comparing these methodologies provide critical insights into their performance. A 2025 study on urinary free cortisol (UFC) for diagnosing Cushing's syndrome found that four new direct immunoassays showed strong correlations (Spearman r = 0.950 - 0.998) with the LC-MS/MS reference method [77]. Despite this strong correlation, all immunoassays exhibited a proportionally positive bias, meaning they consistently overestimated cortisol concentrations compared to LC-MS/MS [77]. This highlights that while immunoassays can be excellent for diagnostic classification (AUC >0.95), they may lack the absolute accuracy of LC-MS/MS [77].

For melatonin, the challenge is greater due to its very low concentrations in non-invasive matrices like saliva. Immunoassays can suffer from cross-reactivity, which is particularly problematic for establishing the precise onset of melatonin secretion (DLMO) [74]. LC-MS/MS is increasingly recognized as the superior method for such applications due to its enhanced specificity and sensitivity [74] [78].

Detailed Experimental Protocol: Simultaneous Quantification of Circadian Hormones by UPLC-MS/MS

The following workflow is adapted from a study that developed a method for analyzing nine circadian rhythm hormones and metabolites in human overnight urine, showcasing the power of LC-MS/MS for comprehensive profiling [78].

Table 2: Key Research Reagent Solutions for UPLC-MS/MS Hormonal Analysis

Reagent / Material	Function / Application
Oasis HLB μElution 96-Well SPE Plate	Sample clean-up; solid-phase extraction to isolate and concentrate target analytes from the complex urine matrix [78].
Reverse Phase HSS C18 Column	Chromatographic separation; core component for resolving different hormones based on hydrophobicity before they enter the mass spectrometer [78].
Deuterated Analogues (Internal Standards)	Quantification control; correct for variability in sample preparation and ionization efficiency (e.g., cortisol-d4 for cortisol) [78] [77].
Gradient Elution System (Mobile Phase)	Liquid chromatography; a mixture of water and methanol (or acetonitrile) is used to separate the hormones as they pass through the column [78] [77].

Step-by-Step Workflow:

• Sample Preparation: A 96-well solid phase extraction (SPE) plate is used for high-throughput sample clean-up. Urine samples are loaded onto the plate, which is then washed to remove interfering components. The target hormones are subsequently eluted with a strong solvent [78].
• Chromatographic Separation: The extracted sample is injected into an Ultra Performance Liquid Chromatography (UPLC) system. The sample is carried by a mobile phase (e.g., water and methanol) through a reverse-phase HSS C18 column. A 9-minute gradient elution is used to separate the nine analytes—melatonin, its metabolites (6-hydroxymelatonin, 6-sulfatoxymelatonin), cortisol, and related steroid hormones—based on their chemical properties [78].
• Mass Spectrometric Detection: As the separated analytes elute from the column, they are ionized and introduced into the tandem mass spectrometer. The instrument is set to Multiple Reaction Monitoring (MRM) mode, where it selectively detects pre-defined mass transitions unique to each hormone and its deuterated internal standard. This provides a highly specific fingerprint for quantification [78] [77].
• Data Analysis: The peak areas for each hormone are compared to those of their internal standards and against a calibration curve to determine precise concentrations [78].

Diagram 1: UPLC-MS/MS workflow for circadian hormone analysis.

Detailed Experimental Protocol: Immunoassay for Hormone Quantification

Immunoassays, whether run on automated clinical platforms or as manual ELISA, follow a core principle of antibody-antigen binding [75]. The following describes a typical sandwich or competitive chemiluminescence immunoassay.

Step-by-Step Workflow:

• Coating and Blocking: A capture antibody is adsorbed onto a solid surface (e.g., a microplate or magnetic microparticles). Any remaining non-specific binding sites are then "blocked" with a protein like BSA or casein to reduce background noise [75].
• Incubation with Sample: The sample (e.g., serum, urine, or saliva) is added. The target hormone (antigen) in the sample binds to the immobilized capture antibody. In a competitive format (common for small molecules like cortisol or melatonin), the analyte in the sample competes with a labeled analyte for a limited number of antibody binding sites [77].
• Washing and Detection: Unbound materials are washed away. A secondary antibody, conjugated to a detection enzyme (e.g., Horseradish Peroxidase - HRP), is added. This antibody binds to the captured antigen, forming a "sandwich" [75].
• Signal Generation and Readout: A substrate solution is added. The enzyme converts the substrate, producing a colorimetric, fluorescent, or chemiluminescent signal. The intensity of this signal is proportional to the concentration of the hormone in the sample [75].
• Data Analysis: The signal from unknown samples is interpolated from a calibration curve run on the same plate or analyzer [75].

Diagram 2: Key steps in a typical immunoassay protocol.

The choice between immunoassay and LC-MS/MS is contingent on the specific research question and operational constraints.

• Choose Immunoassay when: Your priority is high-throughput clinical screening, diagnostic classification is supported by established cut-offs, and resources for specialized equipment and staff are limited. Recent advances in antibody engineering have improved the performance of direct immunoassays, making them a robust choice for many routine clinical applications [77].
• Choose LC-MS/MS when: The research demands the highest level of specificity and accuracy, particularly for low-abundance hormones like salivary melatonin [74]. It is the preferred method for discovering and validating new biomarkers, for studies requiring multiplexing of several hormones simultaneously [78], and when sample volume is severely limited [81].

For the most precise circadian phase assessment, particularly for DLMO where low salivary melatonin levels are critical, LC-MS/MS offers a distinct advantage. However, for large-scale epidemiological studies or clinical monitoring of the cortisol awakening response (CAR), well-validated immunoassays provide a cost-effective and efficient solution. A thorough understanding of the strengths and limitations of each platform ensures that the data generated is fit for purpose, ultimately advancing the field of circadian medicine.

Accurate determination of circadian phase is fundamental to circadian medicine and chronotherapy. Melatonin rhythm, particularly the Dim Light Melatonin Onset (DLMO), serves as the gold-standard circadian phase marker. This review objectively compares the accuracy and application of key circadian phase markers, focusing on two critical sources of variability: inter-individual differences in melatonin production and age-related alterations in rhythm characteristics. We synthesize experimental data demonstrating how low melatonin producers and aging populations present distinct challenges for circadian assessment. By evaluating methodological approaches and their limitations across these variable conditions, this guide provides researchers and drug development professionals with evidence-based recommendations for selecting appropriate circadian phase markers tailored to specific population characteristics and research contexts.

The accurate assessment of endogenous circadian phase is crucial for both basic research and clinical applications, particularly in chronopharmacology and the treatment of circadian rhythm sleep-wake disorders. The human circadian system, orchestrated by the suprachiasmatic nucleus (SCN), regulates numerous physiological processes with approximately 24-hour periodicity. Since direct measurement of SCN activity is not feasible in humans, researchers rely on peripheral biomarkers as proxies for circadian phase [19].

Among these biomarkers, the melatonin rhythm has emerged as the most reliable marker of internal circadian timing due to its robust rhythmicity, minimal masking by sleep or posture, and well-characterized light response properties [82] [19]. The dim light melatonin onset (DLMO) is widely considered the gold standard circadian phase marker, typically occurring 2-3 hours before habitual bedtime [19]. However, significant challenges arise in populations exhibiting either low melatonin production or age-related alterations in circadian rhythmicity, potentially compromising the accuracy and reliability of phase assessment.

This review systematically compares circadian phase markers, with particular emphasis on addressing methodological considerations for low melatonin producers and older adults. We provide experimental data quantifying inter-individual variability in melatonin production and age-related changes in circadian parameters, enabling researchers to select appropriate methodologies and interpret results within the context of these important sources of variability.

Melatonin as the Gold Standard Circadian Phase Marker

Physiology and Synthesis

Melatonin (N-acetyl-5-methoxytryptamine) is a hormone synthesized primarily by pinealocytes in the pineal gland from the essential amino acid tryptophan [82]. Its production follows a robust circadian pattern, with low levels during the day and elevated secretion during the night. The synthesis process involves several enzymatic steps: tryptophan is first hydroxylated and decarboxylated to form serotonin, which is then converted to N-acetylserotonin by the rate-limiting enzyme arylalkylamine N-acetyltransferase (AA-NAT), and finally methylated to form melatonin by acetylserotonin O-methyltransferase [82] [83].

The circadian regulation of melatonin production is controlled by the SCN through a multisynaptic pathway. The SCN receives light information via the retinohypothalamic tract and transmits signals through the paraventricular nucleus of the hypothalamus, the spinal cord, and the superior cervical ganglion, ultimately releasing norepinephrine in the pineal gland which triggers melatonin synthesis [82]. This complex pathway ensures that melatonin secretion is precisely synchronized to the environmental light-dark cycle while being protected from non-photic masking effects.

Figure 1: Melatonin Synthesis and Regulatory Pathway. The synthesis of melatonin in the pineal gland is regulated by the central circadian clock in the suprachiasmatic nucleus (SCN) through a complex multisynaptic pathway. Light information received by the retina travels via the retinohypothalamic tract (RHT) to the SCN, which then signals through the paraventricular nucleus (PVN), superior cervical ganglion (SCG), and ultimately triggers norepinephrine (NE) release in the pineal gland. The biochemical conversion from tryptophan to melatonin involves several enzymatic steps, with arylalkylamine N-acetyltransferase (AA-NAT) serving as the rate-limiting enzyme. Created based on information from [82] and [83].

DLMO Methodologies and Determination

The dim light melatonin onset (DLMO) represents the time in the evening when melatonin concentrations begin to rise significantly under dim light conditions. Several methodological approaches exist for determining DLMO, each with distinct advantages and limitations:

Fixed Threshold Method: DLMO is defined as the time when melatonin concentration crosses a predetermined absolute threshold. Common thresholds include 10 pg/mL for plasma and 3-4 pg/mL for saliva [19]. This method is straightforward but problematic for low melatonin producers whose peak levels may not reach standard thresholds.

Variable Threshold Method: The threshold is set relative to an individual's baseline, typically two standard deviations above the mean of three or more pre-rise values [19]. This approach accommodates inter-individual differences in amplitude but requires sufficient baseline samples.

Curve-Fitting Methods: Mathematical models (e.g., 3-harmonic fits, "hockey-stick" algorithms) are applied to the melatonin profile to objectively identify the onset of secretion [83] [19]. These methods reduce subjectivity but require multiple samples across the rising phase.

Physiologically-Based Models: Differential equation models of melatonin kinetics can estimate synthesis onset and offset (SynOn/SynOff) based on underlying physiology [83]. These models provide additional parameters (e.g., infusion/clearance rates) but are computationally complex.

Figure 2: Experimental Workflow for DLMO Assessment. Standard protocol for determining dim light melatonin onset (DLMO) begins with stabilization of sleep-wake schedules for at least one week prior to assessment. During the experimental session, participants remain in dim light conditions (<1-5 lux) with frequent sample collection (typically every 30-60 minutes) across the evening. Melatonin is assayed from collected samples, and DLMO is calculated using one of several methodological approaches, each with distinct advantages and limitations for different populations. Created based on information from [19] and [84].

Inter-Individual Variability in Melatonin Production

Characterization of Low Melatonin Producers

Low melatonin producers represent a significant challenge for accurate circadian phase assessment. These individuals exhibit consistently reduced melatonin amplitude across the night, with peak levels that may not reach standard thresholds used in DLMO determination. The prevalence of low melatonin production varies across populations, with estimates suggesting substantial portions of the general population may fall into this category [19].

The physiological basis for low melatonin production may involve several factors, including reduced pineal gland volume or function, genetic variations in synthesis enzymes, altered sympathetic innervation, or age-related degeneration. Notably, melatonin amplitude shows high inter-individual variability even among healthy young adults, with some individuals producing up to 50-fold differences in sensitivity to light-induced melatonin suppression [84].

Table 1: Factors Contributing to Inter-Individual Variability in Melatonin Production

Factor Category	Specific Factors	Impact on Melatonin	Research Evidence
Demographic	Age	Progressive reduction in amplitude	[82] [85]
Genetic	Enzyme polymorphisms (AA-NAT, ASMT)	Altered synthesis capacity	[82]
Environmental	Light exposure history	Modulates sensitivity	[84]
Pharmacological	Beta-blockers, NSAIDs, antidepressants	Suppression or enhancement	[82] [19]
Pathological	Pineal tumors, sympathetic damage	Impaired production	[82]
Lifestyle	Shift work, jet lag, alcohol use	Disrupted rhythm	[82] [19]

Methodological Challenges and Solutions for Low Producers

Low melatonin producers present specific methodological challenges for circadian phase assessment. The fixed threshold method becomes particularly problematic when an individual's peak melatonin concentration fails to exceed the standard threshold, making DLMO determination impossible. Similarly, variable threshold methods may yield unreliable results if baseline values are unstable or insufficient [19].

Alternative approaches better suited for low melatonin producers include:

Relative Threshold Methods: Using percentages of individual peak amplitude (e.g., DLMO25% or DLMO50%) rather than absolute thresholds accommodates differences in amplitude while maintaining phase accuracy [83].

Shape-Based Algorithms: The "hockey-stick" algorithm identifies the point of change from baseline to rise without relying on absolute thresholds, proving particularly useful for low amplitude profiles [19].

Kinetic Modeling: Physiologically-based models estimate synthesis onset (SynOn) independently of amplitude by modeling the underlying secretion kinetics [83].

Multiple Phase Markers: Combining melatonin with additional circadian markers (e.g., core body temperature minimum, cortisol rhythm) provides complementary phase estimates when melatonin amplitude is low.

Age-Related Changes in Circadian Rhythmicity

Characterizing Age-Associated Circadian Alterations

Healthy aging is associated with significant changes in circadian regulation that impact the accuracy and interpretation of circadian phase markers. These changes include alterations in both the timing and amplitude of circadian rhythms, with important implications for research and clinical practice.

Multiple studies have demonstrated that older adults (typically >60 years) exhibit earlier circadian timing (phase advance) compared to younger adults. A comparative study of younger (23.5 ± 3.9 years) and older (58.3 ± 4.2 years) adults found significantly earlier DLMO in the older group (20:46 h ± 1:16 vs. 21:41 h ± 1:08, p = 0.02) [86]. This phase advance was accompanied by earlier sleep timing (22:29 h ± 1:00 vs. 23:54 h ± 1:12, p = 0.04) in the older group.

Beyond phase timing, aging affects rhythm amplitude. Older adults show reduced amplitude in various circadian outputs, including approximately 14% lower amplitude in lipid circadian rhythms (p ≤ 0.001) compared to younger individuals [86]. This amplitude reduction reflects dampening of the central circadian signal, potentially due to age-related changes in SCN function or output signals.

Table 2: Quantitative Comparison of Circadian Parameters Between Younger and Older Adults

Circadian Parameter	Younger Adults	Older Adults	Statistical Significance	Data Source
DLMO Time	21:41 h ± 1:08	20:46 h ± 1:16	p = 0.02	[86]
Bed Time	23:54 h ± 1:12	22:29 h ± 1:00	p = 0.04	[86]
Melatonin Rhythm Amplitude	No significant difference	No significant difference	p = 0.62	[86]
Lipid Rhythm Amplitude	Reference	~14% reduction	p ≤ 0.001	[86]
Central vs. Peripheral Misalignment	Lower	Increased	Not specified	[10]
Circadian Lipid Acrophase	Reference	~2.1 h earlier	p ≤ 0.001	[86]

Neurobiological Basis of Age-Related Circadian Changes

The circadian alterations observed in aging have their basis in structural and functional changes within the circadian system. Post-mortem studies have revealed neuronal degeneration in the SCN of older individuals, potentially underlying the observed reduction in rhythm amplitude [85]. Additionally, age-related loss of noradrenergic neurons in the locus coeruleus, which projects to both the SCN and cortical areas, may contribute to circadian dysregulation and cognitive changes [85].

Beyond the central pacemaker, aging affects peripheral oscillators and their synchronization. Research demonstrates that the phase relationship between central and peripheral rhythms becomes altered with age, with older individuals showing different temporal organization between central markers (e.g., melatonin) and peripheral rhythms (e.g., lipid metabolism) [86]. This internal desynchronization may contribute to age-related health conditions.

Notably, the amplitude of the melatonin rhythm itself may be preserved with healthy aging, as one study found no significant difference in melatonin amplitude between younger and older groups (p = 0.62) [86]. This suggests that melatonin remains a reliable phase marker in older populations, though amplitude reduction in other circadian outputs indicates broader changes in circadian regulation.

Comparative Accuracy of Circadian Phase Markers

Methodological Comparison Across Variable Conditions

Different circadian phase markers demonstrate varying reliability across populations with inter-individual variability or age-related changes. The comparative accuracy of these markers has important implications for research design and clinical assessment.

Melatonin-based markers (particularly DLMO) generally provide the most precise phase estimation across diverse populations. Research indicates that melatonin allows for SCN phase determination with a standard deviation of 14 to 21 minutes, significantly more precise than cortisol-based methods (SD ≈ 40 minutes) [19]. This precision advantage persists in both young and older adults, though methodological adjustments may be necessary for low amplitude producers.

Core body temperature (CBT) minimum serves as an alternative phase marker, typically occurring approximately 2 hours before habitual wake time. However, CBT is more susceptible to masking effects from activity, posture, and sleep-wake transitions, potentially reducing its reliability in ambulatory settings or populations with fragmented sleep, such as older adults [83].

Cortisol rhythm, particularly the cortisol awakening response (CAR), provides another circadian indicator. However, cortisol is more strongly influenced by stress, awakening processes, and HPA axis reactivity, introducing additional sources of variability that may confound circadian assessment [19].

Table 3: Comparative Accuracy of Circadian Phase Markers in Variable Populations

Phase Marker	Precision (SD)	Advantages	Limitations	Suitability for Low Melatonin Producers	Suitability for Older Adults
DLMO (Melatonin)	14-21 min [19]	High precision, minimal masking	Requires dim light, multiple samples	Moderate (requires methodological adjustment)	High
CBT Minimum	~30-40 min [83]	Continuous measurement possible	Strong masking from behavior/sleep	High	Moderate (sleep fragmentation issues)
Cortisol Rhythm	~40 min [19]	Easy sampling (saliva)	Affected by stress, awakening	High	Moderate (HPA axis changes)
Acrophase (Activity)	1-2 h [12]	Non-invasive, continuous	Weak circadian component	High	Moderate (reduced amplitude)
Peripheral Rhythms (Lipids)	Not specified	System-wide assessment	Complex measurement	Not established	Limited (altered with aging)

Emerging Digital Markers and Modeling Approaches

Recent technological advances have enabled the development of non-invasive digital markers of circadian phase, offering promising alternatives for populations where traditional biomarkers present challenges. These approaches combine wearable device data with mathematical models to estimate circadian phase from activity, heart rate, or temperature patterns.

Activity-based phase prediction has demonstrated comparable accuracy to light-based models under normal living conditions, with predictions typically within 1 hour of DLMO [12]. Notably, in shift workers with high circadian disruption, activity-based predictions significantly outperformed light-based models, suggesting particular utility for populations with irregular light exposure [12].

Multimodal approaches combining heart rate, activity, and sleep data further enhance prediction accuracy. A large-scale study analyzing over 50,000 days of wearable data from 833 participants developed digital markers of central and peripheral circadian rhythms, demonstrating significant associations with mood and mental health outcomes [10]. These approaches show particular promise for long-term monitoring in real-world settings where traditional laboratory assessment is impractical.

Mathematical models of the human circadian clock have also advanced significantly, with several validated models now capable of predicting circadian phase from non-invasive inputs. Comparative studies show that different models achieve similar accuracy, with no significant differences between four major models when using the same input data [12]. This modeling approach provides a scalable solution for large-scale studies and clinical applications.

The Scientist's Toolkit: Essential Research Reagents and Methodologies

Table 4: Essential Research Materials and Methodologies for Circadian Phase Assessment

Category	Specific Item	Function/Application	Technical Considerations
Sample Collection	Salivette collection devices	Salivary melatonin sampling	Non-invasive, suitable for frequent sampling
Light Control	Dim red light source (<5 lux)	Maintain dim light conditions during DLMO assessment	Wavelength >600 nm minimizes melatonin suppression
Hormone Assay	Radioimmunoassay (RIA)	Melatonin quantification in saliva/blood	Established method, good sensitivity
Hormone Assay	LC-MS/MS	High-sensitivity melatonin quantification	Superior specificity, detects low levels [19]
Activity Monitoring	Actigraphy devices	Objective sleep-wake monitoring	Essential for activity-based phase prediction [12]
Data Analysis	Cosinor analysis software	Rhythm parameter quantification	Fits cosine curves to rhythmic data
Data Analysis	Nonlinear mixed-effects models	Population rhythm analysis	Accounts for inter-individual variability
Protocol Design	Constant routine protocol	Unmasking endogenous rhythm	Controls for environmental influences [86]
Protocol Design	Dim light melatonin assessment	Standardized DLMO determination	4-6 hour sampling window pre- to post-bedtime [19]

Accurate assessment of circadian phase requires careful consideration of inter-individual variability and age-related changes in circadian regulation. Melatonin rhythm, particularly DLMO, remains the gold-standard phase marker due to its precision and relatively minimal masking effects. However, methodological adjustments are necessary for populations with low melatonin production or altered rhythm characteristics.

For low melatonin producers, relative threshold methods, shape-based algorithms, and kinetic modeling approaches provide more reliable phase estimation than standard fixed thresholds. In older adults, preserved melatonin rhythm amplitude supports the continued use of DLMO, though researchers should account for phase advances and potential internal desynchronization with peripheral rhythms.

Emerging digital biomarkers and mathematical models offer promising non-invasive alternatives for circadian phase assessment, particularly in real-world settings and large-scale studies. These approaches demonstrate comparable accuracy to traditional methods while enabling long-term monitoring in diverse populations.

By selecting appropriate methodologies tailored to specific population characteristics and research contexts, investigators can optimize the accuracy and reliability of circadian phase assessment, advancing both basic circadian research and clinical applications in chronotherapy.

Assessing circadian rhythms and sleep-wake patterns presents distinct challenges across different populations, with marker accuracy varying significantly based on individual physiological and pathological conditions. The comparative accuracy of circadian phase markers is influenced by multiple factors, including the integrity of the photic entrainment pathway, stability of social zeitgebers, and underlying medical conditions. In shift workers, circadian misalignment creates predictable fluctuations in marker reliability, while in clinical disorders such as Non-24-Hour Sleep-Wake Rhythm Disorder (N24SWD), the fundamental period of the circadian pacemaker diverges from 24 hours, complicating measurement and interpretation. This analysis examines the specific methodological challenges and comparative performance of assessment tools across these populations, providing researchers with validated protocols and analytical frameworks for generating reliable, reproducible data in complex circadian phenotypes.

Assessment Methodologies: Tools, Protocols, and Comparative Performance

The accurate measurement of circadian parameters relies on a multifaceted approach combining subjective reports, objective monitoring, and molecular biomarkers. Each methodology offers distinct advantages and limitations, with performance characteristics that vary across clinical populations and research settings.

Table 1: Core Methodologies for Circadian Rhythm Assessment

Method Category	Specific Tool/Assay	Measured Parameters	Population-Specific Considerations	Protocol Duration
Subjective Assessment	Sleep Diaries (Prospective)	Time in bed (TIB), sleep onset latency (SOL), wake after sleep onset (WASO), total sleep time (TST), sleep efficiency (SE) [2]	Essential for documenting circadian drift in N24SWD; reveals social jetlag in shift workers [2]	Minimum 7-14 days; 2-4 weeks for N24SWD diagnosis [87]
Objective Monitoring	Wrist Actigraphy	Activity-rest patterns, sleep-wake cycles, estimates of TST, SE, and WASO [88]	High ecological validity for shift work research; tracks progressive delay in N24SWD [89] [90]	5-14 days typical; longer for free-running disorders [90]
Physiological Biomarker	Dim Light Melatonin Onset (DLMO)	Phase angle of entrainment, circadian phase position, period length (tau) [2]	Gold standard for N24SWD; requires controlled dim-light conditions [2] [90]	4-8 hours sampling (every 30-60 min) prior to habitual sleep time
Polysomnography (PSG)	Laboratory PSG	Sleep architecture (N1, N2, N3, REM), respiratory events, limb movements [2]	Rules out comorbid OSA in shift workers and narcolepsy in IH patients [87] [91]	1-2 nights in lab

Detailed Experimental Protocols for Key Assays

Dim Light Melatonin Onset (DLMO) Protocol: Salivary or plasma melatonin sampling remains the gold standard for assessing endogenous circadian phase. The validated protocol requires participants to remain in dim light (<10 lux) for 4-8 hours before their habitual sleep time. Samples are collected every 30-60 minutes under supervised conditions to ensure compliance. The DLMO is computationally determined as the time when melatonin concentration crosses a fixed threshold (e.g., 3-4 pg/mL for saliva) or exceeds a percentage of the peak amplitude. In populations with N24SWD, this protocol may need repetition across multiple weeks to capture the free-running period [2] [90].

Actigraphy Data Processing and Analysis: Raw accelerometer data (often at 30-60 Hz) is processed using validated algorithms (e.g., Sadeh, Cole-Kripke) to dichotomize sleep-wake states. For circadian analysis, 1-2 minute epoch data is integrated into activity counts. The ACCEL algorithm utilizes the derivative of triaxial acceleration (jerk) to reduce individual variability, achieving reported accuracy of 91.7%, sensitivity of 96.2%, and specificity of 80.1% in sleep-wake classification [88]. Non-parametric circadian rhythm analysis (NPCRA) then calculates metrics like interdaily stability, intradaily variability, and relative amplitude, which are particularly useful for quantifying fragmentation in shift workers' rhythms [89].

Population-Specific Challenges and Marker Performance

Shift Workers: Circadian Misalignment and Masking Effects

In shift-working populations, environmental and behavioral factors consistently mask endogenous circadian rhythms, reducing the accuracy of standard phase markers. A 2025 cross-sectional study of 288 shift-working nurses demonstrated that circadian rhythm types significantly moderate the impact of shift work demands on sleep quality and depressive symptoms. Specifically, nurses with higher "languidness" (vulnerability to sleep disruption) showed stronger negative responses to increasing shift hours, with nonlinear analysis identifying a threshold effect beyond 24 shift-work hours in 4 weeks [89].

The constant conflict between socially imposed sleep-wake schedules and the endogenous circadian rhythm creates a state of chronic circadian misalignment. This misalignment compromises the reliability of subjective sleep reports, as sleep episodes often occur against the biological grain of the circadian alerting signal. Actigraphy, while useful for documenting sleep patterns, cannot easily disentangle the voluntary rest during biological day from true circadian-driven sleep propensity. Consequently, melatonin and core body temperature rhythms remain the most stable markers, though their phase relationship to sleep-wake behavior is profoundly altered [2] [89].

Non-24-Hour Sleep-Wake Rhythm Disorder (N24SWD): The Free-Running Challenge

N24SWD presents perhaps the most profound challenge to accurate circadian assessment, characterized by a non-entrained circadian period (tau) that typically exceeds 24 hours. This disorder affects over 55-70% of totally blind individuals but is increasingly recognized in sighted populations, where it is frequently associated with psychiatric comorbidities and male gender [92] [87] [90].

The fundamental assessment challenge in N24SWD is capturing the free-running period, which requires longitudinal measurement over weeks to months. Sleep diaries and actigraphy are essential tools for documenting the characteristic daily drift of sleep onset and offset. However, consumer sleep trackers often perform poorly in this population due to their algorithmic optimization for 24-hour rhythms and limited specificity for detecting wakefulness [88] [93]. DLMO measurement remains the biomarker gold standard but must be repeated at intervals to accurately determine the circadian period, creating significant participant burden and cost [2] [90].

A 2024 patient registry survey of 1,627 CRSWD patients revealed significant diagnostic and therapeutic challenges specific to N24SWD. Current treatments, including light therapy and melatonin, showed limited efficacy, with a sizable proportion of patients reporting that phase-delay chronotherapy subsequently precipitated N24SWD [92]. This highlights the sensitivity of this population to iatrogenic disruption and the need for precise circadian phase assessment before intervention.

Comorbid Psychiatric and Neurological Conditions

Circadian rhythm disruptions exhibit high comorbidity with psychiatric disorders, creating complex diagnostic challenges. In a sighted adolescent case study of N24SWD comorbid with Pediatric Autoimmune Neuropsychiatric Disorders Associated with Streptococcal Infections (PANDAS), the psychiatric symptoms both masked and were exacerbated by the circadian disorder. The successful diagnostic approach required ambulatory circadian monitoring (ACM) over an extended period to differentiate primary circadian dysfunction from sleep disruption secondary to psychiatric pathology [90].

The bidirectional relationship between circadian rhythms and mental health creates particular challenges for marker interpretation. Depression can mimic circadian disorder symptoms, while circadian disruption can precipitate or exacerbate mood disorders. In these populations, multidimensional assessment combining the Pittsburgh Sleep Quality Index (PSQI), Patient Health Questionnaire-9 (PHQ-9), and objective circadian timing markers provides the most accurate differential diagnosis [89] [90].

Signaling Pathways and Molecular Mechanisms

The molecular machinery governing circadian rhythms operates as a transcriptional-translational feedback loop (TTFL) with core components that are highly conserved across tissues and species. Understanding these pathways is essential for developing targeted interventions and interpreting circadian biomarker data.

Diagram: Core Circadian Molecular Feedback Loop. This transcriptional-translational feedback loop, with a period of approximately 24 hours, forms the basis of endogenous circadian timing. The CLOCK/BMAL1 heterodimer activates transcription of Per and Cry genes, whose protein products eventually inhibit their own transcription, creating a self-sustaining oscillator [2].

The core circadian clock consists of positive elements CLOCK and BMAL1 that heterodimerize and activate transcription of Period (Per1, Per2, Per3) and Cryptochrome (Cry1, Cry2) genes. PER and CRY proteins form complexes in the cytoplasm, translocate back to the nucleus, and inhibit CLOCK-BMAL1-mediated transcription, completing the approximately 24-hour cycle. In familial forms of Advanced and Delayed Sleep-Wake Phase Disorders, mutations in these core clock genes (Per2, Per3, Cry2, Cry1) alter the intrinsic period of the oscillator, demonstrating the direct molecular basis of certain circadian rhythm sleep-wake disorders [2].

Diagnostic Workflow and Analytical Approaches

The complexity of circadian assessment in special populations requires structured diagnostic workflows that integrate multiple data sources and analytical methods. The following diagram illustrates a recommended pathway for differential diagnosis of complex circadian disorders.

Diagram: Differential Diagnosis Workflow for Complex Circadian Disorders. This stepped approach integrates subjective and objective measures to differentiate between primary circadian disorders, shift work-related misalignment, and psychiatric comorbidities [2] [89] [90].

The Scientist's Toolkit: Essential Research Reagents and Materials

Table 2: Essential Research Materials for Circadian Rhythm Studies

Tool/Reagent	Specific Example	Research Application	Technical Notes
Actigraphy Device	Actiwatch, Axivity, GENEActiv	Longitudinal monitoring of rest-activity cycles in naturalistic environments [88]	Raw data output preferred for reprocessing with open-source algorithms [88]
Melatonin Assay Kit	Salivary ELISA, RIA	Quantification of melatonin concentrations for DLMO determination [2] [90]	Requires dim-light conditions during collection; saliva collection is less invasive [90]
Consumer Sleep Tracker	Fitbit, Oura Ring, Apple Watch	High-resolution longitudinal sleep data in real-world settings [88] [93]	Use trend data rather than absolute values; beware of low specificity for wake detection [93]
Circadian Type Inventory	CTI Questionnaire (FR/LV scales)	Assessment of individual differences in circadian flexibility and vigor [89]	Identifies subpopulations vulnerable to shift work disruption [89]
Polysomnography System	Laboratory PSG with EEG, EOG, EMG	Gold standard sleep architecture assessment; rules out comorbid sleep disorders [2]	Essential for differentiating N24SWD from narcolepsy or sleep apnea [87]

The accurate assessment of circadian rhythms in special populations requires meticulous methodology and interpretation framed within an understanding of population-specific challenges. Shift workers exhibit predictable marker unreliability due to chronic misalignment, while individuals with N24SWD present the fundamental complication of a non-24-hour endogenous period. Comorbid psychiatric conditions further obscure circadian assessment through bidirectional relationships with sleep disruption. Future research should prioritize the development of less burdensome circadian phase markers validated specifically in these complex populations, alongside analytical methods that can disentangle circadian from masking influences. The integration of multidimensional assessment protocols—combining subjective reports, objective monitoring, and molecular biomarkers—remains essential for generating reliable data to advance both clinical management and therapeutic development for circadian rhythm sleep-wake disorders.

The accurate estimation of circadian phase markers is crucial for advancing research in chronobiology, drug development, and personalized medicine. Consumer-grade wearable devices offer unprecedented opportunities for continuous physiological monitoring in real-world settings, yet they present significant challenges related to data gaps, signal noise, and variable accuracy that can compromise the robustness of circadian phase estimation. Unlike controlled laboratory environments, ambulatory monitoring introduces multiple confounding factors including motion artifacts, device placement issues, and environmental variables that disrupt signal acquisition. This comparative analysis examines the performance of various consumer-grade devices and research-grade alternatives for circadian phase estimation, providing researchers with evidence-based strategies to mitigate these challenges and enhance the reliability of physiological data collected in free-living conditions.

The fundamental tension in this field lies in balancing the ecological validity offered by consumer devices with the measurement precision required for scientific research. As noted in a recent guide to consumer-grade wearables in cardiovascular care, "the proprietary nature and iterative approach in this market makes product comparison and clinical utility difficult to quantify and track in real-time" [94]. This analysis synthesizes validation data across device types and populations to establish a framework for robust phase estimation despite the inherent limitations of ambulatory monitoring.

Performance Comparison of Ambulatory Monitoring Devices

Accuracy Metrics Across Device Types and Physiological Parameters

Table 1: Performance Comparison of Consumer-Grade vs. Research-Grade Devices

Device / Platform	Target Population	Parameter	Accuracy / Agreement	Limitations / Context
Fitbit Charge 2	Medical interns (n=833)	Circadian phase markers	CRCO-sleep misalignment: Increased from 1.67h (SD=1.58) to 2.19h (SD=2.35) during internship [10]	Real-world study with 52,061 days of data; algorithm-derived phase estimates
Garmin Vivosmart 4	Parkinson's disease (n=104)	Step count (avDS)	ICC: 0.89 (95% CI 0.85-0.92) overall; Lower reliability in tremor-dominant subgroup (ICC: 0.84) [95]	5-day monitoring; reduced reliability with specific motor symptoms
Corsano CardioWatch	Pediatric cardiology (n=31)	Heart rate	Mean accuracy: 84.8% (SD 8.7%); Bias: -1.4 BPM; LoA: -18.8 to 16.0 BPM [96]	Accuracy declined with higher HR and movement
Hexoskin Smart Shirt	Pediatric cardiology (n=36)	Heart rate	Mean accuracy: 87.4% (SD 11%); Bias: -1.1 BPM; LoA: -19.5 to 17.4 BPM [96]	Higher accuracy in first 12 hours (94.9%) vs. latter 12 (80%)
Consumer-grade wearables (Various)	General population (Systematic review)	Resting heart rate	MAE: ~2 BPM; MAPE: <10% [94]	Accuracy declines during physical activity
Research-grade devices (e.g., activPAL, ActiGraph)	Lung cancer patients (Ongoing trial)	Step count, posture, PA intensity	Comparison to direct observation (criterion) [97]	Laboratory and free-living validation ongoing

Table 2: Impact of Specific Conditions on Device Accuracy

Factor	Impact on Accuracy	Evidence
High-intensity movement	Significant reduction in HR accuracy	"Accuracy declined during more intense bodily movements" [96]
Tremor (Parkinson's disease)	Reduced step count reliability	"ICCs were significantly lower in participants with tremor" [95]
Disease phenotype (PD)	Variable reliability across subtypes	"Lower reliability in TD phenotype vs. PIGD" [95]
Skin characteristics	Potential signal quality issues	"Accuracy gaps in high-melanin or tattooed skin types" [98]
Extended monitoring	Performance degradation over time	"Hexoskin accuracy higher in first 12 hours (94.9%) vs. latter 12 (80%)" [96]
Consumer vs. research-grade	Consistency differences in free-living	"Lack of standardized validation procedures" for consumer devices [97]

Key Insights from Comparative Analysis

The data reveals several critical patterns for researchers considering devices for circadian phase estimation. First, device performance varies significantly across population subgroups, with specific clinical characteristics (e.g., tremor in Parkinson's disease) substantially impacting accuracy. Second, consumer-grade devices show reasonable accuracy for group-level analyses but may lack precision for individual-level clinical decision making. Third, temporal degradation of signal quality presents challenges for long-term monitoring studies, necessitating specific protocols for device recalibration or data quality checks.

A comprehensive review of consumer wearables summarizes this challenge: "At rest, wearables are widely considered to measure HR accurately... However, the accuracy of HR measurement in wearables is known to decline during physical activity" [94]. This pattern of context-dependent performance underscores the need for rigorous validation studies in the specific populations and conditions of intended use.

Methodological Approaches for Robust Phase Estimation

Experimental Protocols for Device Validation

Laboratory and Free-Living Validation Protocol (Adapted from Lung Cancer Wearable Validation Study [97])

• Objective: Validate and compare accuracy of consumer-grade (Fitbit Charge 6) and research-grade (activPAL3 micro, ActiGraph LEAP) wearable activity monitors in both laboratory and free-living conditions.

• Participants: 15 adults diagnosed with lung cancer (stages 1-4), representing a population with potential mobility challenges and gait impairments.

• Laboratory Protocol:

  • Structured activities including variable-time walking trials, sitting and standing tests, posture changes, and gait speed assessments.
  • Video recording for validation (criterion measure).
  • Comparison of WAM data to video-recorded observations.
  • Calculation of sensitivity, specificity, positive predictive value, and agreement.

• Free-Living Protocol:

  • Participants wear devices continuously for 7 days except during water-based activities.
  • Agreement between devices assessed using Bland-Altman plots, intraclass correlation analysis, and 95% limits of agreement.
  • Administration of validated survey instruments before and after data collection to control for potential confounding factors.

• Outcome Measures: Step count; time spent at light, moderate, and vigorous PA intensity levels; posture; and posture changes.

Digital Circadian Phase Estimation Protocol (Adapted from Medical Intern Study [10])

• Objective: Quantify degrees of circadian disruption from wearable data in real-world settings.

• Participants: 833 first-year medical interns (over 50,000 days of data).

• Device: Fitbit Charge 2 for collecting heart rate, activity, and sleep data.

• Circadian Measures:

  • CRCO: Central circadian rhythm estimated using Kalman filtering framework incorporating indirect information from peripheral rhythms.
  • CRPO: Peripheral circadian rhythm in heart rate estimated using nonlinear least squares method.
  • Sleep midpoint: Behavioral rhythm derived from sleep-wake cycle.

• Circadian Disruption Metrics:

  • CRCO-sleep misalignment: Absolute difference between time of minimum in central oscillation and sleep midpoint.
  • CRPO-sleep misalignment: Absolute difference between time of circadian HR minimum and sleep midpoint.
  • Internal misalignment: Log-likelihood value of absolute difference between central and peripheral HR clock phases.

• Analysis: Bidirectional links between digital markers of circadian disruption and mood, accounting for confounders such as demographic and geographic variables.

Signal Processing and Noise Mitigation Techniques

Virtual PPG Reconstruction Framework [99]

Advanced computational approaches show promise for addressing signal gaps and noise in ambulatory monitoring:

• Cross-modal virtual sensing: Reconstruction of virtual PPG signals from accelerometer data alone, enabling heart rate estimation when PPG is missing, unreliable, or power-constrained.

• Dual-mode architecture:

  • Offline variational autoencoder for high-fidelity PPG spectrum reconstruction from ACC input.
  • Lightweight real-time attention-based denoising model for HR prediction.

• Performance: Achieves 7.0 BPM mean absolute error with only 2.6K parameters, making it suitable for embedded deployment.

• Utility: Serves as a fallback modality when optical sensing is unreliable, enabling gap-filling, post-processing correction, and low-power monitoring.

This approach represents a broader "physiological virtual sensing paradigm" where one modality can be inferred from another, supporting robust multimodal inference under real-world constraints [99].

Diagram 1: Computational Workflow for Robust Circadian Phase Estimation. This workflow illustrates the signal processing pipeline for deriving circadian phase markers from noisy ambulatory data, incorporating cross-modal reconstruction to address signal gaps. CRCO = Circadian Rhythm in Central Oscillator; CRPO = Circadian Rhythm in Peripheral Oscillator.

The Researcher's Toolkit: Essential Solutions for Circadian Monitoring Studies

Table 3: Research Reagent Solutions for Ambulatory Monitoring Studies

Solution / Material	Function / Application	Considerations for Use
Multi-sensor wearables (PPG, ACC, ECG)	Captures complementary physiological signals for cross-modal validation	Research-grade devices (activPAL, ActiGraph) offer better validation but consumer devices (Fitbit, Garmin) improve scalability [97] [94]
Kalman filtering framework	Statistical inference of circadian phase from noisy wearable data	Enables simultaneous estimation of multiple circadian biomarkers under real-world conditions [10]
Cross-modal reconstruction algorithms	Reconstructs missing PPG data from accelerometer signals	Maintains data continuity during signal loss; requires training on synchronized datasets [99]
Hybrid biosensor platforms (PPG + ECG)	Improves accuracy through multi-modal signal acquisition	Combined photoplethysmography and electrocardiography enhances arrhythmia detection and signal reliability [100] [98]
Bland-Altman analysis	Quantifies agreement between consumer devices and criterion measures	Essential for establishing limits of agreement in validation studies [97] [96]
Nonlinear least squares methods	Estimates peripheral circadian rhythms from heart rate data	Suitable for analyzing circadian patterns in heart rate data from wearables [10]

The expanding market for wearable biosensors—projected to grow from USD 648.5 million in 2025 to USD 3,064.8 million by 2035 [98]—reflects both the tremendous potential and evolving nature of this field. For researchers pursuing robust phase estimation from ambulatory and consumer-grade devices, a strategic approach balancing methodological rigor with practical constraints is essential. Key recommendations include: (1) implementing multi-modal sensing and cross-modal reconstruction to address inevitable signal gaps; (2) validating devices in specific target populations rather than relying on general performance metrics; (3) employing advanced computational frameworks like Kalman filtering that account for real-world noise conditions; and (4) transparently reporting limitations related to device accuracy and data quality.

The integration of artificial intelligence with biosensing technologies presents promising opportunities for enhanced noise reduction and pattern recognition in circadian monitoring [101]. As the field advances, researchers must remain critical consumers of wearable technology claims while leveraging these powerful tools to uncover new insights into circadian biology in ecologically valid contexts. By implementing the strategies outlined in this comparison guide, researchers can navigate the challenges of data gaps and noise to extract meaningful circadian phase estimates from ambulatory monitoring devices.

In the field of chronobiology, accurately determining an individual's circadian phase is paramount for both research and clinical applications, from optimizing drug administration in chronotherapy to understanding the links between circadian disruption and disease. The comparative accuracy of different circadian phase markers is highly dependent on the rigor of the protocols used to measure them. This guide objectively compares leading methodologies, focusing on how standardized practices in sample collection, timing, and environmental control affect the reliability and accuracy of the resulting data. Establishing strict protocols is not merely a procedural formality but a critical step in ensuring that comparative findings reflect true biological differences rather than methodological inconsistencies.

Comparative Analysis of Circadian Phase Marker Methodologies

The following table summarizes the key performance characteristics of three primary categories of circadian phase assessment methods.

Table 1: Comparison of Circadian Phase Marker Methodologies

Methodology	Key Measured Analytes / Signals	Phase Estimation Accuracy (Approx.)	Key Advantages	Key Limitations & Practical Burdens
Gold-Standard Hormonal Assays	Dim-Light Melatonin Onset (DLMO), Cortisol rhythm [2] [40]	High (Considered the reference standard)	Direct measurement of key circadian hormones; high validity when protocols are strictly followed [2].	Highly burdensome; requires strict environmental controls (dim light, posture) and frequent sampling over many hours [2].
Wearable-Derived Computational Estimates	Heart Rate (HR), Activity, Sleep-Wake Data (from wearables) [10]	Moderate (Good for group-level trends and longitudinal tracking)	Passive, continuous data collection in real-world settings; enables large-scale studies; non-invasive [10].	Indirect estimate of circadian phase; accuracy can be influenced by activity, stress, and other confounders [10].
Novel Biosensor-Based Approaches	Cortisol and Melatonin in passive perspiration [40]	High (Strong agreement with salivary measures)	Continuous, non-invasive monitoring; strong correlation with salivary gold-standard (e.g., Pearson r = 0.92 for cortisol) [40].	Emerging technology; requires further validation across diverse populations and conditions [40].

Experimental Protocols for Key Circadian Markers

Protocol 1: Determining Dim-Light Melatonin Onset (DLMO)

DLMO is a cornerstone gold-standard marker for assessing the timing of the central circadian clock.

• Sample Collection: Salivary samples are collected at pre-determined intervals (e.g., every 30-60 minutes) for 5-7 hours before and until after an individual's habitual sleep time [2].
• Sample Timing: The precise clock time of each sample must be recorded. The protocol typically begins in the early evening, around 5-7 hours before habitual sleep onset.
• Environmental Controls: This is a critical component. Sampling must occur under dim-light conditions (<10 lux) to prevent light-induced melatonin suppression. Participants should also maintain a relaxed, seated posture and refrain from eating, drinking (except water), or brushing their teeth immediately before or during sampling to avoid contaminating the sample [2].
• Laboratory Processing: Saliva samples are immediately frozen after collection and later analyzed using sensitive immunoassays (e.g., ELISA) or mass spectrometry to determine melatonin concentration. DLMO is calculated as the time at which melatonin concentration crosses a predetermined threshold (e.g., 3 or 4 pg/mL).

Protocol 2: Estimating Phase via Wearable Data and Computational Models

This method uses passively collected physiological data to estimate circadian phase.

• Sample Collection: Continuous data streams are collected from a wearable device (e.g., Fitbit, ActiGraph), including heart rate (HR), heart rate variability (HRV), body movement (acceleration), and sleep-wake timing [10].
• Sample Timing: Data is collected continuously over multiple days and weeks to capture daily patterns and intra-individual variability. A minimum of several days of high-quality data is required for reliable phase estimation [10].
• Environmental Controls: As data is collected in free-living conditions, controlling the environment is not feasible. Instead, computational models must account for "noise" from physical activity, stress, and light exposure. The sleep midpoint, derived from the wearable, is a key behavioral anchor used in analysis [10].
• Data Processing & Analysis: Specialized algorithms are applied to the data streams. One advanced method uses a nonlinear Kalman filtering framework to estimate the phase of the central circadian oscillator (CRCO) and peripheral oscillators (CRPO) from HR and activity data, even under noisy conditions [10]. Phase estimates are often expressed as misalignment between these oscillators and the sleep-wake cycle (e.g., CRCO-sleep misalignment) [10].

Protocol 3: Continuous Hormonal Monitoring via Wearable Biosensors

This emerging protocol uses novel biosensors to measure circadian hormones directly from passive perspiration.

• Sample Collection: A wearable biosensor patch continuously collects and analyzes passive perspiration (sweat) on the skin [40].
• Sample Timing: The sensor provides a near-continuous time-series of cortisol and melatonin concentrations, capturing dynamic changes throughout the 24-hour cycle without requiring discrete samples.
• Environmental Controls: Validation studies require correlative sampling in controlled conditions. For example, simultaneous salivary samples are collected at specific times to validate the sweat-based measurements against the gold-standard matrix [40].
• Laboratory Processing & Analysis: The biosensor performs on-patch analysis or stabilizes the sample for later readout. Data is analyzed using rhythmicity analysis packages like CircaCompare to determine the phase, amplitude, and period of the hormonal rhythms. Research has shown strong agreement between sweat and saliva for both cortisol (Pearson r = 0.92) and melatonin (r = 0.90) [40].

Visualizing Workflows and Pathways

The following diagrams illustrate the core experimental workflow and the underlying molecular mechanism of the circadian clock, which these protocols aim to measure.

Circadian Phase Assessment Workflow

Molecular Mechanism of the Circadian Clock

The Scientist's Toolkit: Essential Research Reagent Solutions

Table 2: Key Reagents and Materials for Circadian Rhythm Research

Item	Function in Research
Salivary Melatonin/Cortisol Immunoassay Kits	Quantifies hormone concentrations in saliva samples for determining DLMO and cortisol rhythms; the core reagent for gold-standard protocols [2].
Validated Neutralizing Transport Buffers	Used with sampling sponges/swabs to neutralize residual sanitizers on environmental surfaces, ensuring accurate microbial recovery during environmental monitoring [102].
Nonlinear Kalman Filtering Software	Computational algorithm used to estimate the phase of central and peripheral circadian oscillators from noisy, real-world wearable data (e.g., heart rate, activity) [10].
CircaCompare Software	A statistical package in R used for differential rhythmicity analysis, enabling comparison of circadian parameters (phase, amplitude) between groups or conditions [40].
Passive Perspiration Biosensor Patch	A wearable device that continuously collects and analyzes biomarkers like cortisol and melatonin from sweat, enabling non-invasive circadian monitoring [40].
Actigraphy Data Analysis Platform	Software that processes raw movement data from actigraphs to objectively estimate sleep-wake patterns, a key behavioral rhythm used in circadian analysis [10] [2].

Benchmarking Performance: A Comparative Validation of Circadian Phase Estimation Methods

In the field of chronobiology, accurately determining an individual's internal circadian phase is crucial for both research and clinical applications. The dim light melatonin onset (DLMO) has emerged as the gold standard biomarker for assessing circadian phase in humans [103] [2]. DLMO represents the time in the evening when melatonin concentrations first rise above a defined threshold under dim light conditions, providing a reliable and phase-locked reference point for the circadian system [104]. The validation of any circadian phase prediction method must therefore be conducted through direct comparison against this established biological marker, with carefully selected error metrics quantifying the degree of alignment.

Current practice parameters for diagnosing circadian rhythm sleep disorders predominantly rely on sleep logs, actigraphy, and polysomnography, but notably lack direct circadian phase measures [103] [104]. This represents a significant clinical gap, as research has demonstrated that among patients with documented delayed sleep timing, approximately half do not actually show delayed circadian rhythms as measured by DLMO [46]. This discrepancy highlights the critical need for accurate, accessible circadian phase assessment methods that can be validated against DLMO using appropriate statistical measures.

Methodological Approaches to Circadian Phase Prediction and Validation

DLMO Measurement Protocols

The rigorous measurement of DLMO requires controlled conditions and standardized protocols. In laboratory settings, participants typically remain in dim light conditions (<20 lux) for several hours while providing serial saliva samples at regular intervals (usually hourly) [103] [104]. These samples are subsequently assayed for melatonin concentration, typically using radioimmunoassay techniques with high sensitivity [103]. DLMO is then determined through one of two primary methods:

• Absolute threshold method: DLMO is defined as the time when melatonin concentration exceeds an absolute threshold of 3 pg/mL [103] [104]
• Relative threshold method: DLMO is defined as the time when melatonin concentration exceeds 2 standard deviations above the mean of three baseline values [103] [104]

Studies have demonstrated that the absolute threshold method (3 pg/mL) shows better agreement between at-home and in-lab measurements, with average differences of approximately 37 (±19) minutes compared to 54 (±36) minutes for the relative threshold method [103]. This protocol serves as the foundational reference against which all predictive methods are validated.

Predictive Modeling Approaches

Dynamic Mathematical Models

Dynamic models represent one major approach to circadian phase prediction. These are based on mathematical representations of the circadian system's response to light, such as the Jewett-Kronauer model [46]. These models quantify the characteristics of the circadian clock and its phase-dependent sensitivity to light, incorporating parameters such as intrinsic circadian period (typically around 24.4 hours) and light sensitivity (determining the amplitude and shape of the phase response curve) [46]. These models have demonstrated the ability to predict DLMO in patients with Delayed Sleep-Wake Phase Disorder (DSWPD) with a root mean square error (RMSE) of 68 minutes, accurately predicting DLMO within ±1 hour in 58% of participants and within ±2 hours in 95% [46].

Statistical Regression Models

Statistical models offer an alternative approach, using regression techniques to identify relationships between measurable inputs and circadian phase. These models typically incorporate light exposure during phase delay and advance portions of the phase response curve, along with sleep timing and demographic variables [46]. In validation studies, statistical models have demonstrated slightly improved performance compared to dynamic models, achieving an RMSE of 57 minutes in predicting DLMO, with predictions accurate within ±1 hour in 75% of participants and within ±2 hours in 96% [46].

Wearable-Based Digital Biomarkers

Recent advances in wearable technology have enabled the development of digital biomarkers for circadian phase. These approaches use physiological data such as heart rate, activity, and sleep metrics collected from wearable devices to estimate circadian phase [10]. Using a nonlinear Kalman filtering framework, researchers can simultaneously infer the time evolution of multiple circadian biomarkers, including central and peripheral circadian rhythms [10]. These digital measures can then be used to calculate circadian disruption markers, including misalignment between central circadian rhythms and sleep midpoint, misalignment between peripheral circadian rhythms and sleep midpoint, and internal misalignment between central and peripheral rhythms [10].

Table 1: Comparison of Circadian Phase Prediction Methodologies

Method Type	Key Inputs	Underlying Principle	Advantages	Limitations
Dynamic Models [46]	Light exposure data, intrinsic period parameters	Mathematical simulation of circadian clock dynamics	Based on established physiology; generalizable	Requires specialized expertise; computationally intensive
Statistical Models [46]	Light exposure timing, sleep patterns, demographics	Regression of measured variables against DLMO	Can achieve high accuracy; potentially simpler implementation	May have limited generalizability beyond training data
Wearable Digital Biomarkers [10]	Heart rate, activity, sleep data from wearables	Statistical inference from physiological time series	Non-invasive; suitable for long-term monitoring	Validation against DLMO still emerging

Key Validation Metrics for Phase Prediction

The performance of circadian phase prediction methods is quantified using standardized error metrics that compare predicted values against measured DLMO. The most commonly employed metrics include:

• Root Mean Square Error (RMSE): This metric gives higher weight to larger errors due to the squaring of differences before averaging, making it particularly sensitive to outliers [105] [46]. The formula is: RMSE = √[Σ(predicted DLMO - actual DLMO)² / N] [106]

• Mean Absolute Error (MAE): This metric represents the average magnitude of errors without considering direction, providing a more intuitive measure of typical error size [105]. The formula is: MAE = Σ|predicted DLMO - actual DLMO| / N [105]

• Prediction Accuracy within Time Windows: This approach calculates the percentage of predictions that fall within specified temporal windows of actual DLMO (e.g., ±1 hour, ±2 hours) [46], offering clinically relevant performance boundaries.

Additional specialized metrics include Mean Absolute Percentage Error (MAPE), which expresses errors as percentages of the actual values [105], and Mean Squared Logarithmic Error (MSLE), which is particularly useful when data spans multiple orders of magnitude [105].

Comparative Performance Analysis

Quantitative Accuracy Assessment

Direct comparison of prediction methods against DLMO reveals significant differences in performance characteristics. The following table summarizes key validation metrics from published studies:

Table 2: Performance Metrics of Circadian Phase Prediction Methods Against DLMO

Prediction Method	RMSE (minutes)	MAE (minutes)	Within ±1 hour	Within ±2 hours	Study Population	Citation
Dynamic Model	68	57	58%	95%	DSWPD patients (N=154)	[46]
Statistical Model	57	44	75%	96%	DSWPD patients (N=154)	[46]
At-home vs. In-lab DLMO (Absolute Threshold)	-	37	-	-	Sleep difficulty patients (N=24)	[103]
At-home vs. In-lab DLMO (Relative Threshold)	-	54	-	-	Sleep difficulty patients (N=24)	[103]
Bedtime - 2 hours	129	-	-	-	DSWPD patients (N=154)	[46]

The superior performance of both dynamic and statistical models compared to the simple heuristic of subtracting 2 hours from bedtime (which reflects the average phase angle in healthy populations) highlights the value of sophisticated modeling approaches, particularly in clinical populations where this relationship may be altered [46].

Clinical Application and Diagnostic Accuracy

Beyond simple prediction error, the clinical utility of phase prediction methods can be assessed by their ability to correctly classify patients according to circadian phenotypes. In one study of DSWPD patients, both dynamic and statistical models were evaluated for their ability to distinguish between circadian and non-circadian DSWPD using the criterion that DLMO occurring 30 minutes before or after desired bedtime indicates circadian DSWPD [46]. The statistical model demonstrated a sensitivity of 74% and specificity of 63%, while the dynamic model showed a sensitivity of 64% and specificity of 66% [46]. This classification performance underscores the potential clinical utility of these methods while highlighting areas for improvement.

Experimental Protocols for Method Validation

Standardized DLMO Measurement Procedure

Proper validation of any circadian phase prediction method requires rigorous DLMO assessment using the following protocol:

• Pre-collection requirements: Participants should avoid eating, drinking, or brushing teeth within 20 minutes of each sample collection to prevent melatonin assay interference [103]

• Light control: Maintain dim light conditions (<20 lux) for several hours before and during sample collection, using dimmable lighting or dark goggles if necessary [103] [104]

• Sample collection: Collect serial saliva samples at regular intervals (typically hourly) beginning several hours before expected DLMO and continuing until several hours after [103]

• Sample handling: Immediately freeze samples at -20°C until assay [103]

• Melatonin assay: Use sensitive immunoassay techniques (e.g., radioimmunoassay) with detection thresholds of at least 0.2 pg/mL [103]

• DLMO calculation: Determine DLMO through linear interpolation between adjacent samples using either absolute (3 pg/mL) or relative (2 standard deviations above baseline mean) thresholds [103]

Prediction Model Validation Workflow

The following diagram illustrates the comprehensive workflow for validating circadian phase prediction methods against DLMO:

Diagram Title: Circadian Phase Prediction Validation Workflow

Essential Research Reagents and Materials

Table 3: Essential Research Materials for Circadian Phase Validation Studies

Item	Specifications	Primary Function	Example Sources/References
Salivary Melatonin Collection Kit	Salivettes or similar collection devices	Non-invasive saliva sample collection for melatonin assay	[103] [104]
Melatonin Immunoassay Kit	High-sensitivity RIA or ELISA (detection limit ≤0.2 pg/mL)	Quantification of melatonin concentration in saliva samples	Bühlmann Direct Saliva Melatonin RIA [103]
Dim Light Lighting System	Adjustable lamps capable of <20 lux illumination	Maintaining appropriate conditions for DLMO assessment	Philips-Respironics [104]
Actigraphy Devices	Wrist-worn accelerometers with light sensors	Objective measurement of activity patterns and light exposure	Actiwatch [46]
Wearable Heart Rate Monitors	Consumer-grade (Fitbit Charge 2) or research-grade	Continuous physiological data for digital biomarker development	Fitbit Charge 2 [10]
Light Measurement Device	Calibrated lux meter	Verification of dim light conditions during DLMO assessment	[103] [104]

The validation of circadian phase prediction methods against DLMO requires careful consideration of both experimental protocols and statistical metrics. Current evidence demonstrates that sophisticated modeling approaches can predict DLMO with mean absolute errors of approximately 44-57 minutes, representing a significant improvement over simple heuristics based solely on sleep timing [46]. The choice between dynamic mathematical models, statistical regression approaches, and emerging wearable-based digital biomarkers depends on the specific application, with each method offering distinct advantages and limitations.

Validation metrics must extend beyond simple measures of central tendency like RMSE and MAE to include clinically relevant classifications such as prediction accuracy within ±1 hour and diagnostic performance in identifying circadian rhythm disorders [46]. As these prediction methods continue to develop, standardized validation protocols and comprehensive reporting of performance metrics will be essential for translating these approaches from research tools to clinical applications.

In the field of chronobiology, accurately determining the phase of the human circadian clock is crucial for both research and clinical diagnostics. Among the most commonly measured circadian biomarkers are the hormones melatonin and cortisol, as well as the rhythm of core body temperature (CBT). Under controlled laboratory conditions, these markers demonstrate significant differences in their precision and susceptibility to confounding factors. Melatonin, particularly its Dim Light Melatonin Onset (DLMO), is consistently identified as the most precise phase marker, exhibiting the lowest variability. Cortisol rhythms, including the Cortisol Awakening Response (CAR), provide a valuable but less precise alternative, while CBT, despite its historical use, shows lower precision and higher susceptibility to masking by behavioral and environmental factors. The following guide provides a detailed, evidence-based comparison to inform biomarker selection for scientific and clinical applications.

Table 1: Overall Comparison of Circadian Phase Markers

Marker	Key Phase Indicator	Reported Precision (Variability)	Major Strengths	Major Limitations
Melatonin	Dim Light Melatonin Onset (DLMO)	Highest (SD: 14-21 min) [74]	Gold standard precision; less affected by sleep/wake state and exercise [107]	Suppressed by light; requires controlled dim light conditions [74]
Core Body Temperature (CBT)	CBT Trough (midpoint of nocturnal decline)	Lower (Wearable vs. rectal probe: LoA ±1.07 hours) [47]	Non-invasive measurement with modern sensors [47]	Highly susceptible to masking from sleep, activity, and posture [107]
Cortisol	Cortisol Awakening Response (CAR); Diurnal peak	Moderate (SD: ~40 min) [74]	Strong diurnal rhythm; easy sampling (saliva) [108]	Affected by stress, sleep deprivation, and medication; lower rhythm amplitude [74]

Experimental Protocols for Circadian Phase Assessment

Melatonin (Dim Light Melatonin Onset - DLMO)

The assessment of DLMO is the gold-standard protocol for determining circadian phase in humans and requires strict control over environmental conditions.

• Sample Collection: Serial sampling of blood plasma or saliva is performed, typically every 30-60 minutes over a 4-6 hour window before and after habitual bedtime [74]. Salivary sampling is favored for its non-invasiveness.
• Controlled Conditions: Sampling must occur under dim light conditions (<10-30 lux) to prevent light-induced suppression of melatonin secretion [74] [107]. Participant posture, sleep-wake state, and food intake are also standardized.
• Analytical Methods: Samples are analyzed using immunoassays (ELISA) or the more sensitive and specific liquid chromatography tandem mass spectrometry (LC-MS/MS) [34] [74].
• Phase Calculation: DLMO is most commonly calculated using a fixed threshold (e.g., 10 pg/mL in plasma, 3-4 pg/mL in saliva) or a variable threshold (2 standard deviations above the mean of baseline daytime values) [74]. Advanced curve-fitting algorithms (e.g., "hockey-stick" model) are also used to improve robustness against noisy or incomplete data [109].

Core Body Temperature (CBT)

The circadian rhythm of CBT is characterized by a decline during the biological night and a trough in the early morning hours.

• Measurement: The traditional gold-standard method uses a rectal probe that continuously measures temperature at high temporal resolution (e.g., once per minute) [47]. Newer, less invasive methods include ingestible pill telemetry and patch-type wearable sensors placed on the chest that estimate CBT from skin temperature and heat flux using machine learning [47].
• Data Analysis: The raw temperature data is averaged and smoothed. The CBT trough is identified as the midpoint between the points where the temperature curve crosses a line set at the mid-level of the nocturnal temperature decline [47].
• Considerations: The CBT rhythm is highly sensitive to masking effects from sleep, physical activity, and postural changes. Therefore, laboratory protocols must carefully control or account for these factors to unmask the endogenous circadian signal [107].

Cortisol (Cortisol Awakening Response - CAR)

Cortisol secretion follows a robust diurnal pattern with a sharp peak shortly after morning awakening.

• Sample Collection: For assessing the CAR, salivary cortisol samples are collected immediately upon waking, and then at 15-, 30-, and 45-minute intervals post-awakening [74] [108]. For full diurnal profiling, sampling continues at 2-4 hour intervals throughout the day.
• Protocol Adherence: Precise timing of sample collection is critical, as the CAR is a rapid event. Participants must accurately record awakening times and adhere to the sampling schedule [108].
• Analytical Methods: Similar to melatonin, cortisol is quantified using immunoassays or LC-MS/MS, with the latter providing superior specificity by avoiding cross-reactivity with other steroids [74] [108].

Quantitative Precision Analysis

Direct comparisons in controlled studies reveal clear hierarchies in the precision of circadian phase estimates.

Table 2: Quantitative Precision of Circadian Phase Estimates

Marker	Phase Indicator	Reported Precision / Variability	Experimental Context
Melatonin	DLMO (Plasma/Saliva)	Standard Deviation: 14 - 21 minutes [74]	Inpatient studies with controlled conditions [74]
Cortisol	Diurnal Rhythm	Standard Deviation: ~40 minutes [74]	Inpatient studies with controlled conditions [74]
Core Body Temperature	CBT Trough (Wearable vs. Rectal)	Limit of Agreement (95% LoA): -0.76 to +1.07 hours [47]	Free-living validation study [47]

The superior precision of melatonin is attributed to its relatively direct control by the suprachiasmatic nucleus (SCN) and its lower susceptibility to masking by non-circadian factors like exercise and sleep-wake state, compared to CBT and cortisol [107]. The precision of cortisol is compromised by its high sensitivity to stress and its pulsatile, ultradian secretion pattern [108].

Methodological Factors Influencing Precision

Impact of Analytical Techniques

The choice of laboratory assay significantly impacts the reliability of hormone measurements.

• Immunoassays (ELISA): While widely available and cost-effective, these tests can suffer from cross-reactivity with other molecules, leading to overestimation of concentrations, particularly critical at low levels near the detection limit for DLMO [74].
• Liquid Chromatography Tandem Mass Spectrometry (LC-MS/MS): This method offers higher specificity, sensitivity, and reproducibility and is considered the superior analytical technique for both melatonin and cortisol in circadian research [34] [74]. It allows for the simultaneous quantification of both hormones.

Data Analysis and Sampling Protocols

The method used to calculate phase from raw data is a major source of variability.

• Melatonin Analysis: A study comparing 17 different analysis methods found that the completeness of data, particularly around the onset of secretion, critically impacts phase estimates [110] [107]. Curve-fitting methods have been shown to be more robust to missing data points and noise than simple threshold methods [109]. Sparse-sampling protocols targeting key periods of the melatonin rise can maintain reliability while reducing costs [109].
• Cortisol Analysis: The calculation of the CAR requires precise timing and is often expressed as the area under the curve (AUC) or the mean increase from waking.

Diagram 1: Circadian Phase Assessment Workflow

The Scientist's Toolkit: Key Research Reagents & Materials

Table 3: Essential Materials for Circadian Rhythm Research

Item / Reagent	Primary Function	Application Notes
LC-MS/MS System	Gold-standard quantification of melatonin and cortisol.	Provides high specificity and sensitivity; allows for multiplexing of analytes [74].
Salivary Immunoassay Kits (ELISA)	Accessible quantification of hormone levels.	Potential for cross-reactivity; requires validation against LC-MS/MS for low melatonin levels [74].
Dim Light-Compatible Lighting	Controls light exposure to prevent melatonin suppression.	Essential for DLMO protocols; typically requires <10 lux [74] [107].
Salivette Collection Tubes	Non-invasive sample collection for salivary hormones.	Ideal for frequent sampling and field studies; requires participant compliance [74] [108].
Rectal Temperature Probe	Gold-standard continuous CBT measurement.	High accuracy but invasive; used for validating new sensors [47].
Wearable Temperature Sensor	Ambulatory estimation of CBT and sleep-wake cycles.	Enables long-term, real-world data collection (e.g., CALERA sensor) [47].
Curve-Fitting Software	Robust calculation of phase from time-series data.	Improves reliability of DLMO estimates with noisy or sparse data [109].

Diagram 2: Simplified Circadian Signaling Pathways

The integration of wearable devices into clinical and research settings represents a paradigm shift from episodic to continuous physiological monitoring. For researchers and drug development professionals, this transition offers unprecedented opportunities to capture circadian phase markers and other digital biomarkers in real-world environments. However, the scientific utility of these data hinges on a fundamental question: how accurately do wearable-derived estimates correlate with gold-standard measurements? Validation studies are paramount, as even research-grade devices demonstrate significant variability in accuracy across different physiological parameters, populations, and measurement contexts.

The limitations of consumer-grade wearables are particularly notable in specialized populations. A 2025 study investigating sleep monitoring in masters endurance athletes revealed that consumer-grade smartwatches and self-reported sleep diaries reported significantly longer total sleep times (by 109 and 126 minutes, respectively) and higher sleep efficiency compared to research-grade actigraphy [111]. This discrepancy was more pronounced in athletes with shorter or more fragmented sleep, highlighting a critical proportional bias that could substantially impact research findings and clinical interpretations [111]. Such findings underscore the necessity of context-specific validation, as device performance is influenced by numerous factors including the physiological parameter being measured, subject demographics, and measurement environment.

Comparative Accuracy of Wearable-Derived Biomarkers

The correlation between wearable-derived data and gold-standard references varies significantly across different types of biomarkers. The tables below summarize key validation findings from recent studies across three critical domains: sleep monitoring, heart rate variability (HRV), and multi-parameter vital signs.

Table 1: Validation of Wearable-Derived Sleep and Circadian Biomarkers

Biomarker	Wearable Device	Gold Standard	Population	Key Correlation/Agreement Findings	Limitations & Contextual Factors
Total Sleep Time (TST)	ActiGraph GT9X (Research-grade)	N/A (Reference)	Masters endurance athletes (n=70)	Recorded shortest TST (332±87 min) [111]	Reference value for comparison [111]
	Garmin smartwatches (Consumer-grade)	ActiGraph GT9X	Same cohort	Longer duration by 126 min (p<0.001) [111]	Poor agreement in athletes with shorter sleep [111]
	Self-reported sleep diary	ActiGraph GT9X	Same cohort	Longer duration by 109 min (p<0.001) [111]	Poor agreement (ICC=0.190); closer to smartwatch (ICC=0.880) [111]
Sleep Efficiency (SE%)	ActiGraph GT9X (Research-grade)	N/A (Reference)	Same cohort	Reference value for comparison [111]	Reference value for comparison [111]
	Garmin smartwatches & Sleep diary	ActiGraph GT9X	Same cohort	Higher SE% with biases of -4.1% and -5.9% [111]	Greater differences in athletes with lower sleep efficiency [111]
Circadian Phase/Energy (CCE)	Fitbit Versa/Inspire 2	Clinical Mets criteria	Adults with/without Metabolic Syndrome (n=272)	Strongest association with MetS (p<0.001) [112]	Novel biomarker from wavelet transform of heart rate [112]

Table 2: Validation of Physiological Parameters from Wearables

Parameter	Wearable Device	Gold Standard	Population	Key Correlation/Agreement Findings	Limitations & Contextual Factors
Heart Rate Variability (RMSSD)	Polar OH1 (PPG)	Polar H10 (ECG)	Healthy adults (n=31)	Excellent supine (ICC=0.955), Good seated (ICC=0.834) [113]	Bias: -2.1 to -8.1 ms; wider LoA when seated [113]
Heart Rate	viQtor Upper Arm PPG	ECG & Pulse Oximetry	Postoperative patients (n=42)	High accuracy: ARMS=2.01 BPM, Bias=0.08 BPM [114]	95% LoA: -3.83 to 3.99 BPM [114]
Respiratory Rate	viQtor Upper Arm PPG	Capnography	Same cohort	High accuracy: ARMS=2.85 BRPM, Bias=-0.40 BRPM [114]	95% LoA: -5.85 to 5.04 BRPM [114]
Oxygen Saturation	viQtor Upper Arm PPG	Pulse Oximetry	Same cohort	High accuracy: ARMS=2.08%, Bias=-0.03% [114]	95% LoA: -4.14 to 4.09% [114]
Heart Rate (Children)	Corsano CardioWatch & Hexoskin Shirt	Holter ECG	Children with heart disease (n=31-36)	Good accuracy (84.8%-87.4%); good agreement (Bias≈ -1 BPM) [96]	Accuracy declined with higher HR and movement [96]

The data reveal several critical patterns. First, consumer-grade devices consistently overestimate sleep duration and efficiency compared to research-grade actigraphy, a significant concern for studies requiring precise sleep architecture metrics [111]. Second, PPG-based HRV measurements show excellent agreement with ECG in controlled, supine conditions, but this agreement diminishes in seated positions and with older populations, highlighting the impact of posture and autonomic dynamics on measurement accuracy [113]. Third, clinical-grade wearable multi-parameter monitoring can achieve high accuracy in controlled clinical environments, with respiratory rate (RR) typically showing the widest limits of agreement compared to heart rate and SpO₂ [114].

Key Experimental Protocols in Validation Research

Understanding the methodologies behind validation studies is crucial for interpreting their results and designing future research. The following section details representative experimental protocols from recent high-quality investigations.

Protocol for Sleep Monitoring Validation in Athletes

A 2025 study exemplifies rigorous validation in a specific population—masters endurance athletes [111]. The protocol was designed to assess agreement between research-grade actigraphy, consumer-grade smartwatches, and self-reported sleep diaries.

• Participants: 70 masters endurance athletes (43 males, 27 females) aged ≥35 years, training ≥240 minutes across five weekly sessions [111].
• Device Configuration: Participants simultaneously wore an ActiGraph GT9X (research-grade) and a Garmin smartwatch (18 different models) on the non-dominant wrist for seven consecutive nights during their base training phase [111].
• Data Collection: The ActiGraph collected triaxial movement data at 60 Hz. Participants maintained a detailed self-reported sleep diary. Garmin data was synced each morning via the Garmin Connect app [111].
• Analysis: Agreement for parameters like Total Sleep Time (TST) and Sleep Efficiency (SE%) was assessed using Intraclass Correlation Coefficients (ICCs) and Bland-Altman analyses, which quantify bias and limits of agreement [111].

This protocol highlights the importance of simultaneous data collection, inclusion of various device grades, and the use of statistical methods tailored for agreement assessment rather than just correlation.

Protocol for HRV Validation Across Postures and Demographics

A 2025 study directly compared HRV derived from PPG and ECG signals, systematically evaluating the impact of posture, recording duration, age, and sex [113].

• Participants: 31 healthy adults, with subgroup analyses for age (≤40 vs. >40 years) and sex [113].
• Device Configuration: Participants wore a Polar H10 chest strap (ECG) and a Polar OH1 sensor (PPG) on the non-dominant arm or forearm. Devices were synchronized for simultaneous recording [113].
• Study Design: A cross-over design where participants completed both seated and supine conditions in randomized order. Each 5-minute measurement was preceded by a 1-minute stabilization phase in a controlled environment [113].
• Data Analysis: Time-domain HRV metrics (RMSSD, SDNN) were extracted from both devices. Agreement was evaluated using ICCs and Bland-Altman plots, comparing biases and limits of agreement across different conditions [113].

This meticulous protocol reveals how factors like body position significantly affect the agreement between PPG- and ECG-derived HRV, providing essential guidance for researchers on standardizing measurement conditions.

Protocol for Clinical-Grade Multi-Vital Sign Monitoring

A clinical validation study of the viQtor upper arm wearable in postoperative patients demonstrates the stringency required for medical device approval [114].

• Participants: 42 adults admitted to the Post-Anesthesia Care Unit (PACU) after major non-cardiac surgery [114].
• Reference Standards: The wearable's readings for RR, HR, and SpO₂ were compared against a standard bedside monitor (Spacelab XPREZZON). Capnography served as the gold standard for RR [114].
• Procedure: The wearable was applied to the patient's upper arm immediately upon PACU admission. Data collection continued for a median of 14 hours, with vital signs recorded as one-minute averages [114].
• Statistical Analysis: Agreement was assessed primarily with Bland-Altman analyses for repeated measurements, calculating the Average Root Mean Square (ARMS), bias, and 95% limits of agreement. Clinical accuracy was further evaluated using Clarke Error Grid analysis [114].

This protocol underscores the necessity of using clinical gold standards, collecting data over extended periods, and employing analysis techniques that evaluate both statistical and clinical significance.

Visualization of the Biomarker Validation Workflow

The following diagram illustrates the multi-stage workflow for validating digital biomarkers from wearable devices, as derived from the methodologies in the cited studies.

Diagram Title: Wearable Biomarker Validation Workflow

This workflow outlines the systematic process for validating digital biomarkers, from initial study design through to final statistical analysis, as demonstrated across multiple cited studies [111] [113] [114].

The Scientist's Toolkit: Essential Research Reagents and Solutions

Table 3: Key Solutions and Technologies for Wearable Validation Research

Solution/Technology	Function in Validation Research	Representative Examples
Research-Grade Actigraphy	Provides benchmark for sleep/wake patterns and physical activity quantification.	ActiGraph GT9X [111], Fibion Krono [55]
Medical-Grade Reference Devices	Serve as gold standards for physiological parameter validation.	Holter ECG [96], Capnography [114], Clinical Bedside Monitors [114]
Multi-Parameter Wearable Platforms	Enable continuous, ambulatory monitoring of multiple vital signs.	viQtor (RR, HR, SpO₂) [114], ActiGraph LEAP (HR, SpO₂) [115], BioButton [116]
Specialized Circadian Monitoring	Captures environmental and physiological cues for rhythm analysis.	Fibion Krono (light, skin temperature, posture) [55]
Agreement Statistical Tools	Quantify bias, limits of agreement, and clinical relevance of measurements.	Bland-Altman Analysis [111] [113] [114], Intraclass Correlation (ICC) [111] [113], Clarke Error Grid [114]
Signal Processing Frameworks	Extract and refine biomarkers from raw sensor data.	Group Sparse Mode Decomposition for PPG [117], Continuous Wavelet Transform for circadian energy [112]

The validation of digital biomarkers from wearable devices is not a binary outcome but a multidimensional assessment highly dependent on context. The evidence indicates that while certain clinical-grade wearables can achieve remarkable accuracy for specific parameters like heart rate, significant challenges remain in other areas, particularly in sleep staging and HRV measurement under dynamic conditions. The correlation with gold standards is consistently influenced by factors such as device grade, sensor placement, population characteristics, and measurement context.

For researchers and drug development professionals, these findings necessitate a cautious, evidence-based approach to selecting and deploying wearable technologies. The choice of device must be guided by the specific biomarker of interest, the target population, and the required precision level. Future validation efforts should prioritize standardized protocols, transparent reporting of limitations, and the development of novel analytical methods, such as explainable AI [112], to enhance the reliability and interpretability of wearable-derived data. As the field evolves, this rigorous validation framework will be essential for transforming raw sensor data into clinically and scientifically meaningful digital biomarkers.

Circadian rhythms, the endogenous ~24-hour oscillations in physiology and behavior, are critical determinants of health and disease [118] [19]. For researchers and drug development professionals, accurately assessing an individual's internal circadian time is crucial for optimizing drug timing (chronotherapy) and understanding disease mechanisms [21] [118]. The field has traditionally relied on biomarker-based methods, such as Dim Light Melatonin Onset (DLMO), considered the gold standard for measuring the phase of the central circadian clock [21] [19]. However, these methods are often cumbersome, expensive, and impractical for large-scale or continuous real-world monitoring [21] [119].

To overcome these limitations, mathematical models that estimate circadian phase from wearable device data (e.g., activity, heart rate, body temperature) have been developed [119] [10] [120]. These models promise a scalable, non-invasive solution for circadian assessment in real-world settings. This guide objectively compares the performance and accuracy of these emerging mathematical models against traditional biomarker protocols and evaluates their applicability for both healthy adults and shift-working populations.

Comparative Accuracy of Circadian Assessment Methods

The table below summarizes the key performance metrics of various circadian assessment methods as reported in validation studies.

Table 1: Accuracy Comparison of Circadian Phase Assessment Methods

Method Category	Specific Method/Model	Reported Accuracy	Validation Population	Key Advantages	Key Limitations
Biomarker (Gold Standard)	Dim Light Melatonin Onset (DLMO)	Standard deviation of 14-21 min for SCN phase determination [19].	Healthy adults in controlled settings [21] [19].	High precision; direct measure of central clock phase [19].	Labor-intensive, costly, requires controlled dim-light conditions [21] [119].
Mathematical Model (Blood)	BodyTime Assay (NanoString)	Accuracy equaling DLMO [21].	28 early or late chronotypes in validation study [21].	High accuracy from a single blood sample; objective [21].	Invasive (blood draw); requires gene expression profiling.
Mathematical Model (Wearables)	Kalman Filtering on Heart Rate	Mean absolute error of ~1 hr for normally entrained adults; ~2.5 hr for non-rotated night shift workers [120].	Medical interns and shift workers [10] [120].	Fully non-invasive; suitable for long-term, real-world monitoring [10].	Accuracy decreases with shift work; requires high-quality sensor data.
Mathematical Model (Wearables)	Approximation-Based Least Squares on Body Temperature	Computationally highly efficient (300-fold faster) [119].	Cancer patients and general users [119].	High computational efficiency enables implementation on low-power devices [119].	Validation in clinical populations ongoing.
Mathematical Model (Wearables)	Activity-based Phase Prediction (Entrain App)	Mean absolute error of ~1 hr for normal conditions [120].	>100 travelers from the general population [120].	Uses widely available activity data; convenient for travelers [120].	Less accurate for populations with irregular schedules.

Detailed Experimental Protocols and Methodologies

Gold Standard Protocol: Dim Light Melatonin Onset (DLMO)

Objective: To determine the circadian phase by measuring the onset of melatonin secretion under dim-light conditions [21] [19].

Workflow:

• Pre-Protocol Stabilization: Participants maintain a stable sleep-wake schedule for at least one week before the assessment.
• Controlled Conditions: Sampling is conducted in a controlled laboratory or dim-light environment (<10-30 lux) to prevent light-induced melatonin suppression [19].
• Sample Collection: Saliva, plasma, or serum samples are collected every 30-60 minutes over a 4-6 hour window, typically starting 5 hours before and ending 1 hour after habitual bedtime [19].
• Hormone Analysis: Melatonin concentration in samples is quantified using immunoassays or the more specific Liquid Chromatography Tandem Mass Spectrometry (LC-MS/MS) [19].
• Phase Calculation: DLMO is calculated as the time when melatonin concentration crosses a predetermined threshold (e.g., 3-4 pg/mL for saliva) or using a variable threshold based on baseline values [19].

Digital Biomarker Protocol: Wearable-Based Circadian Phase Estimation

Objective: To estimate the circadian phase non-invasively from physiological time-series data (e.g., heart rate, body temperature, activity) collected via wearable devices [119] [10].

Workflow:

• Data Acquisition: Participants wear a device (e.g., Fitbit) that continuously records heart rate, activity, and sleep data over multiple days/weeks in their real-world environment [10].
• Data Preprocessing: Raw sensor data is cleaned and filtered. For heart rate and body temperature, which have strong circadian components, the data is often de-trended to remove non-circadian influences [119] [10].
• Model Application:
  • For Heart Rate: A nonlinear least squares method or a Kalman filtering framework is applied to the processed data to estimate the time of the circadian minimum in heart rate, which serves as a phase marker for the peripheral oscillator [10].
  • For Body Temperature: An approximation-based least-squares method fits a harmonic-regression model with autoregressive noise to the data to extract the underlying circadian rhythm [119].
  • For Activity: Actigraphy data is input into mathematical models of the human circadian pacemaker (e.g., the Jewett-Forger-Kronauer model) to predict the phase of the central clock [120].
• Phase Output: The model outputs an estimate of the circadian phase (e.g., the time of minimum heart rate or core body temperature), which can be compared to behavioral markers like sleep midpoint to quantify misalignment [10].

The following diagram illustrates the core computational workflow for estimating circadian phase from wearable data.

Signaling Pathways and Physiological Basis

The accuracy of mathematical models hinges on their ability to approximate the output of the endogenous biological clock system. The central circadian pacemaker, located in the suprachiasmatic nucleus (SCN), is entrained by light and coordinates rhythms throughout the body.

Table 2: Key Oscillators and Digital Proxies in Circadian Physiology

Oscillator Type	Location	Primary Synchronizer	Key Physiological Rhythms	Digital/Model Proxy
Central Oscillator	Suprachiasmatic Nucleus (SCN) [121] [118]	Light-Dark Cycle [118]	Melatonin secretion, cortisol rhythm, core body temperature rhythm [118] [19]	DLMO (Gold Standard), Model-predicted central phase from activity/light [10] [120]
Peripheral Oscillators	Peripheral Tissues & Organs (e.g., Heart, Liver) [118]	SCN signals, feeding-fasting cycles, activity [118]	Heart rate rhythm, core body temperature rhythm, metabolism [119] [10]	Circadian rhythm in heart rate (CRPO) or body temperature from wearables [119] [10]

The following diagram illustrates the relationship between the central and peripheral oscillators and how they are measured.

The Scientist's Toolkit: Essential Research Reagents and Materials

For researchers designing studies to validate or utilize these circadian phase markers, the following tools are essential.

Table 3: Key Reagents and Solutions for Circadian Rhythm Research

Item	Function/Application	Key Considerations
Saliva Collection Kit (e.g., Salivette)	Non-invasive collection of saliva for melatonin and cortisol analysis [19].	Must use kits that do not interfere with immunoassays or LC-MS/MS.
LC-MS/MS System	Gold-standard analytical platform for quantifying melatonin and cortisol in saliva/serum with high specificity and sensitivity [19].	Overcomes cross-reactivity issues of immunoassays; requires specialized equipment and expertise.
Wrist-Worn Wearable Device (e.g., Fitbit, Actiwatch)	Continuous, passive collection of real-world physiological (HR, HRV) and behavioral (activity, sleep) time-series data [119] [10].	Device model and sampling frequency can impact data quality and model accuracy.
Diurnal Hormone Software or Custom Scripts (R, Python)	Implements mathematical models (e.g., Kalman filter, harmonic regression) for phase estimation from wearable data [119] [10] [120].	Choice of model and its parameters should be tailored to the data source (e.g., HR vs. temperature) and population.
Controlled Light Environment (Light Boxes/Goggles)	For administering precise light exposures in phase-response curve studies or for DLMO protocols [120].	Allows for controlled manipulation of the primary zeitgeber to test model predictions.

Mathematical models using wearable data present a scalable and practical alternative to traditional biomarker methods for assessing circadian phase in real-world settings. For healthy, normally entrained adults, the accuracy of these models is approaching that of DLMO, with errors around one hour [120]. However, in populations with the greatest clinical need for circadian monitoring, such as shift workers, model performance currently degrades, with errors reported around 2.5 hours [120]. The choice of method involves a clear trade-off between the high precision of gold-standard biomarkers and the scalability and rich longitudinal data provided by computational models. Future research should focus on improving model robustness for shift work and clinical populations and on standardizing validation protocols across studies.

The accurate determination of an individual's circadian phase is fundamental to advancing the field of circadian medicine, which studies how biological timing influences health and disease [122]. Circadian rhythms, our internal ~24-hour biological cycles, regulate crucial physiological processes including hormone secretion, sleep-wake cycles, metabolism, and cellular repair [123] [124]. Disruptions to these rhythms are associated with increased risk for numerous conditions, including cardiovascular disease, metabolic disorders, mood disorders, and cancer [2] [125] [122].

Researchers and clinicians have developed multiple methodologies for assessing circadian phase, each with distinct trade-offs between accuracy, participant burden, and invasiveness. The suprachiasmatic nucleus (SCN) in the hypothalamus serves as the master pacemaker, coordinating peripheral clocks throughout the body via complex transcriptional-translational feedback loops involving core clock genes such as CLOCK, BMAL1, PER, and CRY [2] [123] [124]. This molecular machinery drives the rhythmic expression of numerous physiological and behavioral outputs that can be measured as circadian phase markers.

Methodologies for Circadian Phase Assessment

Gold-Standard Biochemical Methods

The most precise circadian phase assessments traditionally involve measuring circadian biomarkers under controlled conditions. These methods are characterized by high accuracy but significant participant burden.

Dim Light Melatonin Onset (DLMO)

Dim Light Melatonin Onset (DLMO) is widely considered the gold standard for assessing circadian phase in humans [2]. The experimental protocol requires participants to remain in dim light conditions (<10-30 lux) for several hours before and during sample collection to prevent light-induced melatonin suppression. Saliva or blood samples are typically collected every 30-60 minutes for 5-8 hours before habitual bedtime. Melatonin concentrations are then assayed using radioimmunoassay (RIA) or enzyme-linked immunosorbent assay (ELISA), with DLMO defined as the time when melatonin levels consistently exceed a threshold (usually 3-4 pg/mL in saliva or 25% of the peak amplitude) [2].

The significant limitations of DLMO assessment include the requirement for strict environmental controls, the time-intensive nature of sample collection, and the high analytical costs. These factors render it impractical for large-scale studies or clinical applications despite its high accuracy for determining circadian phase.

Core Body Temperature (CBT) Minimum

Core Body Temperature (CBT) exhibits a robust circadian rhythm, with its nadir typically occurring 1-3 hours before habitual wake time [2]. The experimental protocol for precise CBT measurement historically required rectal temperature probes with continuous monitoring over at least 24 hours, preferably using a forced desynchrony protocol to separate circadian from masking effects of sleep, activity, and posture. More recently, ingestible temperature sensors have been developed that can transmit CBT data as they pass through the gastrointestinal tract.

While CBT provides valuable phase information, the invasive nature of continuous rectal monitoring and the masking effects of behavioral cycles limit its practicality. The forced desynchrony protocol required to unmask the true circadian component is exceptionally resource-intensive, requiring specialized laboratory facilities with controlled environments for multiple days.

Cortisol Rhythm

The hypothalamic-pituitary-adrenal (HPA) axis exhibits a pronounced circadian rhythm, with cortisol levels peaking around wake-time and reaching their nadir during the night [40]. Assessment typically involves collecting saliva or blood samples at multiple time points throughout the day, with particular emphasis on the cortisol awakening response (CAR). The experimental protocol requires participants to provide samples immediately upon awakening, 30 minutes post-awakening, and at several intervals throughout the day while carefully standardizing factors that influence cortisol levels, such as food intake, stress, and activity.

While cortisol assessment is less burdensome than DLMO measurement, it remains challenging for large-scale studies due to the multiple sample collections required and the sensitivity of cortisol to confounding factors including stress, meals, and medications.

Emerging Non-Invasive Technologies

Recent technological advances have enabled the development of less invasive methods for circadian phase assessment that are suitable for longitudinal monitoring in real-world settings.

Wearable Biosensors

Wearable biosensors represent a promising approach for continuous, non-invasive monitoring of circadian biomarkers. A recent breakthrough demonstrated the feasibility of measuring cortisol and melatonin in passive perspiration using a wearable sensor [40]. The experimental protocol involves participants wearing a wrist-based biosensor that continuously collects sweat samples through microfluidic channels. The sensor incorporates electrochemical detection with specific antibodies for cortisol and melatonin, providing real-time measurements correlated with salivary levels (Pearson r = 0.92 for cortisol and r = 0.90 for melatonin) [40].

This methodology enables continuous dynamic monitoring over multiple days with minimal participant burden, facilitating the assessment of circadian phase shifts in response to interventions or environmental changes. The strong agreement with established salivary measures positions this technology as a viable alternative for circadian phase assessment.

Actigraphy and Sleep-Wake Monitoring

Wrist-worn actigraphy provides an indirect estimate of circadian phase through long-term monitoring of rest-activity patterns [88]. The experimental protocol involves participants wearing an accelerometer-based device on the non-dominant wrist for a minimum of 7-14 days to capture both weekday and weekend patterns. Data are analyzed using algorithms such as Nonparametric Circadian Rhythm Analysis (NPCRA) to derive metrics including interdaily stability, intradaily variability, and relative amplitude.

More advanced devices incorporate multiple sensors including photodetectors, heart rate monitors, and skin temperature sensors to improve accuracy. Machine learning algorithms like ACCEL have been developed to enhance sleep-wake classification, achieving 91.7% accuracy, 96.2% sensitivity, and 80.1% specificity [88]. While actigraphy provides valuable information about rest-activity rhythms, it remains an indirect proxy for the underlying circadian phase rather than a direct measurement.

Molecular and Computational Approaches

Transcriptomic Profiling

Peripheral blood mononuclear cells (PBMCs) can serve as a source for gene expression analysis to determine circadian phase. The experimental protocol involves collecting blood samples at multiple time points (typically every 4-6 hours over 24-48 hours) and analyzing expression patterns of core clock genes (e.g., PER1, PER2, PER3, BMAL1, REV-ERBα) using quantitative PCR or RNA sequencing [125]. Computational methods like TimeTeller then use these expression patterns to predict internal circadian time [122].

This approach provides direct insight into the molecular clockwork but requires multiple blood draws and sophisticated analytical methods. Recent advances in machine learning have enabled circadian phase prediction from single timepoint samples by leveraging data from multiple clock-controlled genes, significantly reducing participant burden [126] [122].

Machine Learning and Artificial Intelligence

Machine learning (ML) approaches are revolutionizing circadian phase assessment by enabling accurate predictions from limited data. The experimental framework involves training algorithms on high-dimensional datasets containing gene expression patterns, physiological parameters, and behavioral metrics from deeply phenotyped participants [126] [125]. These models can then predict circadian phase from minimal input data, such as a single timepoint gene expression sample or wearable device data.

ML models have demonstrated the ability to classify circadian transcripts using only DNA sequence features without any transcriptomic timepoints, leveraging k-mer-based motif representations from regulatory regions [126]. Model interpretation techniques help identify the specific regulatory elements contributing to circadian gene expression, providing both prediction and biological insight.

Comparative Analysis of Methodologies

Quantitative Method Comparison

Table 1: Comprehensive Comparison of Circadian Phase Assessment Methodologies

Methodology	Invasiveness Level	Participant Burden	Accuracy/Reliability	Cost	Time Requirement	Key Applications
DLMO	Moderate-High (frequent saliva/blood sampling)	Very High (controlled lighting, multiple samples)	Gold Standard (highest)	Very High ($150-500/assessment)	5-8 hours sampling + analysis	Basic research, clinical trials, circadian disorders
Core Body Temperature	High (rectal/ingestible sensor)	Very High (lab confinement, 24-48h monitoring)	High (with forced desynchrony)	High ($100-300/assessment)	24-48 hours continuous	Basic research, shift work studies
Cortisol Rhythm	Moderate (multiple saliva samples)	High (strict timing, multiple samples)	Moderate-High	Moderate-High ($75-200/assessment)	12-16 hours sampling	Stress research, HPA axis assessment
Wearable Biosensors	Low (wearable device)	Low (normal activities)	Moderate-High (r=0.9-0.92 vs saliva)	Moderate (device + consumables)	Continuous days-weeks	Longitudinal studies, clinical monitoring
Actigraphy	Low (wrist device)	Low (normal activities)	Moderate (80-92% sleep detection)	Low-Moderate ($50-150/device)	7-14 days minimum	Epidemiological studies, sleep disorders
Transcriptomics	Moderate-High (blood draws)	High (multiple timepoints)	High (molecular level)	Very High ($300-1000+/sample)	24-48 hours sampling	Mechanistic studies, pharmacogenomics
Machine Learning Models	Variable (depends on input data)	Low (minimal data requirements)	Moderate-High (improving)	Low (computational only)	Minutes-hours computation	Large-scale studies, personalized medicine

Method-Specific Advantages and Limitations

Table 2: Advantages and Limitations of Circadian Assessment Methods

Methodology	Key Advantages	Major Limitations	Optimal Use Cases
DLMO	Direct phase marker, high temporal precision, well-validated	High burden, cost, laboratory requirements, influenced by light	Gold-standard research, circadian rhythm sleep-wake disorders
Core Body Temperature	Robust rhythm, minimal assay cost, continuous data	Masking effects, invasive monitoring, requires specialized protocols	Basic research with controlled conditions
Cortisol Rhythm	Relevant for stress physiology, multiple sampling matrices	Affected by stressors, medications, requires strict timing	HPA axis research, stress-related disorders
Wearable Biosensors	Continuous monitoring, real-world assessment, minimal burden	Emerging technology, validation ongoing, device costs	Longitudinal monitoring, clinical applications
Actigraphy	Long-term monitoring, natural environment, well-established	Indirect measure, lower specificity for wake, activity confounds	Population studies, sleep pattern assessment
Transcriptomics	Molecular mechanism insight, single-timepoint potential	High cost, technical expertise, analytical complexity	Mechanistic research, biomarker discovery
Machine Learning	Minimal data requirements, predictive power, scalability	Model dependency, training data requirements, black box issue	Large datasets, personalized health applications

Pathway Integration and Experimental Design

Circadian Regulation Pathways

Research Reagent Solutions

Table 3: Essential Research Reagents for Circadian Phase Assessment

Reagent/Resource	Function/Application	Methodology
Melatonin ELISA/RIA Kits	Quantification of melatonin in saliva, plasma, or sweat	DLMO Assessment
Cortisol ELISA/Kits	Measurement of cortisol levels in various biological matrices	Cortisol Rhythm Analysis
RNA Extraction Kits	Isolation of high-quality RNA from blood or tissue samples	Transcriptomic Profiling
qPCR Reagents & Primers	Analysis of clock gene expression patterns	Molecular Chronotyping
Passive Sweat Biosensors	Continuous monitoring of cortisol and melatonin	Wearable Circadian Assessment
Actigraphy Devices	Monitoring rest-activity cycles and sleep patterns	Actigraphy
Temperature Probes	Continuous core body temperature monitoring	CBT Rhythm Analysis
Circadian Analysis Software	Computational analysis of circadian parameters (e.g., CircaCompare)	Data Analysis Across Methods

The field of circadian phase assessment is rapidly evolving from highly invasive, laboratory-bound methodologies toward minimally invasive, real-world compatible technologies. While DLMO remains the gold standard for precision, emerging approaches like wearable biosensors and machine learning algorithms offer compelling trade-offs that enable larger-scale studies and clinical applications.

Future advancements will likely focus on integrating multiple data streams from wearable devices, developing more sophisticated computational models for phase prediction, and establishing standardized protocols for emerging technologies. The optimal methodology choice depends critically on the specific research question, population characteristics, and resources available, with the cost-benefit analysis shifting as new technologies mature and validate against established standards.

For researchers and drug development professionals, understanding these methodological trade-offs is essential for designing robust studies that accurately capture circadian phase while respecting practical constraints. As circadian medicine continues to emerge as a critical component of personalized healthcare, these assessment methodologies will play an increasingly important role in both basic research and clinical applications.

Chronotherapy, the practice of timing medical treatments to coincide with an individual's biological rhythms, represents a paradigm shift in optimizing therapeutic efficacy and minimizing adverse effects. The fundamental premise is that the circadian clock influences the pharmacokinetics and pharmacodynamics of a vast number of drugs; it is estimated that approximately 50% of all current drugs, including many World Health Organization essential medicines, target the products of rhythmic genes [127] [21]. This is because circadian rhythms regulate diverse physiological processes, including drug metabolism, cell cycle progression, and hormone secretion [128]. Consequently, the effectiveness and toxicity of many medications can vary significantly depending on their administration time [128].

A critical barrier to the widespread clinical adoption of chronotherapy is the accurate, practical, and scalable assessment of an individual's internal circadian time. The current gold standard, Dim Light Melatonin Onset (DLMO), is cumbersome and costly, requiring frequent sample collection under controlled dim-light conditions [21]. This review explores how comparative accuracy research is evaluating novel circadian biomarkers against established standards like DLMO. We focus on how these emerging biomarkers—ranging from blood transcriptomics to wearable-derived digital signals—are being validated and how they hold the potential to provide the precise, individualized timing data necessary to realize the full promise of chronotherapy in clinical trials and practice [129] [10].

Comparative Frameworks: Evaluating Circadian Biomarker Modalities

The development of circadian biomarkers employs various technological modalities, each with distinct strengths and validation pathways. The table below provides a structured comparison of the primary biomarker classes informed by comparative accuracy studies.

Table 1: Comparative Analysis of Primary Circadian Biomarker Modalities

Biomarker Modality	Biological Source	Key Example(s)	Reported Performance vs. DLMO	Primary Advantages	Primary Limitations
Blood Transcriptomics	Blood monocytes or whole blood	BodyTime Assay [21]	High accuracy, equaling DLMO at a lower cost [21]	High accuracy from a single sample; direct molecular insight	Requires blood draw; complex lab processing
Multivariate Blood Biomarkers	Whole blood	PLSR, ZeitZeiger, Elastic Net models [129]	Performance highly dependent on training set size and conditions; risk of overfitting in small studies [129]	Potential for universal application; machine learning optimization	Performance may not translate to real-world, disrupted conditions [129]
Wearable-Derived Digital Markers	Heart rate, activity, sleep from wearables	CRCO-sleep misalignment; CCE marker [112] [10]	Associated with mood and metabolic health risks; validated in large real-world cohorts [112] [10]	Fully non-invasive; continuous, long-term monitoring in real-world settings	An indirect correlate of the central circadian pacemaker

The comparative evaluation of these modalities reveals a critical trade-off. Blood-based methods like the BodyTime assay offer high accuracy and a direct snapshot of the molecular clock but lack convenience for daily use [21]. In contrast, wearable-derived digital markers provide unparalleled, continuous monitoring in an individual's natural environment, making them ideal for long-term chronotherapy management, though they function as robust correlates rather than direct measures of the central pacemaker [10]. Furthermore, research indicates that the performance of multivariate blood biomarkers is not universal; it is heavily influenced by the experimental conditions of the training data. For instance, biomarkers developed under baseline conditions may perform poorly in shift-work scenarios, highlighting the necessity for context-specific training and validation [129].

Case Study 1: The BodyTime Transcriptomic Assay

Experimental Protocol and Workflow

The development of the BodyTime assay followed a rigorous 3-stage biomarker development strategy to ensure robustness and clinical relevance [21]:

• Discovery: The circadian transcriptome of blood monocytes was analyzed using RNA-Seq from 12 individuals in a 40-hour constant routine protocol. This design minimizes confounding effects of sleep, activity, and meals to isolate endogenous circadian gene expression.
• Migration: Identified biomarker genes were migrated from the discovery platform (RNA-Seq) to a clinically viable and robust gene expression profiling platform (NanoString nCounter).
• Validation: The final assay was externally validated in an independent cohort of 28 individuals with early or late chronotypes to confirm its accuracy in predicting internal circadian time.

The following workflow diagram illustrates this development process and the subsequent use of the assay.

Key Research Reagents and Materials

Table 2: Essential Research Reagents for Transcriptomic Biomarker Development

Reagent / Material	Function in Protocol
Constant Routine Protocol	A controlled laboratory procedure to unmask endogenous circadian rhythms by standardizing sleep deprivation, posture, light exposure, and caloric intake [21].
RNA-Seq Platform	A high-content, unbiased discovery platform used to sequence the entire transcriptome and identify rhythmically expressed genes [21].
NanoString nCounter Platform	A clinically relevant, highly reproducible gene expression profiling system used to migrate the biomarker panel for robust, scalable application [21].
Dim Light Melatonin Onset (DLMO)	The gold standard reference test against which the accuracy of the novel biomarker is validated [21].

Case Study 2: Digital Circadian Biomarkers from Wearable Data

Experimental Protocol and Analytical Workflow

The derivation of digital circadian markers leverages large-scale, real-world data from wearable devices. A seminal study analyzed over 50,000 days of data from more than 800 first-year medical trainees using Fitbit devices [10]. The methodology involves:

• Data Collection: Passive, continuous collection of physiological time-series data including heart rate (HR), activity, and sleep.
• Biomarker Estimation: Computational algorithms are applied to this data to infer key circadian parameters.
  • Circadian Rhythm in the Central Oscillator (CRCO): Estimated using a nonlinear Kalman filtering framework that incorporates indirect information from peripheral rhythms [10].
  • Circadian Rhythm in the Peripheral Oscillator (CRPO): Specifically in the heart, estimated from HR data using a nonlinear least squares method [10].
  • Sleep Midpoint: Calculated from sleep-wake data as a marker of behavioral rhythm.
• Misalignment Calculation: Three core digital markers of circadian disruption are derived from the above parameters, focusing on the absolute phase differences between them.

This process enables the large-scale study of circadian disruption in real-world settings, a key advantage over laboratory-bound methods.

Key Digital Markers and Their Clinical Correlates

The primary digital markers reflect different types of physiological misalignment [10]:

• CRCO-Sleep Misalignment: The absolute phase difference between the central oscillator and the sleep-wake cycle. This marker showed the most significant negative impact on next-day mood in a large cohort of medical interns.
• CRPO-Sleep Misalignment: The absolute phase difference between the peripheral (heart) oscillator and the sleep-wake cycle.
• Internal Misalignment: The absolute phase difference between the central and peripheral oscillators.

These markers have demonstrated clinically relevant associations. For example, an independent study identified a novel marker, Continuous wavelet Circadian rhythm Energy (CCE), derived from the continuous wavelet transform of heart rate signals, as a key biomarker for identifying Metabolic Syndrome (MetS). This marker showed higher importance than traditional sleep metrics, and its values were significantly lower in the MetS group [112].

Application in Clinical Trials: Informing Drug Timing

Evidence from Cardiovascular Chronotherapy Trials

Comparative accuracy in chronotherapy is starkly illustrated by major cardiovascular outcome trials investigating the timing of antihypertensive medication. The findings, however, have been conflicting, underscoring the complexity of translating timing into therapy.

Table 3: Comparison of Major Antihypertensive Chronotherapy Trials

Trial Characteristic	Hygia Chronotherapy Trial	TIME Trial
Design	Prospective, randomized, open-label, blinded endpoint (PROBE) [127]	Prospective, randomized, open-label, blinded endpoint (PROBE) [127]
Participants	19,084 hypertensive patients from primary care [127]	21,104 hypertensive patients from primary care [127]
Intervention	Taking all antihypertensive medications at bedtime vs. upon awakening [127]	Taking all antihypertensive medications in the evening vs. in the morning [127]
Primary Outcome	Composite of cardiovascular events (e.g., heart attack, stroke) [127]	Composite of vascular death or hospitalization for nonfatal heart attack or stroke [127]
Key Result	45% lower risk of primary outcome with bedtime dosing (HR 0.55) [127]	No significant difference in primary outcome (HR 0.95) [127]
Notable Methodological Differences	In-person enrollment and follow-up; used ambulatory blood pressure monitoring [127]	Decentralized, online enrollment and follow-up; relied on registry data and self-report [127]

The discrepant results between the Hygia and TIME trials highlight that simply changing clock time without knowledge of an individual's underlying circadian phase may be insufficient. This reinforces the need for personalized chronotherapy guided by accurate biomarkers, rather than a one-size-fits-all approach based on clock time alone.

A Framework for Integrating Biomarkers in Chronotherapy Trials

The lessons from comparative studies lead to a proposed framework for designing more effective drug timing trials. The following diagram outlines a workflow that integrates circadian biomarker assessment to personalize treatment timing.

This framework moves beyond simplistic morning-versus-evening designs. By stratifying patients based on their objectively measured circadian phase, trials can test whether aligning drug administration with an individual's internal biology leads to superior outcomes compared to standard fixed-time dosing.

The Scientist's Toolkit: Key Research Reagents for Circadian Biomarker Research

The following table consolidates essential materials and methodologies critical for conducting comparative accuracy research in circadian science.

Table 4: Essential Research Reagents and Tools for Circadian Biomarker Research

Category / Item	Specific Example(s)	Function / Application
Gold Standard Reference	Dim Light Melatonin Onset (DLMO) [21]	The definitive benchmark for assessing the phase of the central circadian pacemaker; essential for validating any novel circadian biomarker.
Molecular Assay Platforms	RNA-Seq; NanoString nCounter [21]	Technologies for discovering and implementing gene expression-based biomarkers. RNA-Seq is for discovery, while platforms like nCounter are for targeted, clinical application.
Computational Algorithms	ZeitZeiger; Partial Least Squares Regression (PLSR); Elastic Net; Nonlinear Kalman Filtering [129] [21] [10]	Machine learning and statistical methods used to identify biomarker patterns from complex molecular or wearable device data and to infer circadian phase.
Real-world Data Collection	Consumer Wearables (e.g., Fitbit); Mobile Health Apps [112] [10]	Sources of continuous, long-term physiological (heart rate, activity) and behavioral (sleep) data, and patient-reported outcomes (mood) for deriving digital biomarkers.
Controlled Protocols	Constant Routine Protocol; Forced Desynchrony Protocol [129] [21]	Experimental designs used to separate endogenous circadian rhythms from masking effects of sleep, light, and activity, thereby generating high-quality training data for biomarkers.

Comparative accuracy research is the cornerstone for transitioning chronotherapy from a compelling biological concept to a standardized, personalized clinical practice. The systematic evaluation of emerging biomarkers—from blood transcriptomics to digital signals—against rigorous standards like DLMO provides the essential evidence base for their application. The conflicting results from major clinical trials like Hygia and TIME underscore that a simplistic approach to drug timing is inadequate. The path forward lies in integrating validated, practical circadian biomarkers into clinical trial design to stratify patients and personalize treatment schedules. This biomarker-guided framework promises to unlock the full potential of chronotherapy, ultimately leading to more effective treatments with fewer side effects across a wide spectrum of diseases, including cancer, metabolic syndrome, and cardiovascular disorders.

Conclusion

The comparative analysis reveals a trade-off between the high accuracy of gold-standard biomarkers like DLMO and the scalability of emerging digital proxies. While DLMO remains the most precise marker for central circadian timing, methodological advancements in computational modeling and wearable technology are enabling robust, non-invasive phase estimation suitable for large-scale studies. The optimal marker choice is context-dependent, balancing precision requirements with practical constraints. Future directions should focus on standardizing protocols, validating digital biomarkers across diverse clinical populations, and integrating multi-modal approaches to fully capture the complexity of the circadian system. For drug development, this evolving toolkit is paramount for optimizing chronotherapy and understanding the circadian etiology of disease, ultimately paving the way for personalized circadian medicine.

References

• 1. Suprachiasmatic nucleus [https://en.wikipedia.org/wiki/Suprachiasmatic_nucleus]
• 2. Methods for Assessment of Sleep and Circadian Rhythms in ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC12540570/]
• 3. Evolving perspectives on the molecular and neural ... [https://www.sciencedirect.com/science/article/abs/pii/S016622362500195X]
• 4. Circadian system coordination: new perspectives beyond ... [https://www.frontiersin.org/journals/physiology/articles/10.3389/fphys.2025.1553736/full]
• 5. Benchmark for quantitative characterization of circadian ... [https://www.sciencedirect.com/science/article/pii/S030326472400248X]
• 6. Model Research on the Influence of the Biological Clock ... [https://ui.adsabs.harvard.edu/abs/2025Symm...17.1418F/abstract]
• 7. Anatomical Methods to Study the Suprachiasmatic Nucleus [https://pmc.ncbi.nlm.nih.gov/articles/PMC10752494/]
• 8. Circadian rhythms are disrupted in patients and preclinical ... [https://pubmed.ncbi.nlm.nih.gov/40692435/]
• 9. Assessment of circadian rhythms in humans - PubMed Central [https://pmc.ncbi.nlm.nih.gov/articles/PMC3360144/]
• 10. The real-world association between digital markers of ... [https://www.nature.com/articles/s41746-024-01348-6]
• 11. A combined mathematical and experimental approach ... [https://www.nature.com/articles/s42003-025-07931-1]
• 12. Predicting circadian phase across populations: a comparison ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC8503830/]
• 13. Parameterized resetting model captures dose-dependent ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC11802799/]
• 14. Singularity response reveals entrainment properties in ... [https://www.nature.com/articles/s41467-023-38392-x]
• 15. Comparative Efficacy of Commercial Wearables for ... [https://arxiv.org/html/2404.03408v1]
• 16. Review Time to target the circadian clock for drug discovery [https://www.sciencedirect.com/science/article/abs/pii/S0968000422000949]
• 17. ChronobioticsDB: The Database of Drugs and Compounds ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC12286229/]
• 18. Home-based dim light melatonin onset assessment among ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC12413864/]
• 19. Circadian Biomarkers in Humans: Methodological Insights ... [https://www.mdpi.com/2218-273X/15/7/1006]
• 20. Novel Approaches for Assessing Circadian Rhythmicity in ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC7543025/]
• 21. High-accuracy determination of internal circadian time from a ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC6118629/]
• 22. Feasibility and acceptability of self-directed, remote dim ... [https://www.frontiersin.org/journals/sleep/articles/10.3389/frsle.2025.1593196/full]
• 23. Methods for Assessment of Sleep and Circadian Rhythms ... [https://link.springer.com/article/10.1007/s11906-025-01345-4]
• 24. Validation Study | About | CALERA Research [https://info.greenteg.com/calera-research/validation-study]
• 25. Comparative Efficacy of Commercial Wearables for ... [https://pubmed.ncbi.nlm.nih.gov/39348247/]
• 26. The cortisol awakening response (CAR): facts and future ... [https://pubmed.ncbi.nlm.nih.gov/18854200/]
• 27. The cortisol awakening response: Fact or fiction? - PMC [https://pmc.ncbi.nlm.nih.gov/articles/PMC12035071/]
• 28. Associations of the cortisol awakening response (CAR) ... [https://pubmed.ncbi.nlm.nih.gov/18022766/]
• 29. Circadian rhythm as a therapeutic target [https://www.nature.com/articles/s41573-020-00109-w]
• 30. The Impact of Circadian Rhythms on Medication Timing and ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC11586979/]
• 31. Circadian and ultradian patterns of HPA axis activity [https://pubmed.ncbi.nlm.nih.gov/31738971/]
• 32. New research could help boost drug efficacy by getting ... [https://news.umich.edu/new-research-could-help-boost-drug-efficacy-by-getting-dosing-in-rhythm-with-circadian-clocks/]
• 33. Circadian rhythms revealed: unraveling the genetic ... [https://www.frontiersin.org/journals/sleep/articles/10.3389/frsle.2025.1544945/full]
• 34. Methodological Insights into the Detection of Melatonin and ... [https://pubmed.ncbi.nlm.nih.gov/40723877/]
• 35. Circadian Levels of Serum Melatonin and Cortisol in relation ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC4459120/]
• 36. RELATIONSHIP OF ENDOGENOUS CIRCADIAN ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC8530273/]
• 37. Differences between circadian and ultradian organization ... [https://pubmed.ncbi.nlm.nih.gov/2921307/]
• 38. Comparisons of the variability of three markers of ... - PubMed [https://pubmed.ncbi.nlm.nih.gov/12002165/]
• 39. Comprehensive integrative analysis of circadian rhythms in ... [https://www.nature.com/articles/s44323-025-00035-3]
• 40. Circadian inference of rhythmicity using comparative ... [https://www.sciencedirect.com/science/article/pii/S2590137025000834]
• 41. Constant routine protocol [https://en.wikipedia.org/wiki/Constant_routine_protocol]
• 42. Constant Routine Protocol – Knowledge and References [https://taylorandfrancis.com/knowledge/Medicine_and_healthcare/Sleep_medicine/Constant_Routine_Protocol/]
• 43. Distinct Circadian Assessments From Wearable Data ... [https://www.frontiersin.org/journals/digital-health/articles/10.3389/fdgth.2021.727504/full]
• 44. Forced desynchrony of circadian rhythms of body ... [https://pubmed.ncbi.nlm.nih.gov/10442237/]
• 45. Shift Right: Assessing Circadian Rhythm Sleep Disorders ... [https://salimetrics.com/salivary-melatonin-and-dim-light-melatonin-onset-dlmo/]
• 46. Light-based methods for predicting circadian phase in ... [https://www.nature.com/articles/s41598-021-89924-8]
• 47. Circadian Phase Assessment of Core Body Temperature ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC12440587/]
• 48. A novel method to separate circadian from non ... [https://www.sciencedirect.com/science/article/pii/S1389945725001996]
• 49. Higher central circadian temperature amplitude is ... [https://www.nature.com/articles/s41598-024-67297-y]
• 50. Accuracy of non-invasive body temperature measurement ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC10692504/]
• 51. Feasibility analysis of applying non-invasive core body ... [https://www.sciencedirect.com/science/article/abs/pii/S0378778823010575]
• 52. Predicting circadian misalignment with wearable technology [https://pmc.ncbi.nlm.nih.gov/articles/PMC8240654/]
• 53. Wearable Technology in Circadian Rhythm Research [https://www.chronobiologyinmedicine.org/journal/view.php?number=196]
• 54. How wearables can be used to assess circadian physiology [https://pmc.ncbi.nlm.nih.gov/articles/PMC9017161/]
• 55. Best Circadian Rhythm Tracker 2025 [https://web.fibion.com/articles/fibion-krono-vs-actigraph-leap-circadian-research/]
• 56. Circadian rhythm analysis using wearable-based ... [https://www.nature.com/articles/s41746-024-01111-x]
• 57. Past, Present, and Future of Multisensory Wearable ... [https://www.frontiersin.org/journals/digital-health/articles/10.3389/fdgth.2021.721919/full]
• 58. The Efficacy of Wearable Cardiovascular Monitoring ... [https://healthcare-bulletin.co.uk/article/the-efficacy-of-wearable-cardiovascular-monitoring-devices-in-real-time-arrhythmia-detection-systematic-review-3415/]
• 59. Longitudinal Digital Phenotyping of Circadian Rest-Activity ... [https://www.medrxiv.org/content/10.1101/2025.09.20.25336210v1.full-text]
• 60. Computational approaches for individual circadian phase ... [https://www.sciencedirect.com/science/article/abs/pii/S2452310020300160]
• 61. Light-based methods for predicting circadian phase in ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC8149449/]
• 62. Predicting circadian phase across populations: a comparison ... [https://pubmed.ncbi.nlm.nih.gov/34013347/]
• 63. A mathematical model of circadian rhythms and dopamine [https://tbiomed.biomedcentral.com/articles/10.1186/s12976-021-00139-w]
• 64. Assessment of Circadian Rhythms - PMC - PubMed Central [https://pmc.ncbi.nlm.nih.gov/articles/PMC6857846/]
• 65. Clinical physiology of circadian rhythms: A systematic and ... [https://www.sciencedirect.com/science/article/pii/S1697260025000213]
• 66. Mediation analysis of chronotype, sleep-related factors ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC10751214/]
• 67. Comparison of the Munich Chronotype Questionnaire with ... [https://research.rug.nl/en/publications/comparison-of-the-munich-chronotype-questionnaire-with-the-horne-/]
• 68. The linkage between chronotype, social jetlag, and ... [https://www.nature.com/articles/s41598-025-93057-7]
• 69. Association between insomnia symptoms and chronotype ... [https://www.sciencedirect.com/science/article/pii/S235272182500138X]
• 70. Keep Your Mask On: The Benefits of Masking for Behavior and ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC9395722/]
• 71. Human circadian rhythm studies: Practical guidelines for ... [https://www.sciencedirect.com/science/article/pii/S2451994422000062]
• 72. Circadian Rhythms, Sleep Deprivation, and Human ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC3963479/]
• 73. Circadian rhythm biomarker from wearable device data is ... [https://www.nature.com/articles/s41746-023-00827-6]
• 74. Circadian Biomarkers in Humans: Methodological Insights into ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC12293921/]
• 75. Immunoassay Methods - Assay Guidance Manual - NCBI - NIH [https://www.ncbi.nlm.nih.gov/books/NBK92434/]
• 76. Usage and limitations of liquid chromatography-tandem ... [https://pubmed.ncbi.nlm.nih.gov/23129542/]
• 77. Comparative evaluation of four new immunoassays and LC ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC12205834/]
• 78. UPLC-MS/MS simultaneous quantification of urinary ... [https://www.sciencedirect.com/science/article/abs/pii/S1570023223000740]
• 79. Case study: high throughput sample analysis using the ... [https://www.bioanalysis-zone.com/case-study-high-throughput-sample-analysis-using-the-gyrolab-automated-immunoassay-platform_ch_frontage/]
• 80. A high-throughput LC-MS/MS method for simultaneous ... [https://www.sciencedirect.com/science/article/pii/S1570023225002958]
• 81. Correlation between Serum Levels of 3,3ʹ,5ʹ ... [https://journals.plos.org/plosone/article?id=10.1371/journal.pone.0138864]
• 82. Physiology of the Pineal Gland and Melatonin - Endotext - NCBI [https://www.ncbi.nlm.nih.gov/books/NBK550972/]
• 83. A physiologically based mathematical model of melatonin ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC2714090/]
• 84. High sensitivity and interindividual variability in the ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC6575863/]
• 85. Age-Related Changes in Sleep and Circadian Rhythms [https://pmc.ncbi.nlm.nih.gov/articles/PMC3405459/]
• 86. Age-related changes in circadian regulation of the human ... [https://www.nature.com/articles/s42003-023-05102-8]
• 87. Non-24-Hour Sleep-Wake Disorder: Treatments That Work [https://gwinnettsleep.com/non-24-hour-sleep-wake-disorder-treatment-options-that-work/]
• 88. Preventive circadian medicine: improving health with sleep ... [https://www.nature.com/articles/s44323-025-00047-z]
• 89. Circadian rhythm types and shift work demands shape ... [https://www.frontiersin.org/journals/public-health/articles/10.3389/fpubh.2025.1667778/full]
• 90. Case report: Diagnosis and intervention of a non-24-h ... [https://www.frontiersin.org/journals/psychiatry/articles/10.3389/fpsyt.2023.1129153/full]
• 91. Jazz Pharmaceuticals Showcases Phase 4 Data ... [https://investor.jazzpharma.com/news-releases/news-release-details/jazz-pharmaceuticals-showcases-phase-4-data-demonstrating-xywavr]
• 92. Registry and survey of circadian rhythm sleep-wake ... [https://www.sciencedirect.com/science/article/pii/S259014272300040X]
• 93. Using consumer sleep trackers in clinical practice [https://www.chestphysician.org/consumer-sleep-trackers-in-clinical-practice/]
• 94. A guide to consumer-grade wearables in cardiovascular ... [https://www.nature.com/articles/s44325-025-00082-6]
• 95. Reliability of Average Daily Steps Measured Through a ... [https://formative.jmir.org/2025/1/e63153/]
• 96. The Validation and Accuracy of Wearable Heart Rate Trackers ... [https://formative.jmir.org/2025/1/e70835]
• 97. Comparing the Accuracy of Different Wearable Activity ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC12226780/]
• 98. PPG Biosensors Market Size & Trends 2025 to 2035 [https://www.futuremarketinsights.com/reports/ppg-biosensors-market]
• 99. Virtual PPG Reconstruction from Accelerometer Data via ... [https://www.sciencedirect.com/science/article/abs/pii/S1566253525008437]
• 100. Diagnostic accuracy of ECG smart chest patches versus ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC11853970/]
• 101. Fusing Wearable Biosensors with Artificial Intelligence for ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC12025234/]
• 102. A Guide to Environmental Monitoring [https://www.eurofinsus.com/food-testing/resources/a-guide-to-environmental-monitoring/]
• 103. Laboratory Validation of an In-Home Method for Assessing ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC3372704/]
• 104. Laboratory validation of an in-home method for assessing ... [https://www.sciencedirect.com/science/article/abs/pii/S1389945712000068]
• 105. Selecting the Appropriate Error Metric for Your Machine ... [https://medium.com/@ashishkumarojha/selecting-the-appropriate-error-metric-for-your-machine-learning-model-a-case-study-on-data-f7b278ef514a]
• 106. Knowledge-based model validation using a custom metric [https://arxiv.org/html/2412.07521v1]
• 107. Analysis Method and Experimental Conditions Affect ... [https://journals.plos.org/plosone/article?id=10.1371/journal.pone.0033836]
• 108. Cortisol Detection Methods and the Hormone's Role in ... [https://www.mdpi.com/1422-0067/26/18/9141]
• 109. Improving melatonin circadian phase estimates [https://www.sciencedirect.com/science/article/abs/pii/S1389945707000871]
• 110. Analysis method and experimental conditions affect ... - PubMed [https://pubmed.ncbi.nlm.nih.gov/22511928/]
• 111. Evaluation of the Agreement Between Research‐Grade ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC12592815/]
• 112. Detection and Analysis of Circadian Biomarkers for Metabolic ... [https://medinform.jmir.org/2025/1/e69328]
• 113. A Comparative Study Between ECG- and PPG-Based ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC12473955/]
• 114. Accuracy of vital sign monitoring using a ... [https://link.springer.com/article/10.1007/s10877-025-01358-z]
• 115. Comparing the Accuracy of Different Wearable Activity ... [https://www.researchprotocols.org/2025/1/e70472]
• 116. Wearable Devices in Healthcare Beyond the One-Size-Fits ... [https://www.mdpi.com/1424-8220/25/20/6472]
• 117. Integrated wearable PPG: a multi-vital sign monitoring ... [https://pubmed.ncbi.nlm.nih.gov/40193041/]
• 118. Keeping an eye on circadian time in clinical research and ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC9790849/]
• 119. Efficient assessment of real-world dynamics of circadian ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC10445022/]
• 120. Optimal adjustment of the human circadian clock in the real ... [https://journals.plos.org/ploscompbiol/article?id=10.1371/journal.pcbi.1008445]
• 121. Seasonal timing and interindividual differences in shiftwork ... [https://www.nature.com/articles/s41746-025-01678-z]
• 122. TimeTeller for timing health: The potential of circadian ... [https://www.frontiersin.org/journals/digital-health/articles/10.3389/fdgth.2023.1157654/full]
• 123. Circadian Variation in Efficacy of Medications - PMC [https://pmc.ncbi.nlm.nih.gov/articles/PMC8268638/]
• 124. Chrono-tailored drug delivery systems: recent advances ... [https://link.springer.com/article/10.1007/s13346-024-01539-4]
• 125. Machine learning and expression analyses reveal ... [https://www.nature.com/articles/s41598-022-09421-4]
• 126. Interpreting machine learning models to investigate circadian ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC8364196/]
• 127. Trials on Timing of Cardiovascular Medication Administration [https://pmc.ncbi.nlm.nih.gov/articles/PMC12466261/]
• 128. Chronopharmacological strategies focused on chrono-drug ... [https://www.sciencedirect.com/science/article/abs/pii/S0163725819301019]
• 129. Performance of Blood-Based Biomarkers for Human Circadian ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC12572356/]
